Chapter 1 Table of Contents

Table of Contents

Chapter 1 Table of Contents..................................................................... 1
1.1 Saftey Precautions.......................................................................................4
1.2 Disposal Instruction .....................................................................................5
1.3 A Thank-you Note Before You Get Start..........................................................8
1.4 Features of This Manual ...............................................................................9
1.5 Safety Information ......................................................................................9
Chapter 2 Introduction to This Motherboard ............................................. 10
2.1 How does your motherboard look like?......................................................... 10
2.2 Specification ............................................................................................. 11
2.3 Block Diagram .......................................................................................... 12
Chapter 3 Hardware Installation ............................................................. 13
3.1 Quick Installation Procedure ....................................................................... 13
3.2 Installation You Have to Know..................................................................... 14
Installing CPU ...........................................................................................14
Installing CPU Cooler .................................................................................15
Installing CPU and System Fans ..................................................................18
Installing Memory Modules .........................................................................19
Connecting IDE and Floppy Cables ..............................................................20
Connecting Front Panel Cable .....................................................................21
Connecting ATX Power Cables .....................................................................22
3.3 Other Installation for Your Reference ........................................................... 23
Setting CPU Voltage and Frequency .............................................................23
Connecting Serial ATA ................................................................................24
Adjusting your Hard Disk Setting.................................................................25
Connecting AGP 8X Expansion Slot ..............................................................26
Connecting IrDA........................................................................................27
10/100 LAN Supported...............................................................................28
