Intel 810 socket 370 motherboard
Table of Contents

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
Model Number:
GA-6WOZ7
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
E r i c L u
Signature:
Date:
Sep. 10, 1999
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device ,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection against harmful interference in
residential
installations.
generates, uses, and can radiate radio
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
This
equipment

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6WOZ7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gigabyte 6WOZ7

  • Page 1 Product Name: Mother Board generates, uses, and can radiate radio Model Number: GA-6WOZ7 frequency energy, and if not installed and used Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), in accordance with the instructions, may cause...
  • Page 2: Declaration Of Conformity

    Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-6WOZ7 is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive...
  • Page 3 6WOZ7 Intel 810 Socket 370 Motherboard USER'S MANUAL INTEL 810 Socket 370 Processor MAINBOARD REV. 1.3 Second Edition R-13-02-091206...
  • Page 5 How This Manual is Organized This manual is divided into the following sections: Manual revision information 1) Revision History Product item list 2) Item Checklist Product information & specification 3) Features Instructions on setting up the motherboard 4) Hardware Setup Product Performance &...
  • Page 6: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 6WOZ7 Motherboard Layout Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition Performance List P.22 Block Diagram P.23 Suspend to RAM Installation P.24 Memory Installation P.30 Page Index for BIOS Setup P.31...
  • Page 7: Revision History

    6WOZ7 Motherboard Revision History Revision Revision Note Date Initial release of the 6WOZ7 motherboard user’s manual. Sep.1999 Second release of the 6WOZ7 motherboard user’s manual Dec.1999 The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein.
  • Page 8: Item Checklist

    Item Checklist Item Checklist þThe 6WOZ7 Motherboard þCable for IDE / Floppy device þDiskettes or CD (IUCD) for motherboard utilities oInternal COM2 Cable (Optional) oInternal USB Cable (Optional) oCable for SCSI device þ6WOZ7 User’s Manual...
  • Page 9: Summary Of Features

    6WOZ7 Motherboard Summary of Features Form factor 25.7cm x 20.5cm Mini NLX SIZE form factor, 4 layers PCB. Ÿ Celeron Socket 370 Processor Ÿ 128 KB 2nd cache in CPU Ÿ Chipset Intel FW82810 ,consisting of: 82810DC100 Graphics and memory Ÿ...
  • Page 10 Summary Of Features On-board Sound YAMAHA YMF-744 (Optional) and AC’97 codec Ÿ Line In / Line Out / Mic In / AUX In / CD In / TEL / Ÿ SPDIF(Optional) / Game Port On-board LAN Intel GD 82559(Optional) Ÿ PS/2 Connector PS/2 Keyboard interface and PS/2 Mouse interface Ÿ...
  • Page 11: 6Woz7 Motherboard Layout

    6WOZ7 Motherboard 6WOZ7 Motherboard Layout COMA LINE LINE PS/2 JP23 JP25 JP27 JP18 YMF744 82559 JP24 JP26 JP16 GMCH JP28 82810 6WOZ7 82801 JP14 PGA 370 JP21 JP19 FWH32 JP13 JP12 BAT1 JP10...
  • Page 12 6WOZ7 Motherboard Layout $ Page Index for Connectors / Panel and Jumper Definition Page CPU Speed Setup Connectors Game & Audio Port COMA / COMB / VGA / LPT Port USB Connector PS/2 Keyboard & PS/2 Mouse Connector CPU / System Cooling FAN Power Connector P.10...
  • Page 13: Cpu Speed Setup

    6WOZ7 Motherboard CPU Speed Setup The system bus frequency can be switched at 66MHz, 100MHz and Auto by adjusting JP6 (See Figure 1). The CPU Frequency is control by BIOS. The CPU speed must match with the frequency RATIO. It will cause system hanging up if the frequency RATIO is higher than that of CPU.
  • Page 14 Connectors...
  • Page 16: Connectors

    Connectors Connectors Game & Audio Port Audio Port JP23 Line Out Game Port Line In COM A / COM B / VGA / LPT Port LPT PORT COM A COMB...
  • Page 17 6WOZ7 Motherboard...
  • Page 18: Usb Connector

    Connectors USB Connector Pin No. Definition USB V0 USB D0- USB D0+ 1 2 3 4 USB V1 USB D1- USB D1+ PS/2 Keyboard & PS/2 Mouse Connector PS/2 Mouse/ PS/2 Mouse Keyboard Pin No. Definition Data VCC(+5V) Clock PS/2 Keyboard...
  • Page 19: Cpu / System Cooling Fan Power Connector

