Gigabyte GA-6WMZ7 User Manual
Gigabyte GA-6WMZ7 User Manual

Gigabyte GA-6WMZ7 User Manual

Intel 810 socket 370 motherboard
Table of Contents

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
Model Number:
GA-6WMZ7
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Dec. 15, 1999
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device ,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection against harmful interference in
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
This
equipment
and
can
radiate
radio

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GA-6WMZ7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gigabyte GA-6WMZ7

  • Page 1 Phone/Fax No: (818) 854-9338/ (818) 854-9339 hereby declares that the product Product Name: Mother Board Model Number: GA-6WMZ7 Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), Class B Digital Device Supplementary Information: This device complies with part 15 of the FCC Rules. Operation is subject to the...
  • Page 2: Declaration Of Conformity

    Safety of household and similar electrical appliances (Stamp) Declaration of Conformity We, Manufacturer/Importer (full address) G.B.T. Technology Träding GMbH declare that the product Mother Board GA-6WMZ7 is in conformity with EN 61000-3-2* EN60555-2 EN61000-3-3* EN60555-3 EN 50081-1 EN 50082-1 EN 55081-2...
  • Page 3 6WMZ7 Series Intel 810 Socket 370 Motherboard USER'S MANUAL INTEL 810 Socket 370 Processor MAINBOARD R-21-01-091207...
  • Page 4 How this manual is organized This manual is divided into the following sections: 1) Revision List 2) Item Checklist 3) Features 4) Hardware Setup 5) Performance & Block Diagram 6) Suspend to RAM 7) BIOS Setup 8) Appendix REV. 2.1 First Edition Manual revision information Product item list Product information &...
  • Page 5: Table Of Contents

    Revision History Item Checklist Summary of Features 6WMZ7 Series Motherboard Layout Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition P.6 Performance List Block Diagram Suspend to RAM Installation Memory Installation Page Index for BIOS Setup Appendix Table of Content P.29...
  • Page 6: Revision History

    6WMZ7 Series Motherboard Revision History Revision Revision Note Initial release of the 6WMZ7 Series motherboard user’s manual. The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners.
  • Page 7: Item Checklist

    Item Checklist Item Checklist þThe 6WMZ7 Series Motherboard þCable for IDE / Floppy device þDiskettes or CD (IUCD) for motherboard utilities þInternal COM2 Cable (Optional) oInternal USB Cable (Optional) oCable for SCSI device þ6WMZ7 Series User’s Manual...
  • Page 8: Summary Of Features

    6WMZ7 Series Motherboard Summary of Features Form factor Ÿ Ÿ Ÿ Chipset Intel GMCH82810 ,consisting of: Ÿ Ÿ Clock Generator Ÿ Ÿ Memory Ÿ Ÿ Ÿ I/O Control Ÿ Slots Ÿ Ÿ Ÿ Ÿ On-Board IDE Ÿ Ÿ On-Board Ÿ Peripherals Ÿ...
  • Page 9 On-board Sound Ÿ Ÿ On-Board LAN Ÿ PS/2 Connector Ÿ BIOS Ÿ Additional Features Ÿ Ÿ Ÿ Ÿ Ÿ Ÿ Drivers & Utilities Ÿ Ÿ Ÿ Ÿ Ÿ YAMAHA YMF-744 (Optional) and AC’97 code Line In / Line Out / Mic In / AUX In / CD In / TEL / SPDIF / Game Port 82559(Optional) PS/2 Keyboard interface and PS/2 Mouse interface...
  • Page 10 6CXE Motherboard...
  • Page 12: 6Wmz7 Series Motherboard Layout

    6WMZ7 Series Motherboard 6WMZ7 Series Motherboard Layout PS/2 JP10 PCISLOT1 AC97 JP12 PCISLOT2 PCISLOT3 JP22 JP25 JP24 PGA 370 GMCH 82810 Display Cache TV/DFP Display Cache 6WMZ7 82559 JP11 82801 IDE2 IDE1 BAT1 JP19 JP15 JP23 JP18 JP13 JP14 BIOS JP20 JP21...
  • Page 13: Page Index For Cpu Speed Setup / Connectors / Panel And Jumper Definition

    Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors Game & Audio Port COMA / VGA / LPT Port COMB Port USB & LAN Connector TV/DFP PS/2 Keyboard & PS/2 Mouse Connector CPU / Power Cooling FAN Power Connector System Cooling FAN Power Connector ATX Power JP18 (Front Panel USB Port)
  • Page 14: Cpu Speed Setup

    6WMZ7 Series Motherboard CPU Speed Setup The system bus frequency can be switched at 66MHz, 100MHz, 133MHz and Auto by adjusting JP4/JP24 (See Figure 1). The CPU Frequency is control by BIOS. The CPU speed must match with the frequency RATIO. It will cause system hanging up if the frequency RATIO is higher than that of CPU.
  • Page 15: Connectors

    Connectors Connectors Game & Audio Port GAME Port MIC In Line Out Line In COM A / VGA / LPT Port LPT PORT COM A...
  • Page 16: Comb Port

    6WMZ7 Series Motherboard COMB Port USB & LAN Connector COMB Pin No. 1 2 3 4 1 – Green LED (LAN Link LED) 2 - Yellow LED (LAN Active LED) Definition USB V0 USB D0- USB D0+ USB V1 USB D1- USB D1+...
  • Page 17: Tv/Dfp

    TV/DFP : TV-Out / Digital Flat Panel Daughter card connector. PS/2 Keyboard & PS/2 Mouse Connector RED LINE PS/2 Mouse Mouse/ Keyboard Pin No. PS/2 Keyboard Connectors PS/2 Definition Data VCC(+5V) Clock...
  • Page 18: Cpu / Power Cooling Fan Power Connector

    6WMZ7 Series Motherboard CPU Cooling FAN Power Connector Power Cooling FAN Power Connector Pin No. Definition +12V SENSE Pin No. Definition +12V SENSE...
  • Page 19: System Cooling Fan Power Connector

    System Cooling FAN Power Connector ATX Power Pin No. Definition +12V SENSE Pin No. 3,5,7,13,15-17 1,2,11 4,6,19,20 5V SB stand by+5V PS-ON(Soft On/Off) Connectors Definition 3.3V +12V -12V Power Good...
  • Page 20: Jp18 (Front Panel Usb Port)

    6WMZ7 Series Motherboard JP18 : Front Panel USB Port J10 : IR/CIR Pin No. 1,4,5,10 3,7,9 Pin No. Definition IRRX IRTX CIRRX Definition USBP0+ USBP0-...
  • Page 21: Floppy Port

    Connectors Floppy Port RED LINE IDE1(Primary) , IDE2 (Secondary) Port RED LINE IDE 1 IDE 2...
  • Page 22: J11 (Ring Power On)

    6WMZ7 Series Motherboard J11 : Ring Power On (Internal Modem Card Wake Up) J7 : Wake on LAN Pin No. Definition Signal Pin No. Definition +5V SB Signal...
  • Page 23: J6 : Cd Audio Line In

    J6 : CD Audio Line In JP7 : AUX IN Pin No. Definition CD-L CD-R Pin No. Definition AUX-L AUX-R Connectors...
  • Page 24: Jp8 (Tel)

    6WMZ7 Series Motherboard JP8 : TEL: The connector is for Modem with internal voice connector JP6 : SPDIF(The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dobly digital decoder.) «Note : JP6 is only available when the motherboard use YMF744. Pin No.
  • Page 25: Jp22 (Str Led Connector & Dimm Led)

    JP22 : STR LED Connector & DIMM LED J13 : Speaker Jumper STR LED Connector External RAM Indicator LED1 Pin No. Definition VCC(+) Data( ) Connectors...
  • Page 26: Panel And Jumper Definition

    6WMZ7 Series Motherboard Panel and Jumper Definition JP23 : For 2X11 Pins Jumper GN (Green Switch) GD (Green LED) HD (IDE Hard Disk Active LED) SPK (Speaker Connector) RE (Reset Switch) P+P P (Power LED) PW (Soft Power Connector) Open: Normal Operation Close: Entering Green Mode Pin 1: LED anode(+) Pin 2: LED cathode( )
  • Page 27: Jp1 (Keyboard Power On)

