Abit AX5 Instruction Booklet page 77

Quick Installation
Installing HDD LED connector:
PN1 - There is a specific orientation for pin 7 and pin 8. Connect the two-
threads IDE LED connector to the connector on mainboard.
Pin number
7
8
Installing Suspend and Power ON/OFF switch connector:
Watch the pin position and the orientation
PN1 - There is a specific orientation for pin 10 and pin 11. Connect the two-
threads suspend switch connector of the computer case to correct pins of
connector on the mainboard. You can ignore this connector since most of
computer cases do not support this feature (the mainboard itself supports it).
Pin number
10
11
Sleep LED connector:
Connect the two-threads Green LED connector on the mainboard.
Pin number
9
10
Installing speaker connector:
for pin 4 to pin 7. Connect the four-threads speaker cable to the PN2 connector
pins on the mainboard
Pin number
4
5
6
7
Name of the signal or signification
HDD LED signal ¡i LED Cathode ¡j
HDD LED signal ¡i LED Anode ¡j
Name of the signal or signification
Power on/off
Ground
PN2 - This connector has a specific orientation.
Name of the signal or signification
LED' s Cathode
LED' s Anode
.
Name of the signal or signification
+5VDC
Ground
Ground
Sound Signal
Watch the pin position and the
orientation
PN2 - There is no specific orientation
A-3
