Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G5850Z 20" PROFESSIONAL PLANER W/ 5 HP

Product Dimensions:

Weight.............................................................................................................................................................. 940 lbs.
Length/Width/Height................................................................................................................. 38 x 40-1/2 x 42-1/4 in.
Foot Print (Length/Width)................................................................................................................. 26-1/2 x 24-1/2 in.

Shipping Dimensions:

Type........................................................................................................................................................... Wood Crate
Content............................................................................................................................................................ Machine
Weight............................................................................................................................................................ 1010 lbs.
Length/Width/Height............................................................................................................................. 41 x 43 x 45 in.

Electrical:

Switch........................................................................................................ Magnetic with Thermal Overload Protector
Switch Voltage...................................................................................................................................................... 220V
Cord Length............................................................................................................................................................ 7 ft.
Cord Gauge....................................................................................................................................................10 gauge
Minimum Circuit Size........................................................................................................................................ 30 amp
Plug Included............................................................................................................................................................ No

Motors:

Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................5 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................ Single
Amps.............................................................................................................................................................25A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer .......................................................................................................................Twin V-Belt Drive
Bearings....................................................................................................................... Shielded and Lubricated
Feed
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................2 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................ Single
Amps.............................................................................................................................................................12A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ......................................................................................................Variable Split Pulley System
Bearings....................................................................................................................... Shielded and Lubricated
The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Model G5850Z
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
MACHINE DATA
SINGLE-PHASE MOTOR
SHEET
PAGE 1 OF 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G5850 Z and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grizzly G5850 Z

Summary of Contents for Grizzly G5850 Z

  • Page 1: Machine Data Sheet

    Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901 MODEL G5850Z 20" PROFESSIONAL PLANER W/ 5 HP Product Dimensions: Weight... 940 lbs. Length/Width/Height... 38 x 40-1/2 x 42-1/4 in. Foot Print (Length/Width)... 26-1/2 x 24-1/2 in.
  • Page 2 Main Specifications: Operation Info Max. Cut Width...20 in. Max. Cut Height...7 in. Min. Stock Length...8 in. Min. Stock Width... 1/4 in. Max. Stock Thickness... 7-3/4 in. No. Of Cuts Per Inch...67 - 102 No. Of Cuts Per Minute... 20800 Cutterhead Speed... 5200 RPM Planing Feed Rate...17 - 26 FPM Max.
  • Page 3 Features: Segmented Chip Breaker Variable Feed Speed Lever Adjustable Bed Rollers 5" Dust Port Precision Ground Cast Iron Bed Cutterhead Ball Bearings Include Grease Fittings Heavy Duty Cast Iron Construction Throughout Board Return Rollers Dust Covers Protect Vertical Support Columns and Leadscrews Handwheel Depth Adjustment The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
