3 . I P A d d r e s
3 . I P A d d r e s

Set IP Address Manually

You can set the IP address of a device on the list or identify a device not on the list and set its IP
address.
To set the IP Address of a Device:
1. From the device list, select the device.
2. On the toolbar, click Assign IP
Note: The Device Identification window prompts for the device's hardware address if a
device was not selected in the previous step. Enter the hardware address from the product
label and click Next.
3. On the Assignment Method page, select Assign a specific IP address and click Next.
The IP Settings window displays.
4. Enter the following information:
IP address
Subnet mask
Default gateway
5. Click Next. The Assignment page displays.
6. Click Assign to assign the IP address to the device. A status message indicates when
the assignment is complete.
7. To exit, click Finish.

Set IP Address Automatically

You can specify the method by which the device obtains its network settings. If you are not
familiar with the specific protocols, we recommend you accept the default options.
To set the IP address of the device automatically:
1. From the device list, select the device.
2. On the toolbar, click Assign IP
s e s
s e s
. The Assign IP Address window displays.
An IP address that will be unique and valid on your
network. There is no default.
Note: Enter the IP address in dot-quad notation. Do not
use leading zeros in the fields for dot-quad numbers
less than 100. For example, if your IP address is
172.19.201.28, do not enter 028 for the last segment.
The network segment on which the device resides.
There is no default. The subnet mask displays
automatically based on the IP address you entered, but
you can change it.
IP address of the router for this network.
. The Assign IP Address window displays.
6