    6WOZ7 Motherboard CPU Cooling FAN Power Connector Pin No. Definition +12V SENSE System Cooling FAN Power Connector Pin No. Definition +12V SENSE...
  • Page 20: Dfp Port [Optional]

    Connectors DFP Port (Optional) Onboard LAN Connector (Optional) Yellow LED (LAN Active LED) 2 – Green LED (LAN Link LED)
  • Page 21 6WOZ7 Motherboard...
  • Page 22: J2 (Cd Audio Line In)

    Connectors J2 : CD Audio Line In Pin No. Definition CD-L CD-R JP25 : SPDIF(The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dobly digital decoder.) (Optional) Pin No. Definition SPDIF OUT...
  • Page 23 6WOZ7 Motherboard...
  • Page 24: Jp26 (Aux In)

    Connectors JP26 : AUX IN JP26 Pin No. Definition AUX-L AUX-R TEL: The connector is for Modem with internal voice connector. JP24 Pin No. Definition Signal-In Signal-Out...
  • Page 25: Jp1 (Str Led Connector & Dimm Led)

    6WOZ7 Motherboard JP1 : STR LED Connector & DIMM LED DIMM LED STR LED Connector External...
  • Page 27: Panel And Jumper Definition

    6WOZ7 Motherboard Panel and Jumper Definition JP12 : Clear CMOS Function JP12 Pin No. Definition 1-2 close Clear CMOS 2-3 close Normal (Default) JP18 : Onboard Sound Function Selection (Optional) JP18 Pin No. Definition 1-2 close Onboard Sound Disable 2-3 close Onboard Sound...
  • Page 28 Panel and Jumper Definition...
  • Page 29: Jp16 (Onboard Lan Function) [Optional]

    6WOZ7 Motherboard JP16 : Onboard LAN Function (Optional) JP16 Pin No. Definition 1-2 close Onboard LAN Disable 2-3 close Onboard LAN Enable(Default) JP28 : Safe mode/Recovery/Normal JP28 Pin No. Definition 1-2close Normal(Default) 2-3close Safe mode 1-2-3open Recovery...
  • Page 30: Jp14 (Timeout Reboot Function)

    Panel and Jumper Definition JP14 : Timeout Reboot Function JP14 Pin No. Definition Open Timeout reboot(Default) Close No Reboot on timeout JP8 : Keyboard Power On Selection Pin No. Definition 1-2 close Keyboard Power on Enabled 2-3 close Keyboard Power on Disabled (Default)
  • Page 31: Jp27 (Usb Device Wake Up Selection)

    6WOZ7 Motherboard JP27 : USB Device Wake up Selection JP27 Pin No. Definition 1-2 close USB Device Wake up Enabled 2-3 close USB Device Wake up Disabled(Default) (If you want to use “USB KB/Mouse Wake from S3” function, you have to set the BIOS setting “USB KB/Mouse Wake from S3”...
  • Page 32: Jp19: Top Block Lock

    Panel and Jumper Definition JP19: Top Block Lock JP19 Pin No. Definition Close Top Block Unlock (Default) Open Top Block Lock JP10 : Case Open JP10 Pin No. Definition Signal...
  • Page 33: Jp13 (Str/Onboard Lan Wake Up Selection)

    6WOZ7 Motherboard JP13 : STR/Onboard LAN Wake Up Selection JP13 Pin No. Definition Close For STR/WOL Function Enabled Open For STR/WOL Function Disabled (Default) BAT1 : Battery + Danger of explosion if battery is incorrectly replaced. + Replace only with the same or equivalent type recommended by the manufacturer.
  • Page 34 Panel and Jumper Definition...
  • Page 35: J5~J8 (Diagnostic Led Connector)

    6WOZ7 Motherboard J5~J8 : Diagnostic LED Connector (Diagnostic code indicates BIOS routine when system hangs during POST.) Status Diagnostic Code Power On, Starting BIOS J5:ON / J6:ON / J7:ON / J8:ON Recovery Mode(BIOS ROM Checksum) J5:OFF / J6:ON / J7:ON / J8:ON Processor, Cache, etc.
  • Page 36: Performance List

    Performance List Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Celeron 533MHz processor...
  • Page 37: Block Diagram

    6WOZ7 Motherboard Block Diagram 66 / 100 MHz 14.318MHz 3.3V SDRAM PGA 370 DIMM Sockets Host Bus INTEL DRAM Bus Display cache FW82810 Memory 4MB (GMCH) PCI to ISA Bridge Winbond w83628 14.318MHz ISA Bus 100MHz Intel 66MHz 82559 ICS 9248-73...
  • Page 38: Suspend To Ram Installation

