Figure 3.1: Svip1020 Explorer [User Login] Screen - Avocent SwitchView IP 1020 Installer/User Manual

14
SwitchView IP 1020 Installer/User Guide
NOTE: The SwitchView IP 1020 remote access device boots to the following static IP address, gateway
and netmask:
• IP address: 192.168.1.254
• Gateway: 192.168.1.1
• Netmask: 255.255.255.0
3. When the browser makes contact with the SwitchView IP 1020 web browser, enter your
username and password, then click Login. The SVIP1020 Explorer window displays, as shown
in Figure 3.1.
NOTE: The default username is Admin with no password.

Figure 3.1: SVIP1020 Explorer [User Login] Screen
