PRIORITY CHANNEL KEYS
➥ Push to select Priority A or Priority B channel.
➥ Push and hold [Prio A (Rewrite)] to rewrite the Prio A channel.
MR-CH 1/2/3/4 KEYS
Select an operating channel directly.
MONITOR KEY
Activates one of (or two of) the following functions on each chan-
nel independently:
• Push and hold to un-mute the channel (audio is emitted; 'Audible' con-
dition).
• Push to mute the channel (sets to 'Inaudible' only).
• Push to un-mute the channel (sets to 'Audible' only).
• Push after the communication is finished to send a 'reset code'.
NOTE: The un-mute condition ('Audible' condition) may auto-
matically return to the mute condition ('Inaudible' condition) after
a specified period.
LOCK KEY
Push and hold to electronically lock all programmable keys except
the following:
[Call] (incl. Call A and Call B), [Moni(Audi)] and [Emergency] keys.
OUTPUT POWER SELECTION KEY
Select the transmit output power temporarily or permanently, de-
pending on the pre-setting.
• Ask your dealer for the output power level for each selection.
PANEL DESCRIPTION
☞ Continue to the next page.
