Remote Management

This option allows the user to enable Remote management on the module. The
remote management feature is designed to work only on the remote module of
the Local/Remote pair. With Remote management enabled, the user can easily
perform the following:
• Test the line integrity of the remote copper port.
• Use the Local unit to configure all SNMP-configurable features for both units.
• Use the Local unit to download firmware for both units.
Refer to the Module LED Functions section for more information.
When the user enables the Remote management feature on the remote module, it is
necessary to disable SNMP-management on the chassis in which the remote unit is
installed (i.e. turn the iMediaChassis enter chassis SNMP switch off, or do not install an
SNMP Management module in either an iMediaChassis or iMcV series chassis.
Monitor/Boost Mode
This option allows the user to boost the UTP receive signal (i.e internal linear gain
boost). This helps the UTP receiver to compensate for line loss.
NRZ (Non-Return-to-Zero)
This option allows the user to enable or disable the NRZ mode.
There are currently no applications that use any other settings than AMI encoding and
NRZ disabled (Passive mode). Enabling NRZ can result in data corruption.
Enabling NRZ terminates the line coding on the copper line. This forces the module
to send raw data to the fiber line without line code information.
NOTE
NOTE
9
