SPECIFICATIONS

General
ï
• Frequency coverage (MHz)
• Mode
• Channel spacing
• Number of memory channels
• Power supply requirement
• Usable temperature range
• Current drain
• Antenna connector
• Dimensions
(projections not included)
• Weight
(Without the battery pack and antenna.)
ï Transmitter
• Output power
• Modulation
• Modulation depth
• Audio harmonic distortion
• Microphone connector
• Frequency stability
• Harmonics spurious emissions : Less than –36 dBm (except oper-
30
: TX 118.000 to 136.9917
*
RX 108.000 to 136.9917
: 6K80A3E/5K00A3E
: 25 kHz/8.33 kHz
: 200 (20 CH × 10 BANK)
: Specified battery packs/case or
11.0 V DC at external DC jack
: –20˚C to +55˚C
:Tx 1.5 A typical
Rx 70 mA typical (at stand by)
300 mA typical
(at AF maximum)
: BNC 50 W (nominal)
: 54(H) × 129.3(W) × 35.5(D) mm
: Approximately 180 g
: 5.0 W (PEP) typical
1.5 W (CW) typical
: Low level modulation
: 85%
: Less than 10% (at 85% ±3 dB
modulation)
: 3-conductor 2.5(d) mm ( 1 / 10 ˝)/
more than 100 kW
: ±1 ppm
ating frequency ±1 MHz range)
Receiver
ï
• Receive system
• Intermediate frequencies
• Sensitivity VOR (AM 6dB S/N)
COM (AM 12dB SINAD)
• Squelch sensitivity
• Adjacent channel rejection
• Spurious response rejection
• Audio output power
• Hum and noise
• External speaker connector
*: IC-A24E only. (IC-A6E frequency coverage is from 118.000 to 136.9917
MHz.)
Measurements made in accordance with EN300 676.
All stated specifications are subject to change without notice
or obligation.
: Double conversion
superheterodyne
: 1st 46.35 MHz
2nd 450 kHz
: –3 dBµ typical
: –3 dBµ typical (with CCITT)
: Less than 0 dBµ (Threshold)
: More than 60 dB
: More than 70 dB
: 500 mW typical
(at 10% distortion with an 8 W
load, 30% modulation)
: More than 40 dB at 90% modula-
tion
: 3-conductor 3.5 (d) mm ( 1 / 8 ˝)/8 W
