  • Page 1 Not intended for use as Primary Power in place of utility or in life-support applications. DEADLY EXHAUST FUMES. OUTDOOR INSTALLATION ONLY!! Installation and Owner’s Manual Air-cooled Automatic Models: 04758-0 (6 kW NG, 7 kW LP) 04759-0 (12 kW NG, 12 kW LP) 04760-0 (13 kW NG, 15 kW LP) GENERAC POWER SYSTEMS, INC.

  • Page 2: Introduction

    INTRODUCTION Thank you for purchasing this model by Generac Power Systems Inc.. This model is a compact, high performance, air-cooled, engine-driven generator designed to automatically supply electrical power to operate critical loads during a utility power failure. This unit is factory installed in an all-weather, metal enclo- sure that is intended exclusively for outdoor installation.

  • Page 3: Table Of Contents

    Introduction ...Inside Front Cover Read This Manual Thoroughly ...IFC Contents ...IFC Operation and Maintenance ...IFC How to Obtain Service ...IFC Authorized Dealer Locator Number ...IFC Safety Rules ...2 Standards Index ...3 Section 1 – General Information ...4 Unpacking/Inspection ...4 Protection Systems ...4 System Set LED ...4 Your Generator ...5 Specifications ...6...

  • Page 4: General Hazards

    IMPORTANT SAFETY INSTRUCTIONS Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators SAVE THESE INSTRUCTIONS – The manufacturer suggests that these rules for safe operation be copied and posted near the unit’s installation site. Safety should be stressed to all operators and potential operators of this equipment.

  • Page 5: Electrical Hazards

    ELECTRICAL HAZARDS • All generators covered by this manual produce dangerous electrical voltages and can cause fatal electrical shock. Utility power delivers extremely high and dangerous voltages to the transfer switch as does the standby generator when it is in opera- tion.

  • Page 6: Section 1 - General Information

    Section 1 — General Information Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators DANGER Only qualified electricians or contractors should attempt such installations, which must comply strictly with applicable codes, standards and regulations. UNPACKING/INSPECTION After unpacking, carefully inspect the contents for damage.

  • Page 7: Your Generator

    YOUR GENERATOR Figure 1.1 – 7 kW, Single Cylinder GH-410 Engine Exhaust Enclosure Figure 1.2 – 12 kW/15 kW, V-twin GT-990 Engine Exhaust Enclosure Section 1 — General Information Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Control Panel Data Decal Battery Compartment Oil Filter...

  • Page 8: Specifications

    Section 1 — General Information Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators SPECIFICATIONS 1.5.1 GENERATOR Rated Max. Continuous Power Capacity (Watts*) Rated Voltage Rated Max. Continuous Load Current (Amps) 120 Volts + 240 Volts Main Line Circuit Breaker Phase Number of Rotor Poles Rated AC Frequency...

  • Page 9: Fuel Requirements And Recommendations

    FUEL REQUIREMENTS AND RECOMMENDATIONS With LP gas, use only the vapor withdrawal system. This type of system uses the vapors formed above the liquid fuel in the storage tank. The engine has been fitted with a fuel carburetion system that meets the specifications of the 1997 California Air Resources Board for tamper-proof dual fuel systems.

  • Page 10: Location

    Section 1 — General Information Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators 5. Remove the small brass hose fitting from the idle circuit port of the regulator housing. 6. Remove the small jet (0D5698A) located in the side of the regulator housing and install it into the small threaded hole in the idle circuit port on the regulator.

  • Page 11: Battery Installation

    1.10 BATTERY INSTALLATION Fill the battery with the proper electrolyte fluid if nec- essary and have the battery fully charged before installing it. Before installing and connecting the battery, complete the following steps: 1. Set the generator's Auto/Off/Manual switch to OFF .

  • Page 12: Section 2 - Post Installation Start-Up And Adjustments

    Section 2 — Post Installation Start-up and Adjustments Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators The following procedures are to be observed: • Wear full eye protection and protective clothing; • Where electrolyte contacts the skin, wash it off immediately with water;...

  • Page 13: Generator Tests Under Load

    8. Connect an accurate AC voltmeter and a frequen- cy meter across transfer switch terminal lugs E1 and E2. Voltage should be 242-252 volts; fre- quency should read about 61-63 Hertz. 9. Connect the AC voltmeter test leads across termi- nal lug E1 and neutral;...

  • Page 14: Adjusting The Regulator (Natural Gas Only)

    Section 3 — Operation Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators ADJUSTING THE REGULATOR (NATURAL GAS ONLY) Although the generator has been factory set to pro- vide maximum power, it may be necessary in some areas to adjust this setting. Because natural gas has different BTU or power content across the country the engine may not perform as designed.