    Suspend to RAM Installation Suspend to RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 39 6WOZ7 Motherboard Step 2: (If you want to use STR Function, please set jumper JP13 Closed.) JP13 Pin No. Definition Close For STR/WOL Function Enabled Open For STR/WOL Function Disabled (Default) Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup.
  • Page 40 Suspend to RAM Installation A.3 How to put your system into STR mode? There are two ways to accomplish this: 1. Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” B.
  • Page 41 6WOZ7 Motherboard Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 42 Suspend to RAM Installation C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button.. A.4 How to recover from the STR sleep mode? There are seven ways to “wake up”...
  • Page 43 6WOZ7 Motherboard...
  • Page 44 Suspend to RAM Installation A.5 Notices : In order for STR to function properly, several hardware and software requirements must be satisfied: A. Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). B.
  • Page 46: Memory Installation

    Memory Installation Memory Installation The motherboard has 2 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 47: Page Index For Bios Setup

    6WOZ7 Motherboard $ Page Index for BIOS Setup Page The MAIN MENU P.33 Standard CMOS Features P.36 Advanced BIOS Features P.40 Advanced Chipset Features P.44 Integrated Peripherals P.46 Power Management Setup P.52 PnP/ PCI Configuration P.56 PC Health status P.58 Frequency / Voltage Control P.60...
  • Page 48: Entering Setup

    BIOS Setup BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...
  • Page 49: Getting Help

    6WOZ7 Motherboard GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page S etup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 50 BIOS Setup Standard CMOS Features This setup page includes all the items in standard compatible BIOS. Advanced BIOS Features This setup page includes all the items of Award special enhanced features. Advanced Chipset Features This setup page includes all the items of chipset special features. Integrated Peripherals This setup page includes all onboard peripherals.
  • Page 51 6WOZ7 Motherboard Save & Exit Setup Save CMOS value settings to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup.
  • Page 52: Standard Cmos Features

    BIOS Setup Standard CMOS Features The items in Standard CMOS Setup Menu (Figure 3) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software Standard CMOS Features Date (mm:dd:yy)
  • Page 53 6WOZ7 Motherboard...
  • Page 54 BIOS Setup Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Primary HDDs / Secondary HDDs The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 55 6WOZ7 Motherboard...
  • Page 56 BIOS Setup Floppy 3 Mode Support (for Japan Area) Disabled Normal Floppy Drive. Drive A Drive A is 3 mode Floppy Drive. Drive B Drive B is 3 mode Floppy Drive. Both Drive A & B are 3 mode Floppy Drives. Video The category detects the type of adapter used for the primary system monitor that must match your video display card and monitor.
  • Page 57: Extended Memory

    6WOZ7 Motherboard Memory The category is display -only which is determined by POST (Power On Self Test) of the BIOS. Base Memory The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system.
  • Page 58: Advanced Bios Features

    BIOS Setup Advanced BIOS Features CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software Advanced BIOS Features Virus Warning Disabled Item Help CPU Cache Enabled Menu Level 4 CPU L2 Cache ECC Checking Disabled Quick Power On Self Test Enabled Allows you to First Boot Device Floppy choose the VIRUS...
  • Page 59 6WOZ7 Motherboard CPU Cache These two categories speed up memory access. However, it depends on CPU / chipset design. Enabled Enable cache. ( Default value ) Disabled Disable cache. CPU L2 Cache ECC Checking Enabled Enable CPU L2 Cache ECC Checking.
  • Page 60: Typematic Rate Setting

    BIOS Setup Boot Up Floppy Seek During POST, BIOS will determine the floppy disk drive installed is 40 or 80 tracks. 360 K type is 40 tracks 720 K, 1.2 M and 1.44 M are all 80 tracks. Enabled BIOS searches for floppy disk drive to determine it is 40 or 80 tracks. Note that BIOS can not tell from 720 K, 1.2 M or 1.44 M drive type as they are all 80 tracks.
  • Page 61 6WOZ7 Motherboard OS Select For DRAM>64MB Non-OS2 Using non-OS2 operating system. ( Default value ) Using OS2 operating system and DRAM>64MB. HDD S.M.A.R.T. Capability Enabled Enabled HDD S.M.A.R.T. Capability. Disabled Disabled HDD S.M.A.R.T. Capability. ( Default value ) Report No FDD For WIN 95 Assign IRQ6 For FDD.
  • Page 62: Advanced Chipset Features

