Working with Roamer Remote Management

DVD drive
007-5717-001
If the server you purchased has the optional Roamer remote management hardware present, then
the server can be managed remotely using this option. The Roamer option provides standard
motherboards with enhanced remote control and serial redirection capabilities. The Roamer is
accessed locally using an RJ-45 serial connection (shown in
With the Roamer option comes a LCD display. This display can be directly programmed within
the OS. The LCD display can also be used to display server status, and other information as
needed.
LCD Front panel I/O
Rear fans
Figure 4-1
Front and Rear Panel Components
Working with Roamer Remote Management
Figure 4-1).
Disk drives
Power LED
button indicator
lights
Power Power
cord switch
connector
Serial
connector
25
