AS-251S User Manual
2 To 1 Serial (RS-232)
AUTO SWITCH
AS-251S

User Manual

Read this manual thoroughly and follow the installation procedures carefully to prevent
any damage to the AS-251S and/or the devices it connects to.
©Copyright 2000 Aten® International Co., Ltd.
Manual Part No. PPAG-905-001
Printed in Taiwan 05/2002
All brand names and trademarks are the registered property of their respective owners.

Packing Checklist

http://10.0.13.228/manuals/html/hdatacom/as251s/as251s.html (1 of 5)2006/7/6 NSH 05:11:54

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS-251S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ATEN AS-251S

Summary of Contents for ATEN AS-251S

  • Page 1: User Manual

    AS-251S User Manual Read this manual thoroughly and follow the installation procedures carefully to prevent any damage to the AS-251S and/or the devices it connects to. ©Copyright 2000 Aten® International Co., Ltd. Manual Part No. PPAG-905-001 Printed in Taiwan 05/2002 All brand names and trademarks are the registered property of their respective owners.
  • Page 2 AS-251S User Manual 1 x AS-251S 2 to 1 Serial (RS-232) Auto Switch 1 x User's Manual If anything is damaged or missing, contact your dealer. Overview This easy to install Auto Switch allows two computers to share a serial printer. Since it features a light weight, compact, design, and requires no external power, it can be easily placed in any convenient location.

  • Page 3: Switch Setting

    Use a DB-25 male to female serial cable to connect your first computer's COM1 or COM2 port to the connector of the AS-251S. Use a DB-25 male to female serial cable to connect your second computer's COM1 or COM2 port to the connector of the AS-251S.
  • Page 4 AS-251S User Manual Selected Port The port that has access to the printer is determined with this three position slide switch as follows: Position Result Under AUTO (the central position of the switch), access to the printer is automatic, and is determined on a first come first served AUTO basis.

  • Page 5: Specifications

    AS-251S User Manual Specifications Function Specification Cable Distance 15 m Input Connectors 2 x DB-25 Female (DCE) Output Connectors 1 x DB-25 Male (DTE) Port Selection Automatic / Selectable Timeout 10 / 60 secs. Operating Temp. 5 to 40° C Storage Temp.