  • Page 15: Kw And 15 Kw Units

    Figure 2.3 — Engine Governor Adjustment Idle Spring Governor Shaft (Rotate Clockwise) No Load Idle Governor Clamp Bolt Adjustment Screw 2.7.2 12 KW AND 15 KW UNITS 1. Loosen governor clamp bolt (See Figure 2.3). 2. Completely remove the idle spring. 3.

  • Page 16: Using The Auto/Off/Manual Switch

    Section 3 — Operation Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators 8. Turn ON the utility power supply to the transfer switch, which will allow the transfer switch to transfer back to utility power. The unit will con- tinue to run for one minute and then shut down.

  • Page 17: Manual Transfer Operation

    D.Utility Voltage Pickup Sensor • This sensor monitors utility power supply volt- age. When that voltage is restored to above 70 percent of the nominal source voltage, a retrans- fer time delay starts timing. E.Retransfer Time Delay • This timer runs for about 15 seconds. •...

  • Page 18: Setting The Exercise Timer

    Section 3 — Operation Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators SETTING THE EXERCISE TIMER Your generator is equipped with an exercise timer. Once it is set, the generator will start and exercise once every seven days, on the day of the week and at the time of day you complete the following sequence.

  • Page 19: Section 4 - Maintenance

    FUSE The generator panel’s 15 amp fuse (Figure 4.1) protects the DC control circuit against overload. The fuse is wired in series with the battery output lead to the panel. If the fuse element has melted open, you cannot crank or start the engine.

  • Page 20: Oil Change Procedure

    Section 4 — Maintenance Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators 4.3.2 OIL CHANGE PROCEDURE To change the oil, proceed as follows: 1. Run the engine until it is thoroughly warmed up then shut OFF the engine. 2.

  • Page 21: Spark Plug(S)

    SPARK PLUG(S) Reset the spark plug(s) gap or replace the spark plug(s) as necessary. See Section 4.13 (Page 22) for maintenance requirements. 1. Clean the area around the base of the spark plug(s) to keep dirt and debris out of the engine. Clean by scraping or washing using a wire brush and commercial solvent.

  • Page 22: Adjusting Valve Clearance

    Section 4 — Maintenance Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators 4.8 ADJUSTING VALVE CLEARANCE After the first 50 hours of operation, you should adjust the valve clearance in the engine. Important: If you feel uncomfortable about doing this procedure or you don't have the proper tools, please contact your Generac Authorized dealer for service assistance.

  • Page 23: Attention After Submersion

    4.10 ATTENTION AFTER SUBMERSION If the generator has been submerged in water, it MUST NOT be started and operated. Following any sub- mersion in water, have a Generac Authorized Dealer thor- oughly clean and dry the generator. 4.11 CORROSION PROTECTION Periodically wash and wax the enclosure using automo- tive type products.

  • Page 24: Service Schedule

    Section 4 — Maintenance Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators 4.13 SERVICE SCHEDULE ATTENTION: It is recommended that all service work be performed by your nearest Generac Authorized Dealer. SYSTEM/COMPONENT X = Action R = Replace as Necessary * = Notify Dealer if Repair is Needed.

  • Page 25: Section 5 - Troubleshooting

    TROUBLESHOOTING GUIDE PROBLEM The engine will not crank. The engine cranks but will not start. The engine starts hard and runs rough. The Auto/Off/Manual switch is set to OFF , but the engine continues to run. There is no AC output from the generator.

