MODEL G1079R 16" DRUM SANDER W/ RUBBER

Product Dimensions:

Weight.............................................................................................................................................................. 283 lbs.
Length/Width/Height................................................................................................................. 36-1/2 x 27 x 42-1/2 in.
Foot Print (Length/Width)............................................................................................................................. 32 x 29 in.

Shipping Dimensions:

Type......................................................................................................................................................... Not Available
Content.................................................................................................................................................... Not Available
Weight.............................................................................................................................................................. 304 lbs.
Length/Width/Height........................................................................................................................... N/A x N/A x N/A

Electrical:

Switch...................................................................................................................On/Off Toggle with Safety Lock Tab
Switch Voltage...................................................................................................................................................... 220V
Cord Length............................................................................................................................................................. 8 ft
Cord Gauge....................................................................................................................................................10 gauge
Minimum Circuit Size........................................................................................................................................ 15 amp
Plug Included............................................................................................................................................................ No

Motors:

Sanding
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................2 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................ Single
Amps.............................................................................................................................................................12A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer .................................................................................................................... Single V-Belt Drive
Bearings.......................................................................................................................... Sealed and Lubricated
Conveyor
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower..............................................................................................................................................1/4 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................ Single
Amps...............................................................................................................................................................1A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ................................................................................................................................Chain Drive
Bearings.......................................................................................................................... Sealed and Lubricated
The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Model G1079R
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
MACHINE DATA
CONVEYOR
SHEET
PAGE 1 OF 2