    BIOS Setup Advanced Chipset Features CMOS Setup Utility -Copyright( C ) 1984-1999 Award Software Advanced Chipset Features SDRAM CAS Latency Time Auto Item Help SDRAM Cycle Time Tras/Trc Menu Level 4 SDRAM RAS-to-CAS Delay SDRAM RAS Precharge Time DRAM Page Closing Policy Precharge Bank System BIOS Cacheable Enabled...
  • Page 63 6WOZ7 Motherboard SDRAM RAS Precharge Set SDRAM RAS Precharge is 3. Set SDRAM RAS Precharge is 2. ( Default value ) DRAM Page Closing Policy Precharge Bank Closing Policy Precharge Bank. ( Default value ) Precharge All Closing Policy Precharge All.
  • Page 64 BIOS Setup Auto-1 Set SDRAM Buffer Strength is Auto-1.
  • Page 65: Integrated Peripherals

    6WOZ7 Motherboard Integrated Peripherals CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software Integrated Peripherals On-Chip Primary PCI IDE Enabled Item Help On-Chip Secondary PCI IDE Enabled Menu Level 4 IDE Primary Master PIO Auto IDE Primary Slave PIO Auto IDE Secondary Master PIO...
  • Page 66 BIOS Setup On-Chip Primary PCI IDE Enabled Enable onboard 1st channel IDE port. ( Default value ) Disabled Disable onboard 1st channel IDE port. On-Chip Secondary PCI IDE Enabled Enable onboard 2nd channel IDE port. ( Default value ) Disabled Disable onboard 2nd channel IDE port.
  • Page 67: Usb Controller

    6WOZ7 Motherboard IDE Primary Slave UDMA Auto BIOS will automatically detect the IDE HDD Accessing mode. ( Default value ) Disabled Disable UDMA function. IDE Secondary Master UDMA Auto BIOS will automatically detect the IDE HDD Accessing mode. ( Default value ) Disabled Disable UDMA function.
  • Page 68: Power On Function

    BIOS Setup POWER ON Function Password Enter from 1 to 5 characters to set the Keyboard Power On Password. Mouse Left Double click on PS/2 left bottom. Mouse Right Double click on PS/2 right bottom. BUTTON ONLY If your keyboard have “POWER Key” button, you can press the key to power on your system.
  • Page 69 6WOZ7 Motherboard D Active Hi, Hi RxD set Hi, TxD set Hi. Hi, Lo RxD set Hi, TxD set Lo. ( Default value ) Lo, Hi RxD set Lo,TxD set Hi. Lo, Lo RxD set Lo,TxD set Lo. IR Transmittiion delay Set IR Transmittiion delay Enabled.
  • Page 70 BIOS Setup Midi Port Address Disabled Disabled On Board Midi Port. ( Default value ) Set On Board Midi Port is 300. Set On Board Midi Port is 330. Midi Port IRQ Set 5 for Midi Port IRQ. ( Default value ) Set 7 for Midi Port IRQ.
  • Page 71: Power Management Setup

    6WOZ7 Motherboard Power Management Setup CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software Power Management Setup S1(PowerOnSuspend) ACPI Suspend Type Item Help Power Management User Define Menu Level 4 Video Off Method DPMS Video Off In Suspend Suspend Type Stop Grant...
  • Page 72 BIOS Setup ACPI Suspend Type S1(PowerOn Suspend) Set ACPI Suspend type is S1. ( Default value ) S3(Suspend to RAM) Set ACPI Suspend type is S3. Power Management User Define For configuring our own power management features. ( Default value ) Min Saving Enable Green function.
  • Page 73 6WOZ7 Motherboard...
  • Page 74: Suspend Mode

    BIOS Setup Suspend Mode Disabled Disable Suspend Mode. ( Default value ) 1 min - 1 Hour Setup the timer to enter Suspend Mode. HDD Power Down Disable Disable HDD Power Down mode function. ( Default value ) 1-15 mins. Enable HDD Power Down mode between 1 to 15 mins.
  • Page 75 6WOZ7 Motherboard CPU Thermal-Throttling 87.5% Monitor CPU Temp. will cause system slow down CPU Duty Cycle to 87.5%. 75.0% Monitor CPU Temp. will cause system slow down CPU Duty Cycle to 75.0%. 62.5% Monitor CPU Temp. will cause system slow down CPU Duty Cycle to 62.5%.
  • Page 76: Pnp/ Pci Configuration

    BIOS Setup PCI PIRQ[A-D] # Enabled Monitor PCI PIRQ[A-D] IRQ Active. ( Default value ) Disabled Ignore PCI PIRQ[A-D] IRQ Active. PnP/PCI Configurations CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software PnP/PCI Configurations PNP OS Installed Item Help Reset Configuration Data Disabled Menu Level 4 Resources Controlled By...
  • Page 77: Resources Controlled By