  • Page 26: Section 6 - Electrical Data

    Section 6 — Electrical Data Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Wiring Diagram – 12 & 15 kW – Drawing No. 0D8500 DIAGRAM KEY BA - BRUSH ASSEMBLY BCR - BATTERY CHARGE RELAY CB1 - MAIN OUTPUT BREAKER CB2 - CIRCUIT BREAKER, ALTERNATOR EXCITATION D - DIODE DSW - PCB MOUNTED DIP SWITCH...
  • Page 27 224A 225A 224A 225A 225B 224B VOLTAGE REGULATOR Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Wiring Diagram – 12 & 15 kW – Drawing No. 0D8500 CONTROL PANEL BOX AUTO MANUAL Section 6 — Electrical Data CLOSEST TO BEARING STATOR CUSTOMER CONNECTION...
  • Page 28 Section 6 — Electrical Data Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Electrical Schematic – 12 & 15 kW – Drawing No. 0D8501 ELECTRONIC VOLTAGE REGULATOR DIAGRAM KEY BA - BRUSH ASSEMBLY BCR - BATTERY CHARGE RELAY CB1 - CIRCUIT BREAKER, MAIN OUTPUT CB2 - CIRCUIT BREAKER, ALT.
  • Page 29 225A 56VA 224A C1-5 Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Electrical Schematic – 12 & 15 kW – Drawing No. 0D8501 C2-6 C2-5 C2-1 C1-1 Section 6 — Electrical Data CUSTOMER CONNECTIONS NEUTRAL 120V 120V POWER WINDING (STATOR) 240V BATTERY...
  • Page 30 Section 6 — Electrical Data Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Wiring Diagram – 7 kW – Drawing No. 0D9013 DIAGRAM KEY BA - BRUSH ASSEMBLY BCR - BATTERY CHARGE RELAY CB1 - MAIN OUTPUT BREAKER CB2 - CIRCUIT BREAKER, ALTERNATOR EXCITATION D - DIODE DSW - PCB MOUNTED DIP SWITCH...
  • Page 31 224A 225A 224A 225A 225A 224A VOLTAGE REGULATOR Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Wiring Diagram – 7 kW – Drawing No. 0D9013 CONTROL PANEL BOX CUSTOMER CONNECTION AUTO MANUAL Section 6 — Electrical Data CLOSEST TO BEARING CLOSEST TO BEARING STATOR STATOR...
  • Page 32 Section 6 — Electrical Data Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Electrical Schematic – 7 kW – Drawing No. 0D9014 ELECTRONIC C2-10 VOLTAGE REGULATOR C2-8 DIAGRAM KEY BA - BRUSH ASSEMBLY BCR - BATTERY CHARGE RELAY CB1 - CIRCUIT BREAKER, MAIN OUTPUT CB2 - CIRCUIT BREAKER, ALT.
  • Page 33 56VA 224A C1-1 C1-5 Section 6 — Electrical Data Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Electrical Schematic – 7 kW – Drawing No. 0D9014 C2-6 C2-5 C1-2 C1-6 CUSTOMER CONNECTIONS NEUTRAL 120V 120V POWER WINDING (STATOR) 240V BATTERY BLACK...

