Kohler Command CV17 Service Manual page 83

CV18 Engines
Intended Standard
Maximum RPM Throttle Control
High Spring
WOT
Idle Color
3888 3600 Green
3780 3500 Blue
3672 3400 Orange
3564 3300 Clear
3456 3200 Red
3348 3100 Purple
3240 3000 Blue
3132 2900 Orange
3024 2800 Black
CV20-740 Engines with 0.0299 + 0.003 in. Thick
(22 GA) Throttle Limiter
Intended Standard
Maximum RPM Throttle Control
High Spring
WOT
Idle Color
3888 3600 Green
3780 3500 Blue
3672 3400 Orange
3564 3300 Clear
3456 3200 Red
3348 3100 Purple
3240 3000 Blue
3132 2900 Orange
3024 2800 Black
CV750 Engines
Governor Shaft
Confi guration
Standard
(Parent Material)
24 690 07 Rev. B
Engine Mounted
Throttle Control
Pivot Shaft
Hole Spring Hole
No. Color No.
4 Orange 4
4 Green 4
3 Blue 4
4 Orange 3
3 Green 3
2 Blue 3
2 Purple 2
1 Blue 2
1 Green 1
Engine Mounted
Throttle Control
Pivot Shaft
Hole Spring
Hole No.
No. Color
4 Purple 4
4 Black 4
3 Red 4
4 Purple 3
3 Black 3
2 Red 3
2 Clear 3
1 Red 2
1 Green 1
Intended Maximum RPM
High Idle
3888
3780
3672
3564
3456
3348
KohlerEngines.com
CV17, CV20-740 Engines Without Throttle Limiter
Intended Standard
Maximum RPM Throttle Control
High Spring
WOT
Idle Color
3888 3600 Red
3780 3500 Purple
3672 3400 Black
3564 3300 Red
3456 3200 Purple
3348 3100 Blue
3240 3000 Orange
3132 2900 Clear
3024 2800 Red
With Governed Idle Systems
WOT Spring Color
3600 Clear
3500 Orange
3400 Blue
3300 Red
3200 Clear
3100 Clear
Reassembly
Engine Mounted
Throttle Control
Pivot Shaft
Hole Spring
Hole No.
No. Color
4 Blue 4
3 Orange 3
3 Black 3
3 Orange 2
2 Green 2
2 Blue 2
1 Orange 1
2 Black 1
1 Red 1
Hole No.
3
1
1
1
1
1
83
