1: Overview
Front and Rear Panel Components
DVD drive
8
Figure 1-3
shows the components of the front and rear panels of a typical C2005 server.
LCD
Front panel I/O
Rear fans
Figure 1-3
Front and Rear Panel Components
Disk drives
Power
LED
button
indicator
lights
Power
Power
cord
switch
connector
Serial
connector
007-5717-001
