Summary of Contents for Schlage KC9000-LG
- Page 1 KING COBRA/KING COBRA-2 NARROW STILE SERIES KC9000-LG KC9000 Latch Guard 57055-B 04-2007...
- Page 2 7. 1/8” drill bit 8. 7/16” drill bit 9. 11/32” drill bit 10. Drill and Tap for 10-32 threads 11. Socket wrench set Contact Information: Schlage Lock Company 575 Birch Street Forestville, CT 06010 technical support: 866-322-1237 fax: 866-322-1233 web: http://www.irsupport.net...
- Page 3 KC9000/KC9000-2 LATCH GUARD INSTALLATION Installing the KC9000-LG 1) Prepare Door: Installing the KC9000-LG New Construction-Start Here Remove all existing trim from outside of door. • Remove backing from sticky template provided. • Refer to Figure 1. Apply sticky template to area on stile where •...
- Page 4 KC9000/KC9000-2 LATCH GUARD INSTALLATION Installing the KC9000-LG Set the Latch Guard aside. • > You should have two, 3/8” squares marked on door stile, 15” apart (a). Draw diagonal lines connecting opposite corners within each square (b). • Centerpunch at the point where the lines intersect within each square (c).
- Page 5 KC9000/KC9000-2 LATCH GUARD INSTALLATION Installing the KC9000-LG 3) Secure the Latch Guard: Refer to Figure 6. From the inside of door, install • the remaining provided hardware onto the Carriage Bolts: > Slide a flat washer onto each Carriage Bolt.
- Page 6 KC9000/KC9000-2 LATCH GUARD INSTALLATION Installing the KC9000-LG 4) Installing the Trim (KC9111 and KC9321 ONLY): The following pertains only to KC9111 and KC9321. If you are installing any- thing other than a KC9111 or KC9321, skip to Step 5. Refer to Figure 7. Insert the adapter into the 1- •...
- Page 7 KC9000/KC9000-2 LATCH GUARD INSTALLATION Installing the KC9000-LG 5) Installing the Trim (All models except KC9111 and KC9321): The following pertains to all models except KC9111 and KC9321. Refer to Figure 9.Install the adapter on the trim: • > Place the spacer on the back of the trim.
- Page 8 KC9000/KC9000-2 LATCH GUARD INSTALLATION Installing the KC9000-LG 6) Finish Installing the Trim (All Models): Install the batteries and the battery cover. • > Instructions for installing the batteries and the battery cover are included in most KC9000 Narrow Stile Installation Manuals, e.g., Form #57040.
