DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
Model Number:
GA-6WMM
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Aug. 05, 1999
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device ,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection against harmful interference in
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
This
equipment
and
can
radiate
radio

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6WMM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gigabyte 6WMM

  • Page 1 Model Number: GA-6WMM frequency energy, and if not installed and used Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), in accordance with the instructions, may cause Class B Digital Device Supplementary Information: harmful interference to radio communications.
  • Page 2: Declaration Of Conformity

    Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-6WMM is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive...
  • Page 3 6WMM Pentium ® II / III / Celeron Processor Motherboard USER'S MANUAL Pentium ® II/III/Celeron Processor MAINBOARD REV. 1.3 Second Edition R-13-02-091013...
  • Page 5 How This Manual is Organized This manual is divided into the following sections: 1) Revision History Manual revision information 2) Item Checklist Product item list 3) Features Product information & specification 4) Hardware Setup Instructions on setting up the motherboard 5) Performance &...
  • Page 7: Table Of Contents

    TABLE OF CONTENT Revision History Item Checklist Summary of Features 6WMM Motherboard Layout Page index for CPU Speed Setup / Connectors / Panel and Jumper Definition Performance List P.29 Block Diagram P.30 Suspend to RAM installation P.31 Memory Installation P.37 Page index for BIOS Setup P.38...
  • Page 8: Revision History

    Revision History Revision Revision Note Date Initial release of the 6WMM motherboard user’s manual. Sep.1999 Second release of the 6WMM motherboard user’s manual Oct. 1999 The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein.
  • Page 9: Item Checklist

    Item Checklist Item Checklist þThe 6WMM Motherboard þCable for IDE / Floppy device þDiskettes or CD (IUCD) for motherboard utilities oInternal COMB Cable (Optional for VGA/AGP on-board Motherboard) oInternal USB Cable (Optional for Baby AT Motherboard) oCable for SCSI device...
  • Page 10: Summary Of Features

    6WMM Motherboard Summary of Features 24.4 cm x 24.2 cm MicroATX SIZE form factor, 4 layers Ÿ Form factor PCB. ® Pentium II/III/Celeron Processor Ÿ Cache Depend on CPU Ÿ ® Chipset Intel GMCH82810 / 810E,consisting of: 82810-DC100/82810E Graphics and memory Ÿ...
  • Page 11 Summary Of Features PS/2 Connector PS/2 Keyboard interface and PS/2 Mouse interface Ÿ BIOS Licensed AWARD BIOS, 4M bit FLASH RAM Ÿ Additional Features Internal/External Modem Wake up Ÿ Keyboard Password Wake up Ÿ System after AC back Ÿ Supports Wake-on-LAN (WOL), header Ÿ...
  • Page 12: 6Wmm Motherboard Layout

    6WMM Motherboard 6WMM Motherboard Layout JP12 PS/2 JP21 JP13 JP17 JP10 JP11 IDE2 IDE1 GMCH 82810 6WMM JP33 JP22 TV/DFP BAT1 PCI SLOT1 JP30 82801 PCI SLOT2 JP18 JP32 PCI SLOT3 JP31...
  • Page 13: Page Index For Cpu Speed Setup / Connectors / Panel And Jumper

    6WMM Motherboard Layout Page index for CPU Speed Setup / Connectors / Panel and Jumper Page Definition CPU Speed Setup Connectors GAME & Audio Port COMA / VGA / LPT Port COMB / USB Connector P.10 TV/DFP P.11 PS/2 Keyboard & PS/2 Mouse Connector P.11...
  • Page 14 6WMM Motherboard JP21 (AMR Selection) P.26...
  • Page 15 6WMM Motherboard Layout JP11 (STR Enable) P.27 JP18 (Safe mode/Recovery) P.27 BAT1 P.28...
  • Page 17: Cpu Speed Setup

    CPU Speed Setup CPU Speed Setup The system bus frequency can be switched between 66 / 100MHz and 133MHz by adjusting JP10 & JP17. The CPU Frequency is control by BIOS. JP10/JP17 Select the System Speed between 66 / 100MHz and 133MHz. JP17 JP10 JP10...
  • Page 18: Connectors

    6WMM Motherboard Connectors GAME & Audio Port GAME Port Line Out Line COM A / VGA / LPT Port LPT PORT COM A...
  • Page 19: Comb / Usb Connector

    Connectors COM B Port COM B USB Connector Pin No. Definition USB V0 USB D0- USB D0+ USB V1 USB D1- USB D1+ 1 2 3 4...
  • Page 20: Definition

    6WMM Motherboard TV/DFP : TV-Out / Digital Flat Panel Daughter card connector. RED LINE PS/2 Keyboard & PS/2 Mouse Connector PS/2 Mouse PS/2 Keyboard PS/2 Mouse/ Keyboard Pin No. Definition Data VCC(+5V) Clock...
  • Page 21: Cpu Fan / Pwr Fan

    Connectors CPU FAN Pin No. Definition +12V SENSE Power FAN Pin No. Definition +12V SENSE...
  • Page 22: System Fan

    6WMM Motherboard System FAN Pin No. Definition +12V SENSE ATX PWR Pin No. Definition 3,5,7,13, 15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off)
  • Page 23: Floppy

    Connectors J6 : IR/CIR Pin No. Definition IRRX IRTX CIRRX FLOPPY RED LINE...
  • Page 24: Ide 1(Primary)/ Ide 2(Secondary)

