- Page 2 LKS-SR16 / LKS-SR24 Features • 10/100Mbps Auto-Negotiation, Auto-MDIX Ethernet Ports • Store-and-Forward switching architecture with non-blocking wire-speed performance • IEEE 802.3x flow control support • Support operation link down power saving • Internal switching power • Metal housing • Diagnostic LEDs...
-
Page 3: Hardware Installation
LKS-SR16 / LKS-SR24 Hardware Installation 1.Connect the AC power cord to the LKS-SR16 / LKS-SR24 and then to a power outlet 2. Connect an Ethernet RJ-45 network cable from the computer to an available Ethernet port on the LKS-SR16/ LKS-SR24... - Page 4 LKS-SR16 / LKS-SR24 4. PWR(Power) ‧Green : Power is on ‧Not Illuminated : Power is off 3. Link / ACT ‧Green (Solid): Indicate the port is operating at 10/100Mbps ‧Green (Blinking): Indicate the activity is occuring...
-
Page 5: Technical Specifications
LKS-SR16 / LKS-SR24 Technical Specifications Hardware IEEE 802.3 10Base-T Standard IEEE 802.3u 100Base-TX IEEE 802.3x Flow Control Ethernet: UTP/STP Cat. 3, 4, 5 up to 100m Network Media Fast Ethernet: UTP/STP Cat. 5, 5e, 6 up to 100m Data Rate...
