Hi Sharp Digital video recorder User Manual page 98

3
Main Screen
Live Screen
1
3
<AVI Storage>
On storing AVI, it stops the archive automatically by the setup time
on the option, without any stop order.
4
Screen Splitting Button
It supports up to 64 screen splitting.
• Full Screen Button
It shows the view of live screen. .
5
Screen Movement Button
On the splitting live screen, it moves the next or the before.
1
2
Channel name
2
Recording Status
3
DVR name
4
4
Current time
Pop-up menu on clicking the right button of mouse,
•Stop : Temporary stops the current image of live view.
•Close: Close the live channel screen .
•Saving Image file : Saving the current live view .
•Print: Printing out the current live view.
•AVI : Saving the current live view as AVI file.
98 98
