Page 1: Instruction Manual
MODEL G7209 AND G7210 INSTRUCTION MANUAL COPYRIGHT © 1999 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. OCTOBER, 2001 PRINTED IN TAIWAN... - Page 2 Some dust created by power sanding, sawing, grind- ing, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...
-
Page 3: Table Of Contents
CLEAN UP ...12 SITE CONSIDERATIONS...12 4. ASSEMBLY BEGINNING ASSEMBLY ...13 EXTENSION WINGS...13-14 FENCE RAILS ...14-15 GUARD SUPPORT SHAFT ...15 SAW BLADE ...15 MOTOR BRACKET ...15-16 BLADE GUARD ...16-17 TABLE INSERT ...18 5. ADJUSTMENTS BLADE HEIGHT ...19 BLADE TILT ...19 MITER SLOT ...20-21 MITER GAUGE...22... -
Page 4: Safety
G7209/10 14'' Table Saw VISITORS... - Page 5 15. USE RECOMMENDED ACCESSORIES. Consult the owner’s manual for recom- mended accessories. The use of improper accessories may cause risk of injury. G7209/10 14'' Table Saw 16. REDUCE THE RISK OF UNINTENTION- 17. MANY WOODWORKING TOOLS CAN LENGTH 50ft 100ft 18.
-
Page 6: Additional Safety Instructions For Table Saws
NEVER stand or have any part of your body in line with the path of the saw blade. ALWAYS hold the work firmly against the miter gauge or fence while holding down against the table. -
Page 7: Safety Accessories
Grizzly also carries a wide selection of table inserts in the Grizzly catalog. Be sure to hold the insert firmly in place with a piece of wood when creating slots. Never hold the table insert with... - Page 8 To make a featherboard, cut a 30- 40° angle at one end of the board and make a number of end cuts at approximately and 2" to 3" deep. Grizzly also offers a number of featherboards in the Grizzly catalog. See Figure 4.
-
Page 9: Common Definitions, Terms And Phrases
It is important that you read and become familiar with them before assembling, adjusting or operating this machine. Your safety is VERY important to us at Grizzly! Arbor: Metal shaft extending from the drive mechanism, to which the cutting blade is attached. -
Page 10: Circuit Requirements
The motor will safely draw about 22 amps at 220V under load. If you operate the G7210 on any cir- cuit that is already close to its capacity, it might blow a fuse or trip a circuit breaker. However, if an... -
Page 11: Grounding And Extension Cords
Serious injury may occur. G7209/10 14'' Table Saw Extension Cords We do not recommend the use of extension cords on 220V equipment. It is much better to arrange the placement of your equipment and the installed wiring to eliminate the need for extension cords. -
Page 12: Information
However, owing to Grizzly’s policy of con- tinuous improvement, changes may be made at any time with no obligation on the part of Grizzly. Whenever possible, though, we send manual updates to all owners of a particular tool or machine. -
Page 13: Unpacking
Failure to do so could result in injury. G7209/10 14'' Table Saw After all the parts have been removed from their containers, you should have: In the event that any nonproprietary parts are missing (e.g. -
Page 14: Clean Up
G7209/10 are coated with a waxy grease that protects them from corrosion during shipment. Clean this grease off with a solvent cleaner or cit- rus-based degreaser such as Grizzly’s G7895 Degreaser. Do not use chlorine-based solvents – if you happen to splash some onto a painted sur- face, you’ll ruin the finish. -
Page 15: Assembly
TOOLS REQUIRED: You will need a high quality square, a long straightedge, 10mm, 12mm, 14mm open end wrenches and a 3mm Allen G7209/10 14'' Table Saw Extension Wings Inspect the extension wings for burrs or foreign material that may inhibit assembly. The mating edges of the wings and table must be clean, smooth, and flat. -
Page 16: Fence Rails
Figure 9. Place a combination square set at ⁄ ", at the edge of the table, and adjust the rail so it is consistently the table. Figure 9. Front rail attachment procedure. G7209/10 14'' Table Saw ⁄ " below the top of... -
Page 17: Guard Support Shaft
Guard Support Shaft To install the guard support shaft: Push the threaded end of the shaft through the hole in the back of the saw (Figure 10B) until the shoulder on the shaft stops it. Secure with the hex nut and washer. -
Page 18: Motor Bracket
