Anchor Voyager Owner's Manual

Portable sound system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version

Troubleshooting Guide

Having trouble with the sound system?
Condition
Possible Solution
No sound
• turn
(power LED not lit):
• fully charge battery
Charge indicator doesn't light:
• plug charger in fully
No sound (power LED lights):
• check for output from source
• make sure all cables are completely plugged in
• turn up volume control of input used
Shortened battery life:
• charge battery fully; if battery life continues to
deteriorate, contact Anchor customer service
• reduce volume to eliminate distortion
• make sure external speaker impedance > 4Ω
Distorted sound:
• turn down system volume control
• reduce source output level
Excessive hum or noise:
• use shielded cables
• use balanced microphone
Having trouble with the wireless system?
Condition
Possible Solution
No sound
• set
(TX ON indicator lights):
MUTE
• turn up wireless (Mic 2) volume control
• make sure mic is plugged into bodypack
transmitter
• unplug mic from Mic 2 input
No sound (TX ON indicator off): • turn Voyager
• make sure transmitter power switch is
• set receiver and transmitter to same channel
• replace battery in transmitter
ANCHOR Audio, Inc. (310) 784-2300
100-0054-000 / Revision C, 07/97
switch
POWER
ON
(Wireless models only.)
switch to
(handheld mic only)
ON
switch
POWER
ON
ON
Voyager
Owner
s Manual
'
