ATEN AS-251S User Manual

2 to 1 serial rs-232 auto switch

Table of Contents

Download this manual

Read this manual thoroughly and follow the installation procedures carefully to

All brand names and trademarks are the registered property of their respective owners.

1 x AS-251S 2 to 1 Serial (RS-232) Auto Switch

1 x User's Manual

If anything is damaged or missing, contact your dealer.

This easy to install Auto Switch allows two computers to share a serial printer. Since it features a light

weight, compact, design, and requires no external power, it can be easily placed in any convenient

location.

1 of 4

2 To 1 Serial (RS-232)

prevent any damage to the AS-251S and/or the devices it connects to.

Manual Part No. PPAG-905-001

Printed in Taiwan 05/2002

AUTO SWITCH

AS-251S

User Manual

Table of Contents

Do you have a question about the AS-251S and is the answer not in the manual?

Page 1: User Manual
AS-251S User Manual Read this manual thoroughly and follow the installation procedures carefully to prevent any damage to the AS-251S and/or the devices it connects to. ©Copyright 2000 Aten® International Co., Ltd. Manual Part No. PPAG-905-001 Printed in Taiwan 05/2002 All brand names and trademarks are the registered property of their respective owners.
Page 2: Switch Setting
Switch Setting There are two slide switches located on the unit's side panel that are used to configure the AS-251S. The one on the left determines which port has access to the printer; the one on the right sets the timeout value.
Page 3: Specifications
Selected Port The port that has access to the printer is determined with this three position slide switch as follows: Position Result AUTO Under AUTO (the central position of the switch), access to the printer is automatic, and is determined on a first come first served basis. As soon as a signal is received, the switch immediatley connects and stays on the port until the print job has finished.
Page 4: Limited Warranty
Storage Temp. -20 to -60˚ C Humidity 0 - 80% RH Housing Plastic Weight 130 g Dimensions (L x W x H) 105 x 85 x 26 mm Limited Warranty IN NO EVENT SHALL THE DIRECT VENDOR S LIABILITY EXCEED THE PRICE PAID FOR THE PRODUCT FORM DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THE PRODUCT, DISK, OR ITS DOCUMENTATION.
