First Start; Initialising The Instrument - Nexus NX Sea Data Installation And Operation Manual

SEA DATA
3

First start

3.1

Initialising the instrument

You will be asked to press SET (PrESkey) on the instrument the
very first time after installation. This will give the instrument a
logical ID number that belongs to your specific Nexus Network.
Press SET, on each installed instrument, one at the time.
Always wait for the text 'Init OK' to be displayed,
before you press SET on the next instrument!
The first unit ID number is 16, then 17 and so on in the order
which you press SET.
The example shows that the instrument version number is 1.0 and
that the instrument was given the logical ID number 16.
The bottom row shows the software version (4.8) and ID number (0) of
the network master.
When the NX WSI-box is network master, the ID number is 2
When the NX2 Server is network master, the ID number is 0
11
English
