Stamina Fusion 7250 Owner's Manual

Magnetic exercise bike
Hide thumbs Also See for Fusion 7250:
Table of Contents

Advertisement

Quick Links

CAUTION:
Weight on this product should not exceed 300 lbs.
2010, 01
This Product is Produced Exclusively by
2040 N. Alliance, Springfield, MO 65803
Customer Service
1 (800) 375-7520
www.staminaproducts.com
Owner's
Manual
WARNING
Exercise can present a health
risk. Consult a physician
before beginning any exercise
program with this equipment.
If you feel faint or dizzy,
immediately discontinue use
of this equipment. Serious
bodily injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur if
all instructions are not followed.
Keep others and pets away
from equipment when in use.
Always make sure all bolts and
nuts are securely tightened
prior to each use. Follow all
safety instructions in this
manual.
When calling for parts or
service, please specify the
following number :
Model#: 15-7250A
STAMINA PRODUCTS
MADE IN CHINA
Product May Vary Slightly
From Pictured.
2010 Stamina Products, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fusion 7250 and is the answer not in the manual?

Questions and answers

Adrian denise lee
March 22, 2025

Where does the adaptor go

0
2 comments:
Mr. Anderson
March 22, 2025

The adapter (105) plugs into the socket of the power wire (28) located on the front of the bike. Then, the adapter (105) is plugged into an electrical outlet.

This answer is automatically generated

0
Adrian denise lee
March 22, 2025

@Mr. Anderson

0
Bill
June 5, 2025

Why won’t the monitor work?

0

Subscribe to Our Youtube Channel

Related Manuals for Stamina Fusion 7250

Summary of Contents for Stamina Fusion 7250

  • Page 1 CAUTION: Weight on this product should not exceed 300 lbs. Product May Vary Slightly From Pictured. This Product is Produced Exclusively by 2040 N. Alliance, Springfield, MO 65803 Customer Service 1 (800) 375-7520 www.staminaproducts.com 2010, 01 2010 Stamina Products, Inc.

  • Page 2: Table Of Contents

    We recommend that two people be available for assembly of this product. Keep children away from the Magnetic Fusion 7250 Bike. Do not allow children to use or play on the Magnetic Fusion 7250 Bike. Keep children and pets away from the Magnetic Fusion 7250 Bike when it is in use.

  • Page 3: Customer Service

    Magnetic Fusion 7250 Bike To help you get started, we have pre-assembled most of your Magnetic Fusion 7250 Bike at the factory with the exception of those few parts left unassembled for shipping purposes. Simply follow the few assembly instructions set forth in this manual.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the Magnetic Fusion 7250 Although Stamina constructs its products with the Bike. We take great pride in producing this quality finest materials and uses the highest standards of product and hope it will provide many hours of quality...

  • Page 5: Equipment Warning & Notice Labels

    EQUIPMENT WARNING & NOTICE LABELS This chart is provided to help identify the warning & notice labels on the Magnetic Fusion 7250 Bike. Please take a moment to familiarize yourself with all of the warning & notice labels. Label is larger than actual size...

  • Page 6: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
  • Page 8 ASSEMBLY INSTRUCTIONS Rear Frame(5), is inside of Rear Covers(65, 66) STEP 3 Attach the REAR STABILIZER(6) to the REAR FRAME(5) with BUTTON HEAD BOLTS(M8x1.25x53mm) (72), LOCK WASHERS(M8)(100), and WASHERS(M8)(103). STEP 4 Slide the FOOT CAPS(63) onto both ends of the REAR STABILIZER(6) so they fit over the edges of the LEFT and RIGHT REAR COVERS(65, 66) and secure with ROUND HEAD SCREWS(M4x0.7x15mm)(85).
  • Page 9 ASSEMBLY INSTRUCTIONS Use this set of attachment holes for assembly. Socket of Pulse Extension Wire(43) STEP 6 Attach the SEAT FRAME(114) to the SEAT CARRIAGE(7) with BUTTON HEAD BOLTS(M10x1.5x200mm) (76), WASHERS(M10)(99), LOCK WASHERS(M10)(101), and ACORN NUTS(M10x1.5)(97). NOTE: The four attachment holes on each side of the SEAT FRAME(114) allow the SEAT FRAME(114) to be attached in two different positions: one to position you closer to the HANDLEBAR(4) and one further away.
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 9 Attach the SEAT(59) and BACK CUSHION(60) to the SEAT FRAME(114) with ROUND HEAD BOLTS (M6x1x38mm)(82). STEP 10 Refer to the inset drawing. Press the NUT CAPS(M10)(53) onto the NYLOCK NUTS(M10x1.5)(95) on both sides of the SEAT CARRIAGE(7).
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 11 NOTE: The RIGHT PEDAL(41) has R stamped on the end of the pedal shaft. The RIGHT PEDAL(41) has right hand threads and is tightened by turning clockwise. The LEFT PEDAL(39) has L stamped on the end of the pedal shaft. The LEFT PEDAL(39) has left hand threads and is tightened by turning counterclockwise.
  • Page 12 ASSEMBLY INSTRUCTIONS Socket of Power Wire(28) STEP 13 Refer to illustration A. Run the CONNECTION WIRE(26) through the hole in the plate on the HANDLEBAR(4). Attach the HANDLEBAR(4) to the UPRIGHT(3) with BUTTON HEAD BOLT(M8x1.25x40mm)(70) and FLAT HEAD SCREWS(M6x1x12mm)(78). STEP 14 Plug the CONNECTION WIRE(26) into the EXTENSION WIRE on the COMPUTER(27).

