Swisher T1360B1 Owner's Manual
  1. Manuals
  2. Brands
  3. Swisher Manuals
  4. Trailmower
  5. T1360B1
  6. Owner's manual
Swisher T1360B1 Owner's Manual

Swisher T1360B1 Owner's Manual

60” finish cut trailmower
Hide thumbs Also See for T1360B1:
Table of Contents

Advertisement

Quick Links

www.swisherinc.com
OWNER'S
MANUAL
STARTING SERIAL #:
L108-152001
MODEL NO.
T1360B1
T1360T
T1360H
T1360K
T13560
RK1360
T14560
T14560EC
T17560
T18560
T18560EC
T14560-CA
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
Rev 08-142
P.O. BOX 67, WARRENSBURG, MISSOURI 64093
Manufacturing quality lawn care equipment since 1945
10809
60" FINISH CUT
TRAILMOWER
Assembly
Operation
Service and Adjustment
Repair Parts
PHONE 660-747-8183 FAX 660-747-8650
Made In The
USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T1360B1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Swisher T1360B1

Summary of Contents for Swisher T1360B1

  • Page 1 OWNER’S MANUAL STARTING SERIAL #: L108-152001 MODEL NO. T1360B1 T1360T T1360H 60” FINISH CUT T1360K T13560 RK1360 TRAILMOWER T14560 T14560EC T17560 T18560 T18560EC T14560-CA IMPORTANT Assembly Read and follow all Safety Precautions Operation and Instructions before operating this Service and Adjustment equipment.

  • Page 2: Limited Warranty

    1-800-222-8183. model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects.
  • Page 4 (EECS) on your model year 2006 and later Swisher Product. In California, new Outdoor Power Equipment, must be designed, built and equipped to meet the State’s stringent anti-smog standards. Swisher Mower must warrant the EECS on your Power Equipment, for the period of time listed below provided there has been no abuse, neglect, or improper maintenance.

  • Page 5: Safety Decals

    SAFETY DECALS Replace decals immediately if damaged.Order by part number from Swisher Mowers OD11- No step Decal OD45- Warning Decal OD55- Triangle Danger Decal OD33- Speed Decal OD43- Flying Debris Decal OD29- Danger Decal...
  • Page 6 REQUIRED ASSEMBLY FRONT WHEEL CASTER ASSEMBLY 1. Remove single nut and washers from caster shaft. 2. Place one washer on the shaft of the caster/wheel sub-assembly. 3. Slide same shaft through the bearing/frame with wheel towards the ground. 4. Place the other washer on the shaft; it should be resting on the top bearing. 5.

  • Page 7: Intended Use

    STARTING THE ENGINE See engine manufacturer’s instructions for the type and amount of oil and fuel used. TrailMowers with electric start engines will need a battery (sold separately). Swisher recommends using a standard “U 1 R” lawn & garden battery.
  • Page 8 • Make sure the tow vehicle parking brake is set, mower is level, and blades are disengaged. • Check spark plug wire, oil, and fuel. • Check all electrical connections (See Schematics). • Make sure toggle switch is turned “ON” and the red tether is properly attached. •...

  • Page 9: General Troubleshooting

    ALTERNATIVE STOPPING METHOD • Bring vehicle to complete stop, shut off engine, and set parking brake. • Disengage blade engage lever (6008). • Manually shut toggle and key switches to their “OFF” positions. • Always remember to remove keys to avoid irresponsible usage. TRANSPORTING MOWER •...

  • Page 10: Mower Maintenance

    MOWER MAINTENANCE GENERAL RECOMMENDATIONS The warranty on this Trailmower does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, operator must maintain unit as instructed in this manual. Some adjustments will need to be made periodically to maintain your unit properly. All adjustments in this manual should be checked at least once each season.
  • Page 11 Item # Description Part # Swivel Hitch Frame 6014TC Detail Bearing Cotter Pin NB126 Rear Axle 6034 Height Adjustment Handle 5/16 PAL Nut NB276 Plastic Knob Crank Arm ES214 5/8 ID X 1 OD 14 Ga Washer NB149 5/8 ID X 1 OD 10 Ga Washer NB178 Eye Bolt 10038...
  • Page 12 GAS TANK ASSEMBLY TANK ASSEMBLY / UNIT MODEL PART # POL14560B POL14560C RK1360 T13560 #6059 T13560B1 T1360T T17560 13 SEE T1360B1 DETAIL T14560 T1360H #6059H #6080 T1360K MOWER DECK DETAIL Item No. Description Part # Belt Cover 6025TK Grass Chute...
  • Page 13 MOTOR BASE DETAIL Slide plastic tube snug against toggle switch. HEAT SHIELD 6052TK NOT USED ON HONDA UNITS MOTOR BASE DETAIL Item No. Description Part # Heat Shield 6052TK Throttle 686N Toggle Switch 685SP Control Console 10737* Ignition Switch 3623 DETAIL 10 Base - Motor, Painted 6003*...

  • Page 14: Engine Detail

    ENGINE DETAIL BRIGGS / TECUMSEH > DETAIL - 1 DETAIL - 1 Item No. Description Part # UPPER SPACER 689L 5-1/2'' ENGINE PULLY 1/4/ X 1'' KEY STOCK 9031 LOWER SPACER 689S 3/8 BELLEVILLE WASHER FLAT WASHER TR150W 3/8-24 X 1BOLT [BRIGGS ] NB452N 7/16-20 X 1 BLOT [TECUMSEH ] NB238N...

  • Page 15: Wiring Schematics

    WIRING SCHEMATICS...

  • Page 16: How To Order Repair Parts

    The model number for the engine will be found on the top of the blower fan housing. T1360B1 All mower parts listed herein may be ordered directly from Swisher Mower & Machine Co. Inc. or your nearest Swisher T1360T dealer. All engine parts may be ordered from the nearest dealer of the...

This manual is also suitable for:

T1360tT1360hT1360kT13560Rk1360T14560 ... Show all

Table of Contents
