SEA DATA English
3.3

Instrument backlight

1. Press and hold PAGE
2 sec
2. Select backlight level with PLUS
3. Set the light level with SET
4

Function overview

The functions in the Sea Data instrument are divided into 2 pages:
SPEED and DEPTH.
The selected page is indicated by the LCD mark at top of the display.
Each page has 2 types of functions that can be displayed together:
1. Main-function, displayed at the top of the display in 30 mm high digits.
2. Sub-function, displayed at the bottom part of the display in 17 mm high digits.
You can easily customise your favourite combination of functions, (See 9).
The instrument can display metric and imperial units.
For unit selection, (see 8).
For function overview and transducers needed to display each function, see below.
13
