W a r n i n g s
1
Warnings
Important Notice: FCC Class A Notification & International Standards Compliance
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at their own expense.
If in a residential setting you are encountering interference with TV and Radio reception
while NOT in inverter mode, then: simply disconnect AC power from the TruePower
Combi Charger/Inverter to confirm if this unit is causing the interference, if so explore
the following options to minimize interference:
1) Make sure your AC connections include a proper Ground connection
2) Reposition your receiving antenna
3) Purchase a separate AC line filter
4) Relocate the affected appliance so it is further separated from the
TruePower Combi Charger/Inverter
This equipment has been designed to comply with:
American Boat & Yacht Council A-31 Battery Chargers and Inverters
FCC Class A
Underwriters Laboratories: Standard 1236 Battery Chargers for Charging Engine Starter Batteries
Standard 458 Power Converter/Inverter Systems for Land Vehicles and Marine Crafts
230VAC Models
DANGER
HIGH VOLTAGE
AVOID SERIOUS INJURY OR DEATH FROM ELECTRICAL SHOCK.
BEFORE PERFORMING ANY ELECTRICAL WORK TURN OFF AC POWER SUPPLY
DANGER
EXPLOSION HAZARD
AVOID SERIOUS INJURY OR DEATH
MAKE CONNECTIONS IN AN ATMOSPHERE FREE OF EXPLOSIVE FUMES
WARNING
LOW VOLTAGE
AVOID SERIOUS INJURY FROM ELECTRICAL BURNS AND SPARKS.
BEFORE PERFORMING ANY ELECTRICAL WORK DISCONNECT ANY DC POWER
SUPPLY FROM UNIT
Appendix 2 Technical Specifications
AC PASS-THROUGH SPECIFICATIONS
TruePower Combi 1000 QS
Input Voltage
Low Voltage Disconnect
Low Voltage Reconnect
High Voltage Disconnect
High Voltage Reconnect
Nominal Input Frequency
Transfer Switch Rating
Pass Through Without Battery
Maximum Pass Through Overload
DC INPUT AMPERAGE
TruePower Combi - Combination Charger / Inverter with Automatic Crossover
(110 VAC 60 Hz.) 12 Volt QS Models
01012 True Power Combi - 12V 40A/1000W Combination Charger/Inverter - 110Vac 60hz
01512 True Power Combi - 12V 40A/1500W Combination Charger/Inverter - 110Vac 60hz
02412 True Power Combi - 12V 40A/2500W Combination Charger/Inverter - 110Vac 60hz
(110 VAC 60 Hz.) 24 Volt QS Models
01524 True Power Combi - 24V 20A/1500W Combination Charger/Inverter - 110Vac 60hz
02424 True Power Combi - 12V 40A/1500W Combination Charger/Inverter - 110Vac 60hz
(230 VAC 50 Hz.) 12 Volt QS Models
01513 True Power Combi - 12V 40A/1500W Combination Charger/Inverter - 230Vac 50hz
02423 True Power Combi - 12V 50A/2500W Combination Charger/Inverter - 230Vac 50hz
(230 VAC 50 Hz.) 24 Volt QS Models
01525 True Power Combi - 24V 20A/1500W Combination Charger/Inverter - 230Vac 50hz
02425 True Power Combi - 24V 25A/2500W Combination Charger/Inverter - 230Vac 50hz
Pure Sine Wave Combination Charger / Inverter with Automatic Crossover
(110 VAC 60 Hz.) PS Models
02012 True Power Combi - 12V 70A/2000W Combination Charger/Inverter - 110Vac 60hz
02024 True Power Combi - 24V 35A/2000W Combination Charger/Inverter - 230Vac 50hz
(230 VAC 50 Hz.) PS Models
02013 True Power Combi - 12V 70A/1500W Combination Charger/Inverter - 230Vac 50hz
02025 True Power Combi - 24V 35A/2000W Combination Charger/Inverter - 230Vac 50hz
A p p e n d i x 2
1500 QS 2500 QS 2000 PS
120Vac 110/230VAC
85Vac ± 4% 85/184Vac ± 4%
95Vac ± 4% 95/194Vac ± 4%
132Vac ± 4% 136/253Vac ± 4%
127Vac ± 4% 132/243Vac ± 4%
50Hz / 60Hz (Auto Detection)
30A
Yes
30A
DC Voltage DC Amps
(range) (max continuous)
10.5 - 15Vdc Up to 100A
10.5 - 15Vdc Up to 150A
10.5 - 15Vdc Up to 250A
21.5 - 29.5Vdc Up to 75A
21.5 - 29.5Vdc Up to 125A
10.5 - 15Vdc Up to 150A
10.5 - 15Vdc Up to 250A
21.5 - 29.5Vdc Up to 75A
21.5 - 29.5Vdc Up to 125A
DC Voltage DC Amps
(range) (max continuous)
10.5 - 15Vdc Up to 200A
21.5 - 29.5Vdc Up to 100A
10.5 - 15Vdc Up to 200A
21.5 - 29.5Vdc Up to 100A