  • Page 34: Section 7 - Exploded Views And Parts Lists

    Section 7 — Exploded Views and Parts Lists Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Enclosure – Drawing No. 0D3416-K 44 85 79 80...
  • Page 35 ITEM PART NO. QTY. DESCRIPTION 0C6140 ASSEMBLY, ENCLOSURE BASE (12KW / 15KW) 0D1901 ASSEMBLY, ENCLOSURE BASE (7KW) 0C6735 SUPPORT, ROOF FOLDING 0C7061 ENCLOSURE, FRONT 0C7062 ENCLOSURE, EXHAUST SIDE (12KW / 15KW) 0C7062A ENCLOSURE, EXHAUST SIDE (7KW) 0C7063 ENCLOSURE, SIDE & BACK (12KW / 15KW) 0C7063A ENCLOSURE, SIDE &...
  • Page 36 Section 7 — Exploded Views and Parts Lists Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Control Panel – Drawing No. 0D8503-E...
  • Page 37 ITEM PART NO. QTY. DESCRIPTION 0A9947E CIRCUIT BREAKER 30 X 2 240V SQD QOU230 (7KW) 0A9947G CIRCUIT BREAKER 40 X 2 240V SQD QOU240 (8.5KW) 0A9947F CIRCUIT BREAKER 50 X 2 240V SQD QOU250 (12KW) 0A9947C CIRCUIT BREAKER 60 X 2 240V SQD QOU260 (13KW) 0A9947D CIRCUIT BREAKER 70 X 2 240V SQD...
  • Page 38 Section 7 — Exploded Views and Parts Lists Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators GT-990 Engine – Drawing No. 0D8674-C Part 1 29 28 Kit Contains: 66 2, 5, 19, 20, 39, 40, 47, 64, 93, 140 8, 11, 12, 13 4, 5, 6 16A, 16B, 17, 18...
  • Page 39 ITEM PART NO. QTY. DESCRIPTION 0C5729 ASSEMBLY, CRANKCASE HOUSING WITH SLEEVE 0C3008 SEAL, 38 I.D. CRANKSHAFT 090388 SCREW, TAPTITE M6-1.0 X 12 YC 0C5372 ASSEMBLY, BREATHER 0C3005 GASKET, BREATHER COVER 0C3003 SEPARATOR, OIL BREATHER 0D8067A ASSEMBLY, HEAD #1 G&S 071983 RETAINER, PISTON PIN 20 0C2981C ROCKER, COVER NO OIL FILL...
  • Page 40 Section 7 — Exploded Views and Parts Lists Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators GT-990/760 Engine – Drawing No. 0D8674-C Part 2 86 85 115 116...
  • Page 41 ITEM PART NO. QTY. DESCRIPTION 0C5136A KNOB, AIR CLEANER 0C3024 COVER, AIRBOX NG/LP 0C3040 PRE-CLEANER, 0C8127 ELEMENT, AIR CLEANER 0D8564A ASSEMBLY, MIXER/AIRBOX 990 0D8564B ASSEMBLY, MIXER/AIRBOX 760 0D2595 SCREW SHOULDER (8MM) M6-1.0 X 18 0D4417 WASHER,RUBBER 1/4" X 1/8" THICK 0C3025 SWITCH, OIL PRESS 0D3083...
  • Page 42 Section 7 — Exploded Views and Parts Lists Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators 7 kW Generator – Drawing No. 0D3504-B...
  • Page 43 ITEM PART NO. 0C6934 0C9935H 0C9934H 0C6043A 0C8096 0C9593 0D3220 0C8860 031971 0C3168 056147 0D1847 0C7038C 0D1647 0D2558 0C7038B 0C7758 0388050AE0 0C2417A 082121C 066386 029451 049451 022237 022511 022131 039287 022145 049820 090388 022129 022259 059637 048031K 0C9592 057822 040976 0C2824 025145 090239...
  • Page 44 Section 7 — Exploded Views and Parts Lists Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators 12 kW and 15 kW Generator – Drawing No. 0D3417-B...
  • Page 45 ITEM PART NO. 0C6934 0C7930 0D2359 0C7944 0D2356 0C6043 0D2336 0C6042 0D3220 0C8101 056482 0C3168 0D1838 0D1846 0C7038 0D1609 0D2559 0C7038A 0C7758 0388050AD0 0C2417A 082121C 066386 029451 049451 022237 022511 022131 039288 022145 049820 045756 022129 022259 059637 083512 074994 057822 052858 0C2824...
  • Page 46 Section 7 — Exploded Views and Parts Lists Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators GN410 Engine – Drawing No. 0D3539-B Part 1...
  • Page 47 ITEM PART NO. QTY. DESCRIPTION 071978 ASSEMBLY, CONNECTING ROD 071980 PIN, PISTON D20 021533 SET, PISTON RING 90MM 0C5848 PISTON, HC 071983 RETAINER, PISTON PIN 20 0D4287 ASSEMBLY, CRANKSHAFT GH410 SMALL TAPER 0A7628 ARM, GOVERNOR RC45 078658 PIN, "R" GOVERNOR ARM 078659 WASHER, GOVERNOR ARM THRUST 088261E...
  • Page 48 Section 7 — Exploded Views and Parts Lists Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators GN410 Engine – Drawing No. 0D3539-B Part 2...
  • Page 49 ITEM PART NO. 0C1069 0D2922 0C8435 0C9997 088434 045756 088433B 0C3794 021544 040976 022129 0C2458A 083512 0D1401 091039 0C9619 049811 022097 040945 086999 0D5667A 049821 099236 070185 082774 091222ESRV 067198N 067890 072347 072734 072735 0C3978 0C6040 084542 092079 0A8222 083502 083503 0D3083 0C8434...
  • Page 50 Section 7 — Exploded Views and Parts Lists Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Gas Regulator – Drawing No. 0D8720-B...
  • Page 51 ITEM PART NO. 0D5694 0C5765 0C4647 0C4680 0C6070 022985 022264 075475 0C5760A 0C6606 097934 0C4645 0C5761 0C5968 0C6066 0C5759 0C5764 0C5764A 070728 070728 0C6069 0C5762 045764 045764 0C6731 0C6067 0C4706 0C6068 0C4643A 026073 0A4032 0D3308 0D3308 0C4643 028414A 0D5698A 0C5760B 0C5760C 0C5760D 0C5760E...

  • Page 52: Section 8 - Mounting Dimensions

    Section 8 — Mounting Dimensions Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators Drawing No. 0D3739-B...

  • Page 53: Section 9 - Notes

    Section 9 — Notes Guardian Air-cooled 7 kW, 12 kW and 15 kW Generators...

  • Page 54: Section 10 - Warranty

    (ECS Warranty), which is provided to you by Generac pursuant to California and federal law. See also the “Generac Limited Warranties for Generac Power Systems, Inc.,” which is enclosed herewith on a separate sheet, also provided to you by Generac.
  • Page 55 Emission Control System Warranty (ECS Warranty) for 1997 and later model year engines: (a) Applicability: This warranty shall apply to 1997 and later model year engines. The ECS Warranty Period shall begin on the date the new engine or equipment is purchased by/delivered to its original, end-use purchaser/owner and shall continue for 24 consecutive months thereafter.

  • Page 56: Warranty Schedule

    GUARDIAN “EMERGENCY AUTOMATIC STANDBY GENERATORS” For a period of two years from the date of original sale, Generac Power Systems, Inc. (Generac) will, at its option, repair or replace any part which, upon examination, inspection and testing by Generac or a Generac Authorized Warranty Service Dealer, is found to be defective under normal use and service, in accordance with the warranty schedule set forth below.
