Gigabyte 6WXM7 User Manual
Hide thumbs Also See for 6WXM7:

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
GA-6WXM7
Model Number:
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any inference received, including interference
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
June. 28, 1999
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device ,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection against harmful interference in
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However,
there
interference will not occur in a particular
installation. If this equipment does cause
interference to radio or television equipment
This
equipment
and
can
radiate
is
no
guarantee
radio
that

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6WXM7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gigabyte 6WXM7

  • Page 1 Product Name: Mother Board generates, uses, radiate radio GA-6WXM7 Model Number: frequency energy, and if not installed and used Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), in accordance with the instructions, may cause...
  • Page 2: Declaration Of Conformity

    Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-6WXM7 is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive...
  • Page 3 6WXM7 Celeron AGP Motherboard USER'S MANUAL INTEL ® Celeron Socket 370 Processor MAINBOARD REV. 1.4 First Edition R-14-01-090729...
  • Page 5: Table Of Contents

    TABLE OF CONTENT Revision History Item Checklist Summary of Features 6WXM7 Motherboard Layout Page index for CPU Speed Setup / Connectors / Panel and Jumper Definition Performance List P.27 Block diagram P.28 Suspend RAM Installation (Optional) P.29 Introduce Dual BIOS (Optional) P.40...
  • Page 6: Revision History

    Revision Note Date 1.41 Initial release of the 6WXM7 motherboard user’s manual. Jul.1999 The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein.
  • Page 7: Item Checklist

    Item Checklist Item Checklist þThe 6WXM7 Motherboard þCable for IDE / Floppy device þDiskettes or CD (IUCD) for motherboard utilities þInternal COM2 Cable (Optional for VGA/AGP on-board Motherboard) oInternal USB Cable (Optional for Baby AT Motherboard) oCable for SCSI device þDisplay Driver(Optional)
  • Page 8 Summary of Feature...
  • Page 10: Summary Of Features

    6WXM7 Motherboard Summary of Features Form factor 30.5 cm x 19.1 cm ATX SIZE form factor, 4 layers PCB. Ÿ Celeron Socket 370 Processor Ÿ ® Chipset Intel 810 ,consisting of: 82810 PCI/AGP Controller(PAC) Ÿ 82801AA PCI IDE Xcelerator(PIIX4E) Ÿ...
  • Page 11 Summary Of Features ® ® PS/2 Keyboard interface and PS/2 Mouse Ÿ PS/2 Connector interface BIOS Licensed AWARD BIOS, 4M bit FLASH RAM Ÿ Additional Features Internal/External Modem Wake up Ÿ Keyboard Password Wake up Ÿ LAN Wake up Ÿ System after AC back Ÿ...
  • Page 12 Summary Of features...
  • Page 14: 6Wxm7 Motherboard Layout

    6WXM7 Motherboard 6WXM7 Motherboard Layout JP11 PS/2 JP25 JP27 JP26 GMCH 82810 JP12 JP10 JP17 PCI1 JP18 6WXM7 82801 PCI2 IT8712 PCI3 Backup JP23 BIOS JP21 IT8888 PCI4 Main BIOS PCI5 JP24...
  • Page 15: Page Index For Cpu Speed Setup / Connectors / Panel And Jumper

    6WXM7 Motherboard Layout Page index for CPU Speed Setup / Connectors / Panel and Jumper Page Definition CPU Speed Setup Connectors COMA / COMB / VGA / LPT Port GAME & Audio Port P.10 USB Connector P.10 TV/DFP P.11 PS/2 Keyboard & PS/2 Mouse Connector P.11...
  • Page 16 6WXM7 Motherboard Layout BAT 1 P.26...
  • Page 18: Cpu Speed Setup

    6WXM7 Motherboard CPU Speed Setup The system bus speed can be set Auto ¡ B 6 6MHz and 100MHz by JP11. The CPU Frequency Auto control by BIOS. The CPU speed must match with the frequency RATIO. It will cause system hanging up if the frequency RATIO is higher than that of CPU.
  • Page 19 CPU Speed Setup JP11 & JP13~JP16:(Optional) JP11 AUTO 66MHz JP11 JP11 GMCH 82810 JP15 JP16 JP15 JP14 JP13 JP16 JP14 JP13 6WXM7 82801 100MHz IT8712 JP11 Backup IT8888 BIOS Main BIOS JP16 JP15 JP14 JP13 <Figure-1>...
  • Page 20: Connectors

    6WXM7 Motherboard Connectors COM A / VGA / LPT Port LPT PORT COM A COM B Port COM B...
  • Page 21: Game & Audio Port

    Connectors GAME & Audio Port GAME Port Line Out MIC In Line In USB Connector Pin No. Definition USB V0 USB D0- USB D0+ 1 2 3 4 USB V1 USB D1- USB D1+...
  • Page 22: Definition

