Power Supply Cable; Figure 9: Power Supply Cable - Wavecom Technical data M1306B User Manual

Pin # Signal
(CCITT / EIA)
11 CCTS/CT106
12 CRTS/CT105
13 CRI/CT125
14 RESET
15 CSPK2N

3.2.2 Power supply cable

Connector Molex
Micro-Fit 3.0
Connector
Side View
Component
Micro-Fit connector
4-pin
Cable
Wire
© 2004
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement.
I/O I/O type
O STANDARD
RS232
I STANDARD
RS232
O STANDARD
RS232
I/O Schmitt
O Analog
Black wire
Red wire

Figure 9: Power supply cable

Part number: MOLEX 43025-0400
Cable length: ∼1.5 m
Core: tinned copper 24 x 0.2 mm
Section: 0.75 mm
All rights reserved
Wavecom Confidential & Proprietary Information
WM_PRJ_M13_UGD_001 - 001
Description
RS232
Clear To Send
RS232
Request To Send
RS232
Ring Indicator
Modem reset
Speaker
negative line
Fuse 2.5 A / 250 V
(5 x 20 mm)
Characteristics
2
20th July 2004
Comment
Active low
Stripped wire
tinned over 5 mm
Page: 19 / 55
