Owner's
Manual
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following number :
Model#: A150-200
STAMINA PRODUCTS
MADE IN CHINA
©
2011 Stamina Products, Inc.
2011, 06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVARI fitness and is the answer not in the manual?

Questions and answers

Summary of Contents for Stamina AVARI fitness

  • Page 1 CAUTION: Weight on this product should not exceed 250 lbs. This Product is Distributed Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N. Alliance, Springfield, MO 65803 Customer Service © 2011 Stamina Products, Inc. 1 (800) 375-7520 2011, 06 www.staminaproducts.com...
  • Page 2: Table Of Contents

    Meijer.com TABLE OF CONTENTS Safety Instructions ........2 Storage ............14 Before You Begin ........4 Conditioning Guidelines ......15 Equipment Warning, Caution & Notice Labels ... 5 Warm-Up and Cool-Down ......16 Hardware Identification Chart ....6 Warranty ............. 17 Assembly Instructions ........
  • Page 3: Customer Service

    Monday - Thursday, 7:30 A.M. - 5:00 P.M., Central Time. Friday, 8:00 A.M. - 3:00 P.M., Central Time. ONLINE TELEPHONE MAIL CUSTOMER SERVICE CUSTOMER SERVICE CUSTOMER SERVICE STAMINA PRODUCTS, INC. customerservice@staminaproducts.com Tel: 1 (800) 375-7520 Fax: (417) 889-8064 ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071...
  • Page 4: Before You Begin

    Meijer.com BEFORE YOU BEGIN Thank you for choosing the AVARI® Recumbent Although Stamina constructs its products with Bike. We take great pride in producing this quality the finest materials and uses the highest standards product and hope it will provide many hours of of manufacturing and quality control, there can quality exercise to make you feel better, look sometimes be missing parts or incorrectly sized...
  • Page 5: Equipment Warning, Caution & Notice Labels

    Meijer.com EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the AVARI® Recumbent Bike. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels. Label is larger than actual size WARNING LABEL(71)
  • Page 6: Hardware Identification Chart

    Meijer.com HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.
  • Page 7: Assembly Instructions

    Meijer.com ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
  • Page 8 Meijer.com ASSEMBLY INSTRUCTIONS STEP 4 NOTE: Install the HEX BOLTS(M6x1x37mm)(50) as shown in the illustration below. This allows the head of the bolts to fit inside the hex shape holes in the SEAT FRAMES(5, 6). Attach the RIGHT HANDRAIL(8) to the RIGHT SEAT FRAME(6) with HEX BOLTS(M6x1x37mm)(50), ARC WASHERS(M6)(64), LOCK WASHERS(M6)(66), and ACORN NUTS(M6x1)(60).
  • Page 9 Meijer.com ASSEMBLY INSTRUCTIONS STEP 6: Refer to illustration A. Pull the ends of the TENSION CABLE(24) and SENSOR WIRE(28) out of the FRONT FRAME(1). There are two straps attached inside of the METER POST(26) to assist when pulling the SENSOR WIRE(28) and the TENSION CABLE(24) through the METER POST(26). Tie STRAP A to the plug end of the SENSOR WIRE(28).
  • Page 10 Meijer.com ASSEMBLY INSTRUCTIONS STEP 8 NOTE: The RIGHT PEDAL(35) has R stamped on the end of the pedal shaft. The RIGHT PEDAL(35) has right hand threads and is tightened by turning clockwise. The LEFT PEDAL(34) has L stamped on the end of the pedal shaft. The LEFT PEDAL(34) has left hand threads and is tightened by turning counter clockwise.
  • Page 11: Set Up Instructions

    Meijer.com SET UP INSTRUCTIONS Place the AVARI® Recumbent Bike in the area where it will be used. It is recommended that the AVARI® Recumbent Bike be placed on an equipment mat. The AVARI® Recumbent Bike is approximately 61.8 inches long (max.) x 27.5 inches wide x 36 inches tall. (These dimensions may vary up to one inch.) An area 4 feet wide x 7 feet long is required for safe operation of the AVARI®...
  • Page 12: Operational Instructions

    Meijer.com OPERATIONAL INSTRUCTIONS SEAT ADJUSTMENT Proper seat adjustment is important. There are seven adjustment holes in the REAR FRAME(3). These adjustment holes allow users to adjust the position of the seat for efficient exercise. 1. Unscrew to remove the ADJUSTMENT KNOB(37) from the FRONT FRAME(1). Slide the REAR FRAME (3) to adjust the seat.
  • Page 13 Meijer.com OPERATIONAL INSTRUCTIONS USING THE FITNESS METER POWER ON : Pedal movement or press the button. POWER OFF : Automatic shut off after four minutes of inactivity. MODE/RESET BUTTON: Press to select display functions, include SCAN, TIME, SPEED, DISTANCE, and CALORIES. Press and hold for three seconds to reset all functions to zero.
  • Page 14: Maintenance

    3. Verify that all nuts and bolts are present and properly tightened. Replace missing nuts and bolts. Tighten loose nuts and bolts. 4. Verify that the WARNING LABEL(71) is in place and easy to read. Call Stamina Products immediately at 1-800-375-7520 for a replacement WARNING LABEL(71) if it is missing or damaged.
  • Page 15: Conditioning Guidelines

    Meijer.com CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.
  • Page 16: Warm-Up And Cool-Down

    Meijer.com WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place Stretching Stretching while your muscles are warm after a proper warm-up and again after your...
  • Page 17: Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071, or email us at customerservice@staminaproducts.com, or call us at 1-800-375-7520.
  • Page 18: Product Parts Drawing

    Meijer.com PRODUCT PARTS DRAWING FRONT Strap A Strap B BACK...
  • Page 19: Parts List

    Meijer.com PARTS LIST PART# PART NAME Front Frame Front Stabilizer Rear Frame Rear Stabilizer Left Seat Frame Right Seat Frame Left Handrail Right Handrail Crank Bearing Housing Ball Bearing Inside Bearing Collar Outside Bearing Collar Bearing Washer Bearing Snap Washer Bearing Nut Pulley V-Ribbed Belt...
  • Page 20 Meijer.com PARTS LIST PART# PART NAME Bolt, Button Head (M8 x 1.25 x 15mm) Bolt, Button Head (M10 x 1.5 x 122mm) Bolt, Hex Head (M6 x 1 x 37mm) Bolt, Round Head (M6 x 1 x 35mm) Bolt, Flat Head (M10 x 1.5 x 20mm) Bolt, Flat Head (M10 x 1.5 x 35mm) Screw, Round Head (M5 x 0.8 x 15mm) Screw, Flat Head (M5 x 0.8 x 10mm)
  • Page 21: Notes

    Meijer.com NOTES...
  • Page 22: Fax/Mail Ordering Form

    ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071 Would you like to recieve email information or special offers from Stamina Products? Register at contact.staminaproducts.com TO REGISTER YOUR PRODUCT TO REGISTER YOUR PRODUCT To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your...

This manual is also suitable for:

Avari fitness recumbent bikeA150-200
