AUTOMATIC DOORS
MICROWAVE RADAR
CANCELLI AUTOMATICI
TECHNICAL
Technology
SPECIFICATIONS
Frequency emitted
Power density emitted
Mounting height
Tilt angle
Detection area (typical)
• wide sensing field
• narrow sensing field
Detection mode
Minimum speed
Supply voltage
Mains frequency
Power consumption
Standard output relay (free potential contact)
• Max contact voltage
• Max contact current
• Max switching power : 30 W (DC) / 60 VA (AC)
DESCRIPTION
OF
THE SENSOR
INSTALLATION
TIPS
• The sensor must be firmly
fastened in order not to
vibrate
- UNIDIRECTIONAL
: hyperfrequency and
microprocessor
: 24.125 GHz
: << 5 mW/cm
: 4 m max
: 0° to 90° vertical
: –30° to +30° lateral
: 4 m (W) x 2 m (D)
: 2 m (W) x 2.5 m (D)
: motion
: 5 cm/s (measured in axis
of radar)
: 12 to 24 V AC ±10%
: 12 to 24 V DC +30 %/–10 %
: 50 to 60 Hz
: < 2 W
: 75 V DC / 50 V AC
: 1 A (resistive)
Narrow sensing field antenna
INTERNAL VIEW
Terminal block
Push buttons +/–
Led
Adjustment for
vertical position
of antenna
Adjustment of
lateral position of
antenna
Planar antenna
wide original sensing field
• The sensor must not be
placed directly behind a
panel or any kind of
material
MR8106
Output hold time
Manual adjustments
• sensitivity (by push buttons)
• orientation of sensing field (mechanically)
2
• shape of sensing field (choice of antenna)
Remote control adjustment
• sensitivity
• hold time
• multiple functions
Temperature range : from –20°C to +55°C
Immunity
Dimensions
Weight
Material
Colour of housing
Length of cable
Cover viewed
from inside
• The sensor must not have
any object likely to move
or vibrate in its sensing
field
Documentazione
Tecnica
M90
rev.
02/2002
©
CANCELLI
AUTOMATICI
119PM90_GB
: 0.5 s to 9 s (adjustable)
: electromagnetic compatibility
(EMC) in accordance with
89/336/EEC
: 120 mm (W) x 80 mm (H) x
50 mm (D)
: 0.215 kg
: ABS
: anthracite grey, aluminium finish
or white
: 2.5 m
• No fluorescent lighting in
the sensing field
0.1
CAME
