- Page 1 KING COBRA/KING COBRA-2 NARROW STILE SERIES KC9354/KC9354-2 Keypad Programmable and SNAP Compatible Trim For Narrow Stile Doors 57049-A 04-2007...
-
Page 2: Contents Of The Box
KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Contents of the Box KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Contents of the Box Contents of the Box 57049-A Page 2 04-2007... -
Page 3: Introduction / Tools And Materials Needed / Contact Info
Introduction: Introduction / Tools and Materials Needed / Contact Info The KC9354/KC9354-2 will allow access by allowing the trim to unlock the exit device when an access code or iButton is entered and the turnpiece is turned coun- terclockwise. Mechanical key override is standard. The trim is compatible with the dogging features available with the Adams Rite®... -
Page 4: Door Preparation
Installation may require the use of a cover plate (a) to cover the holes left in the door. If an existing pull (b) must be removed, Ives offers a compatible pull. >Schlage Cover Plate P/N: KC9000-KRP >Ives Pull P/N: 8190-18-xxx (xxx = finish) Backset is determined by the Adams Rite®... -
Page 5: Cams, Cores, Cylinders And Blocking Rings
Cams For Mechanical Override Cylinder: Cams, Cores, Cylinders and Blocking Rings The KC9000 trim requires the use of a clover leaf cam (a). This is a list of compatible Schlage parts. For other manufacturers, consult cross-reference charts. > Cam for Standard Mortise cylinder:... - Page 6 KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 Installing the KC9354/KC9354-2 Installing the KC9354/KC9354-2 If your trim has a key cylinder already installed, skip to Determine Hand: on page 12. Other- wise, continue with Loosen the Baseplate Screws: on this page. 1) Loosen the Baseplate Screws: IMPORTANT: Do not remove any of the screws in the fol- lowing step or it will be difficult to reinstall them.
- Page 7 KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 3) Make Room for Key Cylinder: Due to the diameter of the key cylinder, it is necessary to have dead latch (a) placed out of the way when installing the key cylinder. Therefore... Using your finger or a pair of needle-nose •...
- Page 8 • Screw in key cylinder until it stops. Use mechanical key as a han- • dle for turning if necessary. Table 1: Blocking Rings Key Cylinder Length Blocking Ring (Schlage P/N; XXX = finish) • 1-1/4” 1/8” (36-079-012-XXX) • 1-3/8”...
- Page 9 KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 8) Alignment of Interchangeable Cores: If an IC Core is used, center the interface toward the • bottom. 9) Tighten the Four Screws in the Baseplate: Tighten the four baseplate screws in the fol- •...
- Page 10 KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 11) Position the Dead Latch’s Set Screw Hole: Tilt the trim until you see the “critical • edge” align with the larger hole in the baseplate as shown in photo on right. Look closely at edge of dead latch’s “critical edge”...
- Page 11 KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 12) Partially Tighten the Set Screw: Using a 1/16” Allen wrench, partially turn in the set • screw until outer end of set screw is about flush with surface of baseplate. 13) Fully Tighten the Set Screw: Finish turning in the set screw until it hits the stop.
- Page 12 KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 14) Prep for Exit Only or New Installation: Prep door for device according to the Adams • Rite® instructions. Transfer horizontal and vertical centerlines • to front of door. Place the transparent self-adhesive template •...
- Page 13 KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 15) Prep with Existing Cylinder Escutcheon: Remove screw that secures the • cylinder escutcheon. Remove cylinder escutcheon. • NOTE: It will be necessary to remove the exit device pushpad or paddle in order to access the cylinder escutcheon mounting screw.
- Page 14 KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 Prep with Existing Adams Rite Lever Trim: ® Remove existing trim. See Adams Rire® instructions • for more information. Apply transparent self-adhesive template as shown. • It is very important to line up the template with the •...
- Page 15 KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 16) Install Adapter Housing: Using the provided #8-32 • screw, install adapter housing. NOTE: If the KC900-KRP cove plate is used, the provided spacer (a) must be used between the interface attachment and the baseplate 17) Verify That Handing Screw is Installed As Shown: Turn the key 180 degrees CCW.
- Page 16 KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 19) Remove Trim Interface Tube If present, remove trim interface tube using small phil- • lips screwdriver. Use care not to let it drop into the hollow door stile. TIP: To help prevent interface tube from dropping into the door stile, hold a small piece of paper underneath trim inter- face tube.
- Page 17 KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 22) Place Trim On Door: Align trim with exit device interface. Reposition tail- • piece if necessary. Place trim on door. • 23) Partially Tighten Trim’s Top Screw Using a ball-end, 1/8” hex wrench, partially tighten trim’s top •...
- Page 18 KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 25) Install Lower Mounting Screws: Remove battery pack (a). • Install and completely tighten both lower mounting screws (b) and • (c) located within battery compartment. Finish tightening top mounting screw. • 26) Install Batteries: Remove and retain battery bag.
-
Page 19: Installation Complete
KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Installing the KC9354/KC9354-2 28) Install Battery Pack: Install battery pack into compartment with bag open- • ing facing down. Tuck wiring neatly into compartment • 29) Install Battery Compartment Cover: Slide battery compartment cover on from the bottom. -
Page 20: Test Operation / Dimensions
KC9354/KC9354-2 INSTALLATION INSTRUCTIONS Test Operation / Dimensions Test Operation Test Operation / Dimensions 1. Turnpiece should rotate freely. 2. Insert key into cylinder and rotate counterclockwise 180 degrees. 3. Rotate turnpiece clockwise to unlock device > Door should be able to be opened.
