s661FXm-S / s661FXm
IrDA Connector
Case Open Connector
Onboard AC'97 CODEC
Front Audio Connector
S/PDIF Connector
AUX_IN Connector
STBY LED
CD_IN Connector
AGP Protection LED
32-bit PCI Expansion Slots x3
SYSFAN2 Connector
USB 2.0 Connectors x 2
DieHard BIOS Lite
Serial ATA Ports x2
Supports 150 MB/s Transfer Rate
JP14 CMOS Data Clear Jumper
Front Panel Connector
FDD Connector
AOpen reserves the right to revise all the specifications and information contained in this document, which are subject to change without notice.
SPP/EPP/ECP Parallel Port
PS/2 Mouse
Connector
USB 2.0
Ports
PS/2
COM Port
VGA Port
Keyboard
RJ45
LAN Jack
Line-In
Speaker
Out
MIC-In
USB 2.0 Ports
JP28 PS2 KB/Mouse Wakeup
Jumper
Resetable Fuse
4-pin 12V ATX Power Connector
Functional Polymer Capacitor
AGP 8X Expansion Slot that
supports 8X AGP card(2.1GB/s)
CPUFAN Connector
478-pin CPU socket with Voltage
and
Frequency
Auto-detection
that supports Intel
®
Pentium
®
4
Nothwood and Prescott CPU
SIS
®
661FX/964 (s661FXm-S) /
SIS
®
661FX/964L (s661FXm)
Chipsets that support
400/533/800 MHz FSB,
SYSFAN1 Connector
184-pin DIMMsx2 support
DDR400/333/266
Max. To 2GB
IDE Connectors x 2
(ATA33/66/100/133 supported)
ATX Power Connector
Advertisement
Table of Contents
Related Manuals for AOpen s661FXm-S
Summary of Contents for AOpen s661FXm-S
- Page 1 JP14 CMOS Data Clear Jumper IDE Connectors x 2 (ATA33/66/100/133 supported) Front Panel Connector ATX Power Connector FDD Connector AOpen reserves the right to revise all the specifications and information contained in this document, which are subject to change without notice.
- Page 2 Memory Module Frequency 80-Wire IDE Cable x 1 Floppy Drive Cable x 1 9. Connecting Back Serial ATA Power Cable x 1 (for s661FXm-S) 4. Installing HD, Panel Ports Serial ATA Cable x 1 (for s661FXm-S) CD-ROM and SATA (Keyboard, Mouse,...
- Page 3 1. Installing CPU 3. Installing Memory Modules This socket supports FC-PGA2 package CPU, which is the latest CPU package DIMM slots are designed in Electronic Blue which are very easy to recognize. Insert developed by Intel. Other forms of CPU package are impossible to be fitted in. the module straight down to the DIMM slot with both hands and press down firmly until the DIMM module is securely in place.
- Page 4 (CPU, RAM, HDD, etc.) are good enough for turbo setting. 6. Connecting ATX Power Cables 8. AOpen Bonus Pack CD and EzInstall This motherboard comes with a 20-pin and 4-pin ATX power connector as shown You can use the autorun menu of Bonus CD disc. Choose the utility and driver below.
-
Page 5: Jp28 Keyboard/Mouse Wakeup Jumper
Setting CPU Voltage & Frequency JP14 Clear CMOS Setting CPU Core Voltage You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedure This motherboard supports Voltage ID (VID) function to detect CPU voltage below. automatically during power-on. -
Page 6: Sata1 Sata2
USB 2.0 Connectors Front Audio Connectors This motherboard provides eight USB 2.0 ports to connect USB devices, such as If the housing has been designed with an audio port on the front panel, you’ll be mouse, keyboard, modem, printer, etc. There are four ports on the back panel. able to connect onboard audio to front panel through this connector. -
Page 7: Model Name And Bios Version
Gold member of Club AOpen, and to ensure high service quality and priority from AOpen. You will also have a chance to play slot machine game to win prize from AOpen. Please prepare the following information before you start: Model Name, Part Number (P/N), Serial Number (S/N) and Purchase Date. - Page 8 Gold Member of Club AOpen so as to ensure quality service in the future. In order to maintain the best service to every customer of us, we recommend you to follow the procedures below and seek help from our branches according to the region you buy the product.
