To c onfigure a p refix t o a p ort:
1) From t he M ain T oolbar, c lick P orts.
2) Select a p ort f rom t he l ist o n t he l eft.
3) Select t he P refixes t ab. A p refix t able f or t he s elected p ort i s d isplayed.
4) Enter t he p refixes y ou w ant t o a dd t o t his p ort i n t he t able.
There a re t wo r ules:
The d efault p refix i s * . I f t he p refix o f a p ort i s * , t hen a ll t he c alls t hat d o n ot m atch a p refix i n

another p ort a re r outed t hrough t his p ort.
If t wo o r m ore p orts h ave t he s ame p refix t hen t he G ateway w ill d ivide t he c alls b etween t he

ports.
Note: T o a void l osing c alls, m ake s ure t hat t he c ellular p refix i s d ifferent t han t he V oIP a nd H ost
prefixes.
1) (Optional) Y ou c an m odify t he d ialing n umber r eceived f rom t he S IP w hich t he G ateway u ses t o
dial o ut b y u sing t he f ollowing p arameters:
R emove P refix -­‐ S elect h ow m any d igits t o r emove f rom t he b eginning o f t he d ialed n umber.

A dd P refix -­‐ E nter t he d igits t o b e a dded a t t he b eginning o f t he n umber.

2) Click S ave.
3.1.4.4. LAN C ONFIGURATION
When t he G ateway i s w orking b ehind N AT o r a F irewall, y ou m ust m ake s ure t hat t he p orts o f t he
Gateway a re a ccessible f rom t he p ublic I P t o t he G ateway l ocal I P.
The f ollowing p orts n eed t o b e f orwarded t o t he G ateway:
Port 2 007 -­‐ t o m ake c onnection w ith t he P C s oftware

Port 2 008 a nd p ort 2 009 ( optional) -­‐ t o a llow a ccess t o t he i nternal S IM S erver

Port r ange f rom 5 060 t o 6 066 -­‐ f or t he S IP r egistration a nd c alls

3.1.5. CONFIGURING T HE S ECOND P ART O F T HE M ASTER
When w orking w ith a 2 4ch V oIP²ALL G ateway t he s econd p art o f t he m aster ( ST2) m ust b e
configured. F ollow t he s ame c onfiguration s teps w hich y ou p erformed f or t he 1 st p art o f t he m aster
above.
Note : T he s econd p art o f t he m aster ( ST2) m ust h ave d ifferent I P A ddress f rom t he f irst p art ( ST1).
3.1.6. BASIC S YSTEM T EST
Once y ou h ave c ompleted t he b asic c onfiguration d escribed i n t he p revious s ections, y ou c an n ow
test t hat t he s ystem i s f unctioning n ormally u sing t he f ollowing p rocedures.
VoIP²ALL 8 - 16 - 24 Channel Gateway User Guide http://www.dtt.tw 16
