ILLUSTRATED PARTS LIST
MODEL NUMBER ST 268EP
PRODUCT NUMBER 961 91 00-38
MFG. ID. NUMBER 96191003803
532 44 37-35 Rev. 1

Advertisement

loading

  Related Manuals for Husqvarna ST 268EP/96191003803

  Summary of Contents for Husqvarna ST 268EP/96191003803

  • Page 1 ILLUSTRATED PARTS LIST MODEL NUMBER ST 268EP PRODUCT NUMBER 961 91 00-38 MFG. ID. NUMBER 96191003803 532 44 37-35 Rev. 1...
  • Page 2: Auger Housing / Impeller Assembly

    AUGER HOUSING / IMPELLER ASSEMBLY REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 2 (EXPLODED) 01.07.026-E NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty.
  • Page 3: Repair Parts

    AUGER HOUSING / IMPELLER ASSEMBLY REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 18 41-05 IMPELLER 532 42 71-48 GEARBOX ASSEMBLY 532 18 89-09 BEARING 532 42 71-46 IMPELLER PULLEY 532 44 24-38 DISCHARGE BASE 532 18 40-95...
  • Page 4 AUGER HOUSING / IMPELLER ASSEMBLY REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 42 95-87 AUGER HOUSING 532 40 77-27 SCRAPER BAR 872 27 05-05 CARRIAGE BOLT 5/16−18 X .625 532 15 53-77 NUT 5/16−18 3 (5x)
  • Page 5 AUGER HOUSING / IMPELLER ASSEMBLY REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 18 81-70 PLASTIC RETAINER 532 43 06-91 AUGER BALL BEARING 532 17 95-82 SCREW 5/16-18 x 1.00 874 78 04-26 SCREW 1/4-20 x .625 873 80 04-00...
  • Page 6 AUGER HOUSING / IMPELLER ASSEMBLY REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 18 25-15 WEIGHT BAR 872 11 05-10 CARRIAGE BOLT 5/16−18 X 1.25 532 75 11-53 NUT 5/16−18 819 11 22-06 WASHER 01.17.002-B...
  • Page 7: Control Panel / Discharge Chute