    6WOZ7 Motherboard Resources Controlled by Manual User can set the PnP resource (I/O Address, IRQ & DMA channels) used by legacy ISA DEVICE. Auto(ESCD) BIOS automatically use these PnP rescuers. ( Default value ) IRQ (3,4,5,7,9, 10,11,12,14,15),DMA(0,1,3,5,6,7) assigned to ( Legacy ISA or "PCI/ISA PnP ) Legacy ISA The resource is used by Legacy ISA device.
  • Page 78: Pc Health Status

    BIOS Setup PC Health Status CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software PC Health Status Reset Case Open Status Disabled Item Help Case Opened Menu Level 4 Current CPU Temperature 41 C/105 F CPU FAN Speed 5443 RPM Power FAN Speed 0 RPM System FAN Speed 0 RPM...
  • Page 79 6WOZ7 Motherboard...
  • Page 80 BIOS Setup CPU FAN / Power FAN / System FAN Speed (RPM) Detect Fan speed status automatically. Current Voltage (V) VCORE / VGTL/ VCC3 / 12V / + 5V /VBAT /5VSB Detect system’s voltage status automatically. CPU Warning Temperature ( C / F) 65 C / 149 F Monitor CPU Temp.
  • Page 81: Frequency/Voltage Control

    6WOZ7 Motherboard Frequency/Voltage Control CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software Frequency/Voltage Control Auto Detect DIMM/PCI Clk Enabled Item Help Spread Spectrum Disabled Menu Level 4 CPU Type INTEL(R) CELERON Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults...
  • Page 82: Load Fail-Safe Defaults

    BIOS Setup Load Fail-Safe Defaults CMOS Setup Utility -Copyright( C ) 1984 -1999 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features Load Fail-Safe Defaults 4 Advanced Chipset Features Load Optimized Defaults 4 Integrated Peripherals Set Supervisor Password 4 Power Management Setup Set User Password 4 PnP/PCI Configurations...
  • Page 83: Load Optimized Defaults

    6WOZ7 Motherboard Load Optimized Defaults CMOS Setup Utility -Copyright( C ) 1984 -1999 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features Load Fail-Safe Defaults 4 Advanced Chipset Features Load Optimized Defaults 4 Integrated Peripherals Set Supervisor Password...
  • Page 84: Set Supervisor / User Password

    BIOS Setup Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. CMOS Setup Utility -Copyright( C ) 1984 -1999 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features...
  • Page 85 6WOZ7 Motherboard...
  • Page 86: Save To Cmos And Exit

    BIOS Setup Save & Exit Setup CMOS Setup Utility -Copyright( C ) 1984-1999 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features Load Fail-Safe Defaults 4 Advanced Chipset Features Load Optimized Defaults 4 Integrated Peripherals Set Supervisor Password 4 Power Management Setup Set User Password 4PnP/PCI Configurations...
  • Page 87: Exit Without Saving

    6WOZ7 Motherboard Exit Without Saving CMOS Setup Utility -Copyright( C ) 1984-1999 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features Load Fail-Safe Defaults 4 Advanced Chipset Features Load Optimized Defaults 4 Integrated Peripherals Set Supervisor Password...
  • Page 88: Appendix

    Appendix Appendix Appendix A : Onboard Driver Installation Procedure (In this manual, we assume that your CD-ROM Drive letter to be Drive D: ) Please reference IUCD CD directory D: \ Manual \ Whitney 810.pdf Appendix B : 810 INF update utility can’t find ICHxIDE.cat file automatically After the installation is of Winodws98 is completed, run the “Setup.exe”...
  • Page 89 C:\utility \ AWDFlash or AMIFlash <filename of the BIOS binary file intended for flashing> Once the process is finished, reboot the system ü MNote: Please download the newest BIOS from our website (www.gigabyte.com.tw) or contact your local dealer for the file.
  • Page 90 Appendix Appendix D : Acronyms Acor. Meaning Acor. Meaning Acor. Meaning ACPI Advanced Error checking Interrupt request configuration and correcting and power interface POST Power-on self Integrated dual Network interface test channel card enhanced Local area Special A.G.P. Accelerated network circumstance graphics port instructions...
  • Page 91 6WOZ7 Motherboard To be continued...
  • Page 92 Appendix Acro. Meaning Acro. Meaning Acro. Meaning Dual retention PCI A.G.P. Peripheral mechanism controller component interconnect Industry Audio Modem RIMM Rambus In-line standard Riser Memory Midule architecture CRIMM Continuity RIMM...
