8.2.6.3
External antenna
The external antenna is connected to the modem via the SMA connector.
The external antenna must fulfill the characteristics listed in the table below.
Antenna frequency range
Impedance
DC impedance
Gain (antenna + cable)
VSWR (antenna + cable)
Note: refer to chapter 10 for recommended antenna.
© 2004
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement.
Table 17: External antenna characteristics
Dual-band GSM 900/DCS 1800 MHz
50 Ohms nominal
0 Ohm
0 dBi
-10 dB
Wavecom Confidential & Proprietary Information
WM_PRJ_M13_UGD_001 - 001
All rights reserved
20th July 2004
Page: 50 / 55