Your saw comes from the factory with a red motor bracket designed to protect the motor assembly during shipping. Remove the bracket shown in Figure 10C. Blade Guard/Splitter Slip the blade guard/splitter over the mount- ing bolts as shown in Figure 12. The wash- ers should be between the bolt head and the slots. -
Page 19: Blade Guard
Readjust blade to 90° and raise and lower it through the full range. There should be no contact between the base and the table insert, or any other part of the saw. If it does, repeat Steps 7-9. -17-... -
Page 20: Table Insert
45° position. Wear leather gloves while rotating the blade to prevent being cut. Be sure to review Section 5: Adjustments, “Blade Alignment,” before operating the saw. -18- adjust- Figure 18. Setscrew on each corner of insert. G7209/10 14'' Table Saw... -
Page 21: Adjustments
⁄ " above the surface of the material you plan on cutting. The handwheel at the front of the saw adjusts blade height. To adjust blade height: Loosen the locking knob at the center of the blade height handwheel. -
Page 22: Miter Slot
Miter Slot to Blade Your table saw will give the best results if the miter slot and rip fence are adjusted parallel to the blade. If they are not exactly parallel, your cuts and finished work will be lower in quality, but more important, it increases the risk of kickback. - Page 23 Assembly, “Blade Guard/Splitter. Also, if you ever remove the table in the future, be sure to make note of shim placements and reassemble exactly how it came apart. G7209/10 14'' Table Saw ", repeat Steps 9- Blade tilted to 45° Figure 24.
-
Page 24: Miter Gauge
Figure 26. -22- Rip Fence The rip fence included with your Model G7209/10 14" Table Saw is designed to provide excellent ripping accuracy when properly adjusted. There are three main adjustments to concern yourself with: square, parallelism and clamping pressure. -
Page 25: Blade Alignment
Figure 29, and lock it down. If the fence is not perfectly parallel to the miter slot: Release the clamping mechanism. Remove the fence from the saw and adjust the setscrews on the rear side of the front bracket as shown in Figure 28. Make VERY... - Page 26 Loosen the four trunnion mounting bolts as shown in Figure 30A, and nudge to either the left or right depending on where the blade is hitting the saw. Reattach the table, making sure there is adequate blade clearance through all blade adjustments.
-
Page 27: Operations
Failure to com- ply may result in serious personal injury. Face the table saw and stand to the left of the blade path. With one finger on the START button and one finger on the STOP button, turn the saw on. -
Page 28: Blade Selection
If anything appears abnormal, immediately turn off the saw and fix the problem. If a problem exists that is beyond the scope of this manual, call our service department. If the saw is behaving normally, turn it off and prepare to make a cut according to the instructions outlined in the following sec- tions. -
Page 29: Crosscutting
Inspect the miter gauge. Is it properly set and tight? Move the rip fence completely out of the way. Turn on the saw and allow it to come to full speed. Hold the workpiece firmly against the face of the miter gauge and ease it into the blade. -
Page 30: Ripping
Page 45, or you can purchase the G3445 or G1411 push stick from the Grizzly catalog. Use them to hold the workpiece against the table and fence, and push the -28- workpiece fully past the blade. -
Page 31: Dado Operations
Dado Operations In addition to its ability to rip and crosscut lumber, the table saw is also an invaluable tool for creat- ing a variety of dadoes. These non-through cuts can be created with a regular saw blade or with specially-designed stacking or wobbling dado blades. -
Page 32: Rabbet Operations
-30- Rabbet Operations In addition to its ability to create a variety of dadoes, this table saw can be used to cut L- shaped rabbets. These cuts can be created with a regular saw blade or with specially-designed stacking or wobbling dado blades. See Figure Proper rabbet operation will differ depending on the blade system you choose. - Page 33 ALWAYS replace the blade guard after dadoing is complete. Ensure that the saw is switched off and dis- connected from its power source. Remove the table insert, splitter guard and the regular saw blade from the arbor.