    6WMM Motherboard IDE1(Primary) , IDE2 (Secondary) RED LINE IDE 2 IDE 1 J2 : RING PWR ON (Internal Modem Card Wake Up) Pin No. Definition Signal...
  • Page 25: J4 (Wake On Lan)

    Connectors J4 : Wake on LAN Pin No. Definition +5V SB Signal J7 : CD Audio Line In Pin No. Definition AUX-L AUX-R...
  • Page 26: Jp9 (Tel)

    6WMM Motherboard JP9 : TEL: The connector is for Modem with internal voice connector Pin No. Definition Signal-In Signal-Out J8 : AUXIN Pin No. Definition AUX-L AUX-R...
  • Page 27: Jp31 (Usb Port Selection)

    Connectors JP31 : USB Port Selection Front Panel USB Enable Back Panel USB Enable FPUSB(Default) BPUSB 1-3close 3-5close 2-4close 4-6close JP30 : Front Panel USB Port Pin No. Definition 1,4,5,10 3,7,9 USBP0+ USBP0-...
  • Page 28: J17 (Front Panel Jumper)

    6WMM Motherboard J17 : Front Panel Jumper Pin No. Definition HD LED+ GN LED+ HD LED- PWR LED+ RESET SW Soft ON/OFF 10,12 Green SW IR RX IRTX IR Power J22 : Front Audio Jumper Pin No. Definition LINE-OUT–L LINE-OUT–R...
  • Page 29: Jp33 (Spdif)

    Connectors JP33 : SPDIF(The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dobly Digital decoder.) Pin No. Definition SPD OUT...
  • Page 30: Panel And Jumper Definition

    6WMM Motherboard Panel and Jumper Definition Panel Jumper GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED) Pin 1: LED anode(+) Pin 2: LED cathode(−) HD (IDE Hard Disk Active LED) Pin 1: LED anode(+) Pin 2: LED cathode(−)
  • Page 31: Jp13 (Keyboard Power On)

    Panel and Jumper Definition JP13 : Keyboard Power On Pin No. Definition 1-2 close Keyboard Power on Enabled 2-3 close Keyboard Power on Disabled (Default) JP21 : USB Device Wake up Selection Pin No. Definition Enable USB 1-2 close Wake up 2-3 close Disable USB Wake up(Default)
  • Page 32: Jp6 (Clear Cmos Function)

    6WMM Motherboard JP6 : Clear CMOS Function Pin No. Definition 1-2 close Clear CMOS 2-3 close Normal (Default) JP7 : CASE OPEN Pin No. Definition Signal...
  • Page 33: Jp2 (Str Led Connector)

    Panel and Jumper Definition JP2 : STR LED Connector STR LED Connector External. RAM Indicator LED1 JP1 : Top Block Lock Pin No. Definition Open TBL Lock Close UN Lock...
  • Page 34: Jp5 (Timeout Reboot Function)

    6WMM Motherboard JP5 : Timeout Reboot Function Pin No. Definition Open Timeout reboot Close No Reboot on timeout J1 : Buzzer Enable Pin No. Definition Open Internal Buzzer Disable Close Internal Buzzer Enable (Default)
  • Page 35: Jp32 (Onboard Sound Function Selection)

    Panel and Jumper Definition JP32 : Onboard Sound Function Selection Pin No. Definition Disable 1-2 close Onboard sound Enable 2-3 close Onboard sound (Default) J21 : AMR Selection Pin No. Definition 1-2close Secondary AMR 2-3close Disable CODEC...
  • Page 36 6WMM Motherboard JP11 : STR Enable Pin No. Definition Open STR Disabled (Default) Close STR Enabled JP18 : Normal / Safe mode / Recovery Pin No. Definition 1-2close Normal(Default) 2-3close Safe mode 1-2-3open Recovery...
  • Page 37 Panel and Jumper Definition BAT1 : Battery + Danger of explosion if battery is incorrectly replaced. + Replace only with the same or equivalent type recommended by the manufacturer. + Dispose of used batteries according to the manufacturer’ s instructions.
  • Page 38: Performance List

    6WMM Motherboard Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.)
  • Page 39 Memory Installation Hi-End Winstone99 24.7...
  • Page 41: Block Diagram

    Performance List Block Diagram 66 / 100 / 133 MHz 16.67 MHz 3.3V SDRAM Slot 1 DIMM Sockets Host Bus INTEL DRAM Bus Display cache FW82810/ Memory 4MB FW82810E (GMCH) PCI to ISA Bridge W83628F/ 283629D ISA Bus 100MHz 66MHz ICS 9248-73 Ultra DMA 33MHz...
  • Page 42: Suspend To Ram Installation

    6WMM Motherboard Suspend to RAM Installation Suspend to RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “ state” of the system before it went to sleep and recover to that state.
  • Page 43 Suspend to RAM installation Step 2: (If you want to use STR Function, please set jumper JP11 (Closed.) Pin No. Definition Open STR Disabled Close STR Enabled Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup.
  • Page 44 6WMM Motherboard A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “ Stand by” item in the “ Shut Down Windows” area. A. Press the “ Start” button and then select “ Shut Down”...
  • Page 45 Suspend to RAM installation Define the system ” power on” button to initiate STR sleep mode: A. Double click “ My Computer” and then “ Control Panel” B. Double click the “ Power Management” item.
  • Page 46 6WMM Motherboard C. Select the “ Advanced” tab and “ Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “ Power on” button..
  • Page 47 Suspend to RAM installation A.5 Notices : In order for STR to function properly, several hardware and software requirements must be satisfied: A. Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). B.
  • Page 48: Memory Installation

    6WMM Motherboard Memory Installation The motherboard has 2 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
