IMC Networks iMcV-T1 Operation Manual page 11

Jitter Attenuator Select
S3-1: ON
S3-1: OFF
Remote Management
S3-2: ON
S3-2: OFF
Loopback Selection iVIEW
S3-3: ON
S3-3: OFF
S3-3: ON
S3-3: OFF
Monitor/Boost Mode
S3-5: ON
S3-5: OFF
S3-5: ON
S3-5: OFF
NRZ Selection iVIEW
S3-7: ON
S3-7: OFF
Fiber Type
S3-8: Factory Configured
S3-9: Factory Configured
S3-10: Factory Configured DO NOT CHANGE
DIP Switch Table
2
All iView enabled switches are overridden by management software.
Switch Settings for Switch S3
Place Jitter Attenuator on RCV Side
Place Jitter Attenuator on XMT Side
Remote Management Enabled (only at the REMOTE end)
Remote Management Disabled (only at the LOCAL end)
2
S3-4: ON None
S3-4: ON Local Loopback
S3-4: OFF Analog Loopback
S3-4: OFF Remote Loopback
S3-6: ON Normal Operation (No Boost)
S3-6 ON 20 dB
S3-6 OFF 26 dB
S3-6 OFF 32 dB
2
Disable NRZ (Required for Passive Mode)
Enable NRZ (Line Terminating Mode)
DO NOT CHANGE
DO NOT CHANGE
11
default
default
2
iVIEW
default
2
iVIEW
2
iVIEW
2
iVIEW
default
2
iVIEW
default
2
iVIEW
