MODEL G1071Z
1 HP VARIABLE-SPEED
OSCILLATING SPINDLE SANDER
MANUAL INSERT
For Machines Mfd. Since 06/24
and Owner's Manual Revised 05/19
The Model G1071Z is the same machine as the Model G1071 except for the power controls, spindle speed,
power supply requirements, and wiring. Except for the differences noted in this insert, all other content in
the Model G1071 owner's manual applies to this machine.
: To reduce the risk of serious injury, you MUST read and understand this insert—and
the entire Model G1071 manual—BEFORE assembling, installing, or operating this machine!
If you have any further questions about this manual insert or the differences between the Model G1071Z and
the Model G1071, contact our Technical Support at (570) 546-9663 or email techsupport@grizzly.com.
COPYRIGHT © MAY, 2024 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#CS23187 PRINTED IN TAIWAN
***Keep for Future Reference***
