- Page 1 TCM-3111 H.264 Megapixel IP PoE Fixed Camera Hardware User’s Manual Ver. 2012/12/12...
-
Page 2: Table Of Contents
TCM-3111 Hardware User’s Manual Table of Contents Precautions Introduction Package Contents ................4 Features and Benefits ..............5 Safety Instructions ................6 Physical description ................ 8 Installation Procedure ...... Error! Bookmark not defined. Ceiling Mount ........Error! Bookmark not defined. Wall Mount ........Error! Bookmark not defined. -
Page 3: Precautions
TCM-3111 Hardware User’s Manual 0. Precautions Read these instructions You should read all the safety and operating instructions before using this product. Heed all warnings You must adhere to all the warnings on the product and in the instruction manual. Failure to follow the safety instruction given may directly endanger people, cause damage to the system or to other equipment. -
Page 4: Introduction
TCM-3111 Hardware User’s Manual 1. Introduction Package Contents TCM-3111 Product CD Accessories Warranty Card Drill Template www.acti.com... -
Page 5: Features And Benefits
TCM-3111 Hardware User’s Manual Features and Benefits This is a cutting-edge digital video surveillance camera. It can compress and transmit real time images with outstanding image quality (18 FPS @ SXGA, 1280x1024) through a standard TCP/IP network. This camera is your best choice to build an intelligent IP surveillance system. -
Page 6: Safety Instructions
TCM-3111 Hardware User’s Manual Safety Instructions Don’t use the power supply with other voltages This device is likely to be damaged or damage other equipments / personnel, if you use a power supply with different voltage than the one included with this device. All warranty of this product will be voided in the situations above. - Page 7 TCM-3111 Hardware User’s Manual Safety Check Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine if the video product is in proper operating condition. www.acti.com...
-
Page 8: Physical Description
TCM-3111 Hardware User’s Manual Physical description 1) Power LED LED light will light up after the Camera has successfully completed the boot process. 2) Ethernet Port The IP device connects to the Ethernet via a standard RJ45 connector. Supporting NWAY, this IP device can auto detect the speed of local network segment (10Base-T/100Base-TX Ethernet). -
Page 9: Installation Procedure
TCM-3111 Hardware User’s Manual Installation Procedure Ceiling Mount Use the drill template, and drill a hole with φ35 on the ceiling Use the mounting plate and choose the correct three screw holes. There are two versions of the mounting plate. - Page 10 TCM-3111 Hardware User’s Manual Tighten the plate to ceiling with T4*20 screws (not to use screws other than flat heads). Please make sure the screw is flat on the plate, protruding is incorrect. Connect cables through the hole on the ceiling and plate, or on the side of casing...
- Page 11 TCM-3111 Hardware User’s Manual Fasten the camera to ceiling by turning clockwise direction Insert the cables (Power/Network/DIO/Audio) through the mounting plate and connect to the camera. Then use the little strap in bundled accessory to fasten the network cable. www.acti.com...
- Page 12 TCM-3111 Hardware User’s Manual 1.6.1.6 Done www.acti.com...
-
Page 13: Wall Mount
TCM-3111 Hardware User’s Manual Wall Mount Tighten wall mount bracket to the wall by 3 PAN Head Tapping screws Use the mounting plate and choose the correct three screw holes. There are two versions of the mounting plate. Tighten the plate to wall mount bracket with... - Page 14 TCM-3111 Hardware User’s Manual Please make sure the screw is flat on the plate, protruding is incorrect. Insert the cables (power/Network/audio) through the mounting plate and connect to the camera. Then use the little strap in bundled accessory to fasten the network cable.
- Page 15 TCM-3111 Hardware User’s Manual Fasten the camera to wall mount kit by turning clockwise direction and done www.acti.com...
-
Page 16: Basic Connections
TCM-3111 Hardware User’s Manual Basic Connections Follow the procedures below to connect the IP device to the respective apparatuses. Please use a PoE (Power over Ethernet) supported switch or injector: 1) Connect your IP Camera to the Switch / Injector by CAT5 or CAT6 cables with RJ45 connector. -
Page 17: Product Specification
TCM-3111 Hardware User’s Manual Product Specification TCM-3111 • Device Device Type Fixed Dome Camera Image Sensor Progressive Scan CMOS 1/3” (4.8 x 3.6 mm) Sensor Size Day / Night Yes (electronic) Minimum Illumination Color: 0.5 lux at F1.0 (30 IRE, 2400°K); B/W: 0.5 lux... -
Page 18: Accessing Camera
TCM-3111 Hardware User’s Manual 2. Accessing Camera If you have DHCP server / router in your network: Many network server / routers are able to automatically provide IP addresses through DHCP. If you are using such a network, just plug in your computer and IP Camera into the network and your IP device will acquire network address by itself. - Page 19 TCM-3111 Hardware User’s Manual Please set the settings as below. IP address: 192.168. 0.xxx Subnet mask: 255.255.255. (NOTE: xxx should be a number from 1 to 254 except 100, which is used by the IP device. Please also...
- Page 20 TCM-3111 Hardware User’s Manual If you are using a single camera, this is enough to access the device. If you are using multiple devices, you need to change the current device to another unused IP address, so that when the next device is connected to the network, no two devices use the same IP.
- Page 21 TCM-3111 Hardware User’s Manual 10. Click “Apply” 11. Please go to System -> Save & Reboot, and click “Apply”. Internet Explorer will close after a few seconds. This is normal. 12. Wait for 30 seconds, and open IE again to connect to the IP.
