Hi Sharp Digital video recorder User Manual page 92

<Use management add/modify >
Option management
2
<Option management>
<Recommended Graphic Card>
ATI series : Radeon7000 series (More than 32M, more than 64M recommendable), RADEON series...
NVIDIA series : More than M64 series (Min over 32M, more than 64M recommendable), GEFORCE series
Etc :VGA card to support YUV mode... , Recommended 2 times memory when dual monitor is used.
Space for saving data
Sets ups basic path of AVI file to save
AVI Saving time
Sets up saving time of AVI file from CMS.
Transmission Speed
High Speed : System sends off images at high speed possible.
Low Speed : System sends off image at normal speed in consideration of stability.
Event Sound
Set ups sound file
(*.wav), when the event occurs.
User name :
Type the user name authorized in DVR
Password:
Type the password authorized in DVR
User Description:
Shows the user information
Language : To choose program'
language.
Video output : ATI
YUV mode : According to your PC
graphic card ability, the support can be
decided. This mode shows faster, clear
ability of image transmission than RGB
mode.
RGB mode : nVidia
It is widely compatible with most graphic
cards, and select this when TUV mode
is not supported.
※ Above setting value will apply after
restarting of the program.
