Husqvarna ST230E Operator's Manual page 16

Walk-behind snow throwers


Table of Contents
Check belts for deterioration and wear after every 50 hours
of operation and replace if necessary. The belts are not
ad just able. Replace belts if they begin to slip from wear.
(See "TO REMOVE BELT COVER" in the Service and
Adjustments section of this manual).
The belts on your snow thrower are of special con struc tion
and should be replaced by original equipment man u fac tur er
(OEM) belts avail able from your nearest dealer. Using other
than OEM belts can cause personal injury or damage to
the snow thrower.
The gear case was filled with lubricant to the proper
level at the factory. The only time the lubricant needs
attention is if service has been performed on the gear
If lubricant is required, use only Ronex ED #1 grease.
DO NOT lubricate the drive components inside the snow
thrower. The sprockets, hex shafts, drive disc and friction
wheel require no lubrication. The bearings and bushings
are lifetime lubricated and require no maintenance.
CAUTION: Any lubricating of the above com po -
nents can cause contamination of the friction
wheel and damage to the drive system of your
snow thrower.
See engine manual.
Use only high quality detergent oil rated with API service
classification SG–SL. Select the oil's SAE viscosity grade
according to your expected operating temperature.
NOTE: Although multi-viscosity oils (5W30, 10W30 etc.)
improve starting in cold weather, these multi-viscosity oils
will result in increased oil consumption when used above
32°F. Check your engine oil level more frequently to avoid
possible engine damage from running low on oil.
Change the oil after every 25 hours of operation or at least
once a year if the snow thrower is not used for 25 hours
in one year.
Check the crankcase oil level before starting the engine and
after each five (5) hours of continuous use. Tighten oil fill
cap / dipstick securely each time you check the oil level.
Determine temperature range anticipated before next oil
change. All oil must meet API service classification SG–SL.
NOTE: The left side wheel may be removed from snow
thrower for easier access to the oil drain plug and place-
ment of a suitable container. The unit tilted, resting on the
frame with the left wheel removed, will help drain any oil
trapped inside the engine. (See "TO REMOVE WHEELS"
in the Service and Adjustments section of this manual).
1. Remove safety ignition key and disconnect spark plug
2. Clean area around drain plug.
3. Remove drain plug and drain oil in a suitable container.
4. Install drain plug and tighten securely.
5. Wipe off any spilled oil from snow thrower and engine.
6. Install left wheel (if removed for draining oil). Be sure
7. Remove oil fill cap/dipstick. Be careful not to allow dirt
8. Refill engine with oil through oil dipstick tube. Pour
9. Use gauge on oil fill cap/dipstick for checking level.
10. Wipe off any spilled oil.
Inspect and replace corroded muffler as it could cre ate a
fire haz ard and/or dam age.
Replace spark plug at the beginning of each season or after
every 100 hours of operation, whichever occurs first. Spark
plug type and gap setting are shown in the "PROD UCT
SPEC I FI CA TIONS" section of this manual.
IMPORTANT: For best performance, keep snow thrower
housing free of any dirt or trash. Clean the outside of your
snow thrower after each use.
Be sure snow thrower is on level surface.
Oil will drain more freely when warm.
Catch oil in a suitable container.
wire from spark plug and place wire where it cannot
come in contact with plug.
to install wheel pin and retainer pin into proper hole
in wheel axle (See "TO REMOVE WHEELS" in the
Service and Adjustments section of this manual).
to enter the engine.
slowly. Do not overfill. For approximate capacity see
"PRODUCT SPECIFICATIONS" section of this man u al.
Be sure dipstick cap is tightened securely for accurate
reading. Keep oil at "FULL " line on dipstick.
WARNING: Disconnect spark plug wire
from spark plug and place wire where it
can not come in contact with plug.
Keep finished surfaces/wheels free of gasoline, oil, etc.
We do not recommend using a garden hose to clean
your snow thrower unless the electrical system, muffler
and carburetor are covered to keep water out. Water
in engine can result in shortened engine life.
