Having trouble with the PA system?
Condition
Possible Cause
No sound (power LED not lit):
• power switch OFF
• batteries fully discharged (LED flashes briefly)
Charge indicator doesn't light:
• confirm proper charger; replace if necessary
No sound (power LED lights):
• no output from source
• input cable unplugged
• input volume control low or off
Shortened battery life:
• short in external speaker cable or speaker
• total external speaker impedance < 8Ω
• batteries not fully charged
• batteries need replacement
Distorted sound:
• poor connection on input cable
• input signal too strong
Excessive hum or noise:
• input cable not shielded
Having trouble with the wireless system?
Condition
Possible Cause
No sound (RX ON indicator lights): • wireless volume control low or off
• no mic plugged into belt-pack transmitter
No sound (RX ON indicator off):
• sound system not turned on
• transmitter power switch turned off
• low battery or no battery in transmitter
ANCHOR Audio, Inc. (310) 784-2300
100-0058-000 / Revision D - 05/03

TROUBLESHOOTING GUIDE

MEGA-6000
MEGA-6000U1
MEGA-6000U2
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MegaVox Pro MEGA-6000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anchor MegaVox Pro MEGA-6000

Summary of Contents for Anchor MegaVox Pro MEGA-6000

  • Page 1: Troubleshooting Guide

    No sound (RX ON indicator off): • sound system not turned on • transmitter power switch turned off • low battery or no battery in transmitter MEGA-6000U1 MEGA-6000U2 Owner’s Manual ANCHOR Audio, Inc. (310) 784-2300 100-0058-000 / Revision D - 05/03...

  • Page 2: Important Safeguards

    (service) dans le livret d'instruction accompagnant l'appareil. DATE OF MANUFACTURE The date of manufacture of this Anchor Audio product can be determined by the eight digit serial number code. The fourth digit denotes the year, the third digit (letter) denotes the month (A=Jan, B=Feb, etc.) Example: "AWDO1432"...

  • Page 3: Table Of Contents

    ACCESSORIES Thank you for choosing an Anchor Audio portable sound system. Our products incorporate state-of- MEGA-6001 the-art design and the finest quality of materials Unpowered MegaVox Pro companion speaker and workmanship. We’re proud of our products and SS-550 appreciate the confidence which you have shown by Heavy-duty brushed aluminum speaker stand selecting an Anchor system.

  • Page 4: Getting Started

    MIC 1/Wireless input. Unplug any other mic pending freight claim. from the MIC 1/Wireless input when using the wireless system. Returning Systems For Service or Repair Replacing Transmitter Battery Should your unit require service, contact your dealer or the Anchor IMPORTANT: CAUTION: Handheld Transmitter: Save the...

  • Page 5: System Setup

    Diversity Wireless by Anchor Audio Setting Up The MegaVox Pro Anchor Audio UHF wireless is a 16 channel, diversity wireless For best results, it is recommended that the PA system be placed system that utilizes two independent antennae to receive signal. The...
  • Page 6 Line Out - to - Line In Connection to the MegaVox Pro for greater crowd coverage. Speaker Out Use the speaker output to drive Anchor’s model MEGA-6001 companion speaker (in addition to MegaVox Pro's built-in speakers) for greater output. When an external speaker is powered by the MegaVox Pro, battery service per charge will decrease considerably.

  • Page 7: General Operation

    5. Use the volume control on the primary unit to set the volume interference. for the entire chain. Wireless Receiver/ Mic Controller 6. Power off speakers in reverse order, primary unit last. This MEGA-6000 will avoid speaker popping which can cause damage. Back Panel...

  • Page 8: Battery Operation

    PRECAUTIONS BATTERY OPERATION Feedback Caring For Built-in Batteries Feedback is a howling or shrill sound that is self-generated by the It is very important that you fully charge the batteries in your system IMPORTANT: sound system. It is caused by microphone pickup of the sound before first use and as soon as possible after each and every use, For longer emanating from the speaker and then being re-amplified.