    CONTROL PANEL / DISCHARGE CHUTE REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 44 40-41 CHUTE WELDMENT 532 18 41-13 DEFLECTOR WELDMENT 532 42 06-73 DEFLECTOR CONTROL ASSEMBLY 532 42 03-25 DEFLECTOR SEAL 532 41 42-80 KNOB BLACK...
  • Page 8 CONTROL PANEL / DISCHARGE CHUTE REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 42 11-38 SHIELD DEFLECTOR 532 42 32-47 STRAP 532 18 22-27 SCREW 8-32 X .50 532 18 22-28 NUT 8-32 01.09.009-A PART...
  • Page 9 CONTROL PANEL / DISCHARGE CHUTE REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 42 82-72 LEVER/CABLE ROTATOR ASSEMBLY 817 50 10-10 SCREW 10-24 X .625 01.09.010-B 532 42 06-78 ROTATOR HEAD 532 40 59-32 ROTATOR PIVOT BRACKET 532 42 06-75...
  • Page 10 HANDLES REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 01.08.012-E PART DESCRIPTION 532 41 55-39 CONTROL PANEL 532 42 91-50 CONTROL LEVER LH 532 42 91-51 CONTROL LEVER RH 532 41 55-46 TRACTION ROD ARM 532 42 90-98 IMPELLER ROD ARM 532 41 26-77...
  • Page 11 HANDLES REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 42 17-08 PLOW HANDLE LH 532 42 17-09 PLOW HANDLE RH 532 42 91-48 PANEL BRACKET LH 532 42 91-49 PANEL BRACKET RH 532 41 45-15 HEATED HANDLE GRIP 874 78 05-12...
  • Page 12 HANDLES REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 18 04-80 IMPELLER ROD ASSEMBLY 532 40 57-40 TRACTION ROD ASSEMBLY 532 18 04-45 SHIFTER ROD TOP 532 18 77-16 SHIFTER ROD BOTTOM 532 18 04-47 SPRING SLEEVE 532 17 86-69...
  • Page 13 HANDLES REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 41 62-88 INTERLOCK SPRING 532 41 45-72 INTERLOCK CAM 532 44 32-15 TORSION SPRING 532 16 96-75 RETAINER 817 06 04-10 SCREW 1/4−20 X .625 532 42 18-14 INTERLOCK STOP...
  • Page 14 DRIVE REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 ITEM 42 EXPLODED 01.02.013-C NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your snow thrower and void your warranty.
  • Page 15 DRIVE REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART PART DESCRIPTION DESCRIPTION 532 19 88-75 SPEED SELECTOR 532 17 53-44 BEARING ASSEMBLY 532 17 86-13 WHEEL HUB 817 50 10-10 SCREW 10-24 X .625 874 76 05-14 SCREW 5/16-18-.875 532 43 60-80...
  • Page 16 DRIVE REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 01.03.002-B PART DESCRIPTION 532 40 49-23 AXLE ASSEMBLY (assy of 1a,1b) 532 40 43-07 AXLE SHAFT 532 18 42-06 ROLL PIN 3/16 X 1.50 532 40 26-91 SPROCKET 532 17 46-97...
  • Page 17 CHASSIS / PULLEYS REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 01.00.034-A PART DESCRIPTION – – – – B&S ENGINE 20M314-1479-H2 532 43 59-52 FRAME 532 15 04-06 BOLT 3/8-16 532 42 88-67 SCREW 5/16-18 X .750 PART DESCRIPTION...
  • Page 18 CHASSIS / PULLEYS REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 40 80-19 IMPELLER BELT 532 41 97-44 TRACTION BELT 532 42 92-71 IDLER ARM BRACKET 532 43 08-46 IDLER PULLEY 532 42 92-70 IDLER ARM BRACKET 532 42 65-89...
  • Page 19 WHEELS REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART 01.15.001-B DESCRIPTION 532 40 51-61 COVER 532 18 44-71 SHOULDER SCREW 812 00 00-45 RETAINER RING 532 19 21-26 WHEEL DRIVER 532 18 24-66 RETAINER RING 532 18 76-22 WHEEL LOBE...
  • Page 20 WHEELS REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 43 65-68 WHEEL ASSEMBLY LH 532 43 65-69 WHEEL ASSEMBLY RH 01.06.024-A PART DESCRIPTION 43 84-46 CABLE BRACKET LH 43 84-47 CABLE BRACKET RH 817 49 04-08 SCREW 1/4 -20 X .500...
  • Page 21: Bag Of Parts

    BAG OF PARTS REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 16 96-75 RETAINER PIN 532 42 91-12 WRENCH 532 18 45-05 REMOTE SPRING 532 17 98-29 SHOULDER BOLT 1/4−20 532 19 17-30 LOCKNUT 1/4−20 872 25 05-05...
  • Page 22 BAG OF PARTS REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 01.14.012-A PART DESCRIPTION 532 18 04-45 SHIFTER ROD TOP 532 18 77-16 SHIFTER ROD BOTTOM 872 27 05-05 CARRIAGE BOLT 5/16-18 X .75 532 15 53-77 NUT 5/16-18 PART...
  • Page 23 DECALS REPAIR PARTS SNOW THROWER - MODEL NO. ST 268EP (96191003803), PRODUCT NO. 961 91 00-38 PART DESCRIPTION 532 19 96-83 DECAL, DANGER 532 19 96-82 DECAL, DANGER, DEFLECTOR 532 18 40-45 DECAL, DANGER 532 42 95-75 DECAL, INSTURCTION 532 42 95-69 DECAL, TRACTION LEVER 532 44 47-68 DECAL, HANDWARMER...
  • Page 24 08.31.11 SR...