  • Page 13: Set Up Instructions

    24 3/8 inches wide x 50 3/8 inches tall (max.). (These dimensions may vary up to one inch.) An area 4 feet wide x 7 feet long is required for safe operation of the Magnetic Fusion 7250 Bike. Make sure that adequate space is available for access to and passage around the Magnetic Fusion 7250 Bike.

  • Page 14: Operational Instructions

    LOAD ADJUSTMENT The load level of Magnetic Fusion 7250 Bike can be changed at any time during your workout. Use the UP and DOWN buttons on the COMPUTER(27) to increase or decrease your intensity level. Press the UP...

  • Page 15: Computer Instructions

    COMPUTER INSTRUCTIONS Your Magnetic Fusion 7250 Bike utilizes a magnetic braking system to create resistance for your workout. You control the amount and pattern of this resistance by means of the advanced computer console mounted at the center of the handlebar. We recommend that you use this computer console to vary your workout from session to session and note your progress toward your fitness goals.
  • Page 16 COMPUTER INSTRUCTIONS PROGRAM NUMBER HEART RATE CONTROL PROGRAMS TIME CALORIE SPEED AGE / TARGET H.R. DISTANCE HEART RATE HEART SYMBOL PROGRAM PROFILE LCD DISPLAY INSTRUCTIONS PROGRAM: Displays the selected program during exercise, from P1 to P12. TIME: Displays the time. Counts upward from one second to 99:59 minutes. Counts down from preset value.
  • Page 17 COMPUTER INSTRUCTIONS PROGRAM DESCRIPTIONS This computer contains 12 different programs. You can preset the program time and the computer will divide the time chosen into 10 intervals. If you do not set the program time in advance, the computer will default to a 30 minute workout time.
  • Page 18 COMPUTER INSTRUCTIONS HEART RATE CONTROL PROGRAMS: P11 and P12 are preset automatic Heart Rate Control Programs. You must input your age and always hold the pulse sensors on the HANDRAIL(9) with both hands when using the Heart Rate Control Programs. P11 is programmed to use 60% of your maximum heart rate as your target heart rate zone workout goal, and P12 is programmed to use 85% of your maximum heart rate as your target heart rate zone workout goal;...
  • Page 19 The computer will shut off automatically after 4 minutes of inactivity, and the function values, DISTANCE and CALORIE, will be kept. POWER SOURCE: The computer uses the ADAPTER(105) as a power source. Use the Magnetic Fusion 7250 Bike with the adapter plugged into an electrical outlet.

  • Page 20: Storage

    55 3/4 inches long x 24 3/8 inches wide x 50 3/8 inches tall (max.). These dimensions will vary. Please measure your Magnetic Fusion 7250 Bike if exact dimensions are needed. To move the Magnetic Fusion 7250 Bike, lift the REAR STABILIZER(6) and the bike will roll on the WHEELS(118) on the FRONT STABILIZER(117).

  • Page 21: Conditioning Guidelines

    CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.

  • Page 22: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place Stretching Stretching while your muscles are warm after a proper warm-up and again after your strength...

  • Page 23: Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071, or email us at customerservice@staminaproducts.com, or call us at 1-800-375-7520.

  • Page 24: Product Parts Drawing

    PRODUCT PARTS DRAWING FRONT BACK...

  • Page 25: Parts List

    PARTS LIST PART# PART NAME Front Frame Upright Handlebar Rear Frame Rear Stabilizer Seat Carriage Handrail Pulley and Axle Bearing (6003Z) Bearing Washer (M17) C Ring (17mm) V-Ribbed Belt Idler Arm Idler Wheel Idler Wheel Spacer Tension Spring Magnetic Unit Lock Washer (3/8") Thin Nut (3/8"...
  • Page 26 PARTS LIST PART# PART NAME Foot Cap Foot Stand Left Rear Cover Right Rear Cover Cover Plug Stand Screw, Round Head (M4 x 50mm) Bolt, Button Head (M8 x 1.25 x 40mm) Bolt, Button Head (M8 x 1.25 x 45mm) Bolt, Button Head (M8 x 1.25 x 53mm) Bolt, Button Head (M10 x 1.5 x 15mm) Bolt, Button Head (M10 x 1.5 x 20mm)

  • Page 27: Fax/Mail Ordering Form

    FAX/MAIL ORDERING FORM Please do not return the product. For your convenience, Stamina's Customer Service Department can be reached by email at customerservice@staminaproducts.com or toll free at 1-800-375-7520 (in the U.S.). Should a part be missing or a defective part found, please call us from 7:30 A.M. to 5:00 P.M. Central Time, Monday through Thursday and 8:00 A.M.