    6WXM7 Motherboard TV/DFP :TV-Out / Digital Flat Panel Daughter card connector. RED LINE PS/2 Keyboard & PS/2 Mouse Connector PS/2 Mouse PS/2 Mouse/ Keyboard Pin No. Definition Data VCC(+5V) PS/2 Keyboard Clock...
  • Page 23: Definition

    Connectors CPU FAN / PWR FAN Pin No. Definition Control +12V SENSE SYSTEM FAN Pin No. Definition Control +12V SENSE...
  • Page 24: Atx Pwr

    6WXM7 Motherboard ATX PWR Pin No. Definition 3,5,7,13,15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off) JP4 : Front Panel USB Port Pin No. Definition 1,4,5,10 3,7,9 USBP0+ USBP0-...
  • Page 25: Floppy

    Connectors J12 : CIR/IR Pin No. Definition 2,6,9 IRRX IRTX CIRRX KBVcc CIRTX FLOPPY RED LINE...
  • Page 26: Ide 1(Primary)/ Ide 2(Secondary)

    6WXM7 Motherboard IDE1(Primary) , IDE2 (Secondary) RED LINE IDE 2 IDE 1...
  • Page 27: Panel And Jumper Definition

    Panel and Jumper Definition Panel and Jumper Definition J9 : For 2X11 PINs Jumper S P K GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED) Pin 1: LED anode(+) Pin 2: LED cathode(−) HD (IDE Hard Disk Active Pin 1: LED anode(+) LED) Pin 2: LED cathode(−)
  • Page 28: Jp2 (Keyboard Power On)

    6WXM7 Motherboard JP2 : Keyboard Power On Pin No. Definition 1-2 close Keyboard Power on Enabled 2-3 close Keyboard Power on Disabled (Default) J11 : RING PWR ON (Internal Modem Card Wake Up) Pin No. Definition Signal...
  • Page 29: Jp9 (Clear Cmos)

    Panel and Jumper Definition JP9 : Clear CMOS Function Pin No. Definition 1-2 close Clear CMOS 2-3 close Normal (Default) J10 : Wake on LAN Pin No. Definition Signal...
  • Page 30: J6 (Cd Audio Line In) [Optional]

    6WXM7 Motherboard J6 : CD Audio Line In (Optional) JP18 : CASE OPEN Pin No. Definition Signal...
  • Page 31: Jp10 (Str Led Conn)

    Panel and Jumper Definition JP10 : STR LED CONN STR LED Connector External. JP10 RAM Indicator LED1 JP1 Close : STR Enable Pin No. Definition Close STR Enable Open STR Disable...
  • Page 32: Jp21 (Top Block Lock)

    6WXM7 Motherboard JP21 : Top Block Lock Pin No. Definition UN Lock(Default) Lock J19 : Timeout Reboot Function Pin No. Definition Open Timeout reboot Close No Reboot on timeout (Default)
  • Page 33: Jp6 (Spdif)

    Panel and Jumper Definition USB Keyboard Wake up Selection JP25 : Pin No. Definition 1-2 close Disable USB Wake up 2-3 close Enable USB Wake up JP6 : SPDIF(The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dobly Digital decoder.) Pin No.
  • Page 34: Jp8 (Aux In)

    6WXM7 Motherboard JP7 : TEL: The connector is for Modem with internal voice connector. Pin No. Definition Signal-In Signal-Out JP8 : AUX IN Pin No. Definition AUX-L AUX-R...
  • Page 35: Jp26/Jp27 (Usb Port Selection)

    Panel and Jumper Definition JP26/JP27 : USB Port Selection JP26 JP27 Front Panel USB Enable Back Panel USB Enable FPUSB BPUSB JP26 1-2close 2-3close JP27 1-2close 2-3close JP12 : Onboard Sound Function Selection (Optional) Pin No. Definition 1-2 close Disable Onboard sound 2-3 close Enable Onboard sound (Default)
  • Page 36: Jp17 (Amr Function Selection) [Optional]

    6WXM7 Motherboard JP17 : AMR Function Selection (Optional) Pin No. Definition 1-2 close AMR Secondary (Default) AMR Primary 2-3 close (SW AC97 Disabled) JP24 : Buzzer Enable (Optional) Pin No. Definition Open Internal Buzzer Disable Close Internal Buzzer Enable (Default)
  • Page 37: Jp23 (Safe Mode/Recovery/Normal)

    Panel and Jumper Definition JP23 : Safe mode/Recovery/Normal JP23 Pin No. Definition 1-2close Normal(Default) 2-3close Safe mode 1-2-3open Recovery BAT1 : Battery + Danger of explosion if battery is incorrectly replaced. + Replace only with the same or equivalent type recommended by the manufacturer.
  • Page 38: Performance List

    6WXM7 Motherboard Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.)
