1.4
THE GENERATOR
Figure 1.1 – 7 kW, Single Cylinder GH-410 Engine
Exhaust
Enclosure
Figure 1.2 – 12 kW and 15 kW, V-twin GT-990 Engine
Exhaust
Enclosure
Section 1 — General Information
Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators
Oil Check/Fill
Oil Filter
Data
Decal
Oil Dipstick
Air Filter
Oil Filter
Data Decal
Control Panel
Air Filter
Fuel Regulator
Fuel Inlet
Battery Compartment
Control
Panel
Fuel Regulator
Fuel Inlet
Battery Compartment
Generac
®
Power Systems, Inc.
5
