Abit AX5 Instruction Booklet page 79

Quick Installation
Installing PS2 Mouse:
cable that comes with the hardware to the connector on the mainboard. Install
the bracket located on the other end of the computer case. When you buy a
Mouse, it has to be a PS/2 Mouse for it to be connected to this port.
Attach the bracket of Parallel Port, Serial Port and PS2 Mouse on the
computer case.
Installing CPU Fan Power connector:
orientation. Connect the three-threads CPU Fan power cable to the Fan
connector on the mainboard.
AX5/PX5
Pin number
1
2
3
TX5
Pin number
1
2
3
Adjusting other jumpers:
functions or are not to be adjusted in normal operation. Adjust them according
to the following recommendations.
CCMOS ¡G Put jumper on pin 1 and pin 2.
BIOS Setup:
steps described above and completed the installation, when you power the
computer on, you will see the following message displayed:
Press immediately Del key to enter BIOS Setup. Select Load Setup Defaults,
than enter CPU Soft Menu to set CPU parameters.
Mouse - Connect the six-threads PS/2 Mouse
FAN1
Name of the signal or signification
Ground
+12V
Ground
FAN1/FAN2/FAN3
Name of the signal or signification
Sensor
+12V
Control on/off
Some jumpers are reserved for future
Parameters and CPU settings After you have followed the
PRESS DEL TO ENTER SETUP
FAN1 - There is a specific
A-5
