4. If your GPS device prompts for a PIN or Passkey enter 0000 (four zeros).
5. Your GPS device will confirm that pairing has succeeded. The
headset will begin flashing slowly in Blue.
6. If you wish to use a Bluetooth mobile phone to make and
receive calls through the headset, you must now pair your
mobile phone to your GPS device by following your GPS
and/or mobile phone's instructions.
NOTE: If the Pairing process is not completed within two
minutes the headset will return to Standby mode.

RESET PAIRING

You can delete all of the headset's pairings at any time.
1. With the scala rider TeamSet
and hold the CTRL Button for at least six seconds until the Red
and Blue Lights begin rapidly alternating.
2. Once the Red and Blue Lights begin flashing rapidly, press and
hold Volume up for three seconds.
3. The Red and Blue Lights will flash five times, confirming that
the Reset Pairing was successful.

GETTING STARTED

ATTACHING THE CLAMP ON THE HELMET

The Helmet Clamp must be attached to the left side of the helmet.
Once attached, the headset unit can be mounted or released from
the Helmet Clamp at any time. If you wish to connect your MP3 player
to your headset, please refer first to the assembly instructions listed in
section: USING THE MP3 PLAYER WITH YOUR HEADSET.
There are two methods that can be used in order to attach the Clamp
onto the helmet:
6 scala rider ® TeamSet ™
PRO
headset turned ON, press
pro
Standard Method: Recommended for most helmet types.
Glue Plate Method: Recommended for helmets to
which the standard method cannot be applied,
using the Glue Plate included in the box.
Standard Method
1. Use the enclosed Allen Wrench to loosen the
two screws on the Back Plate.
2. Slide the Back Plate between the internal
padding and the external shell of the helmet.
3. Adjust the clamp's location so that the
microphone is located opposite your mouth
and then tighten the screws. You may need to
reposition the Clamp repeatedly until you
identify the best spot. The microphone must
be positioned vertically and not horizontally.
Glue Plate Method
You have the option to glue the Helmet Clamp onto your helmet,
when the above standard method cannot be used, or in case you
prefer to secure the Helmet Clamp with adhesive glue. This option
has been successfully used for a range of high end helmets.
NOTE: While we have no reason to believe that the gluing option might
negatively affect any helmet, Cardo does not assume any responsibility to
that affect, irrespective of its nature and circumstances. The Glue Plate is
offered as a free option that you may choose to use at your own risk and
subject to renouncement of any future claims.
Caution: This process can be done only once!
1. Use the enclosed Allen Wrench to remove both Allen
screws and release the Helmet Clamp's back plate.
2. Determine the location on the helmet where the Hel-
met Clamp must be attached.
