Secondary B ill I nterval

Secondary C ost p er B ill I nt

Current B alance

5) Click S ave.

To d efine t he C all D uration S IM l ist:
1) On t he M ain T oolbar, c lick P orts.
2) From t he p orts l ist o n t he l eft, s elect a p ort.
3) Select t he T ime T able t ab.
4) In T ype, s elect a T ime T able t ype.
5) In S wapping T ype, s elect C all d uration.
6) In A vailable S IMs, s elect t he L ocal S IM ( L1).
7) In t he T ime T able, c lick a c ell. A d ialog b ox a ppears.
8) In t he d ialog b ox, e nter t he a mount o f u nits y ou w ant t o l imit t he S IM t o t hat d ay.
9) To u nselect t he c ell, c lick i t a gain.
10) Click S ave.
4.2. CONFIGURING T HE I NTERNAL S IP S ERVER
The G ateway h as a n i nternal S IP S erver t hat i s a ble t o r egister u p t o 3 2 S IP c lients. A S IP c lient c an b e
a:
VoIP p hone

External S IP S erver

IP P BX/Softswitch

The i nternal S IP S erver c an w ork w ith o r w ithout a uthentication. W hen w orking w ith a uthentication,
the S IP a ccount m ust b e e ntered i nto t he U sers l ist.

To c onfigure t he S IP S erver:
1) On t he M ain T oolbar, c lick V oIP.
2) Select t he S IP t ab.
3) In t he I nternal S IP S ettings s ection o f t he w indow, d efine t he f ollowing p arameters:
SIP P ort -­‐ T he T CP p ort o f t he S IP S erver. T he d efault i s 5 060.

RTP S tart P ort -­‐ T he f irst p ort i n t he R TP p ort r ange. T he d efault i s 5 066.

RFC2833 P ayload T ype -­‐ T he t ype o f p ayload t o b e u sed b y t he S IP. T he d efault i s 1 01.

Codec 1 -­‐ C odec 4 -­‐

The p riority o f t he C odec w hich t he S IP S erver u ses w hen m aking o utgoing V oIP c alls.
Note: T he C ODEC p riority i s r elevant o nly i n c alls t o S IP, t he c odec f or t he i ncoming c alls f rom S IP i s
determined b y t he S IP t hat s ends t he c alls t o t he G ateway.
Authentication -­‐ W hen e nabled a u ser n ame a nd p assword i s r equired t o r egister t he

VoIP²ALL i n t he i nternal S IP S erver.
Realm -­‐ T he n ame o f t he S IP S erver r ealm o f o peration.

VoIP²ALL 8 - 16 - 24 Channel Gateway User Guide http://www.dtt.tw 24