-
Page 34: Maintenance
The V-belts are accessed through the cavity on the right side of the saw. They link the arbor and motor pulleys. To check V-belt tension: Squeeze the center of each V-belt. -
Page 35: V-Belts
Model G7209/10 require no fur- ther lubrication during their lifetime. When they do wear out, replacements can be obtained through the Grizzly Parts Department. Lubricate the areas indicated below every 12 months. Blade angling trunnions. These should be lubricated with 6 or 7 drops of light machine oil. -
Page 36: Closure
Grizzly’s policy of continuous improvement, changes may be made at any time with no oblig- ation on the part of Grizzly. Whenever possible, though, we send manual updates to all owners of a particular tool or machine. Should you receive one, add the new information to this manual and keep it for reference. -
Page 37: Machine Data
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901 GRIZZLY MODEL G7209 14'' TABLE SAW Design Type ... Tilting Arbor Overall Dimensions: With Wings and Fence Rails ...82" W x 47" D x 42" H Table Height ...35... -
Page 38: Machine Data
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901 GRIZZLY MODEL G7210 14'' TABLE SAW Design Type ... Tilting Arbor Overall Dimensions: With Wings and Fence Rails ...82" W x 47" D x 42" H Table Height ...35... -
Page 39: Wiring Diagram
220 VOLT POWER SOURCE Disconnect power from machine before performing electrical service. Failure to do this will result in a shock hazard leading to injury or death. G7209/10 14'' Table Saw SINGLE-PHASE 5L3 NO 13 6T3 NO 14 30 36 MOTOR -37-... - Page 40 Failure to do this will result in a shock hazard leading to injury or death. -38- THREE-PHASE 220 VOLT POWER SOURCE 5L3 NO 13 6T3 NO 14 22 28 MOTOR © G i l I d G7209/10 14'' Table Saw i l I...
- Page 41 128A 128A 330 334 K IC T I- V IC 134A 134B 153A...
- Page 46 FLAT WASHER 8MM P7209140 GUARD SUPPORT (UPPER) PLW04M LOCK WASHER 8MM P7209142 GUARD SUPPORT (LOWER) PW01M FLAT WASHER 8MM PB06M HEX BOLT M8-1.25 X 12 P7209145 FENCE GUIDE RAIL (FRONT) P7209146 FENCE GUIDE RAIL (REAR) P7209147 T BOLT G7209/10 14'' Table Saw...
-
Page 47: Push Stick Pattern
P7209231 NYLON ADJUSTING SCREW P7209233 BAR END CAP P7209254 TOOL BOX W/O ARBOR EXTS P7209255 HARDWARE BAG P7209256 COMPLETE GUARD ASSY G7209/10 14'' Table Saw "-16 "-16 X 1 3/4 PART # DESCRIPTION P7209301 HANDLE PW04M FLAT WASHER 10MM P7209303... -
Page 48: Troubleshooting Guide
Remove hand wheel and adjust bullets. Inspect roll pins and setscrews in the worm gear. Tighten if necessary. Disconnect power to the machine when perform- ing any maintenance or repairs. Failure to do this may result in serious personal injury. G7209/10 14'' Table Saw... - Page 49 G7209/10 14'' Table Saw -47-...
-
Page 50: Warranty And Returns
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance. -
Page 51: Warranty Card
Do you think your purchase represents good value? ___Yes Would you recommend Grizzly Industrial to a friend? ___Yes Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than three times. ___Yes Comments:_________________________________________________... - Page 52 FOLD ALONG DOTTED LINE FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: Name_______________________________ Street_______________________________ City______________State______Zip______ GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 TAPE ALONG EDGES--PLEASE DO NOT STAPLE Place Stamp Here...
