The iMcV-T1/E1/J1 Repeater modules are delivered pre-configured for standard T1
operation in Passive mode. To enable remote management, the user must move DIP
Switch S2-2 to the "ON" position on the Remote module (refer to the DIP Switch diagram
and table).
Managed Modules
To manage iMcV-T1/E1/J1 Repeater modules, an SNMP agent must be present; the
iMediaChassis requires an SNMP management module. For a managed
environment, first manually configure all of the desired DIP Switch selectable features
to match what will be configured through the SNMP Management Module.
Use the Graphical User Interface (GUI) to enable features by using the iView
management software. In a managed chassis, the software settings take priority over
the SNMP enabled feature DIP Switch settings. Make sure that the software settings
match the desired configuration requirements for the installation.
iView² Management Software
iView² is the IMC Networks management software designed specifically for the IMC
Networks "iMcV" family of modules. It features a GUI and gives network managers
the ability to monitor and control the manageable IMC Networks products.
iView² is available in several versions and can also function as a snap-in module for
HP OpenView Network Node Manager and other third party SNMP Management
software. For assistance in selecting the right version of iView² for your operating
system, please visit:
http://www.imcnetworks.com/products/iview2.cfm
2
iView supports the following platforms:
•
Windows NT
•
Windows 2000
•
Windows XP
•
Windows Vista
In addition, there are Java versions of iView² for any Java-capable operating systems
such as Linux.
Please see the SNMP Management Module for software configuration options.
IMC Networks' iView
NOTE
NOTE
2
software is available for downloading from the web site:
www.imcnetworks.com.