    JP1 : Keyboard Power On JP2 : USB Device Wake up Selection (If you want to use “USB KB/Mouse Wake from S3” function, you have to set the BIOS setting “USB KB/Mouse Wake from S3” enabled, and the jumper “JP2” enabled). *(Power on the computer and as soon as memory counting starts, press <Del>.
  • Page 28: Jp19 (Clear Cmos Function)

    6WMZ7 Series Motherboard JP19 : Clear CMOS Function JP15 : Recovery/Safe mode/Normal Pin No. Definition 1-2 close Clear CMOS 2-3 close Normal (Default) Pin No. Definition 1-2close Normal(Default) 2-3close Safe mode 1-2-3open Recovery...
  • Page 29: Jp17 (Case Open)

    JP17 : Case Open J12 : Buzzer Enable (Optional) Panel and Jumper Definition Pin No. Definition Signal Pin No. Definition Open Internal Buzzer Disable Close Internal Buzzer Enable (Default)
  • Page 30: Jp16 (Timeout Reboot Function)

    6WMZ7 Series Motherboard JP16 : Timeout Reboot Function Pin No. Definition Open Timeout reboot Close No Reboot on timeout JP21 : Top Block Lock Pin No. Definition Open TBL Lock Close Unlock...
  • Page 31: Jp13 (Usb Port Selection)

    JP13 : USB Port Selection Front Panel USB Enable Back Panel USB Enable FPUSB(Default) 1-2close 4-5close JP12 : Onboard Sound Function Selection Panel and Jumper Definition BPUSB 2-3close 5-6close Pin No. Definition 1-2 close Disable Onboard Sound Enable Onboard Sound 2-3 close (Default)
  • Page 32: Jp10 (Amr Select)

    6WMZ7 Series Motherboard JP10 : AMR Select JP3 : LAN Power On & STR Connector Pin No. Definition 1-2close AMR Secondary AC’97 Disabled 2-3close (Disabled Onboard CODEC) Pin No. Definition Open Disable LAN Power On & STR(Default) Close Enable LAN Power On &...
  • Page 33: Jp14 (Power Led)

    JP14 : Power LED JP20 : Green LED Panel and Jumper Definition Pin No. Definition LED anode(+) LED cathode( ) LED cathode( ) Pin No. Definition LED anode( ) LED cathode(+)
  • Page 34: Jp11 (Onboard Lan Function)

    6WMZ7 Series Motherboard JP11 : Onboard LAN Function JP25 : Cyrix CPU Turbo Function (Optional) Pin No. Definition 1-2 short Onboard LAN Disable 2-3 short Onboard LAN Enable (Default) Pin No. Definition Open Normal Close Turbo...
  • Page 35 Panel and Jumper Definition BAT1 : Battery + Danger of explosion if battery is incorrectly replaced. + Replace only with the same or equivalent type recommended by the manufacturer. + Dispose of used batteries according to the manufacturer’ s instructions.
  • Page 36: Performance List

    6WMZ7 Series Motherboard Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Intel Celeron Intel Coppermine 600MHz processor...
  • Page 37: Block Diagram

    Block Diagram Coppermine Display Cache Memory 4MB Display Cache ATA66 IDE Channels 2 USB Ports COM Ports Winbond LPT Ports W83627 IR Floppy PS/2 INTEL Celeron 66/100/133 MHz Host Bus 66/100/133MHz 66/100/133 MHz GMCH 3.3V SDRAM 82810 14.318/33/48/66 MHz Interface PCI Bus 33MHz 82801AA YMF744...
  • Page 38: Suspend To Ram Installation

    6WMZ7 Series Motherboard Suspend to RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 39 Step 2: (If you want to use STR Function, please set jumper JP3 Closed.) Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup. Select the item “POWER MANAGEMENT SETUP”, then select “ACPI Suspend Type:S3 (Suspend to RAM)”.
  • Page 40 6WMZ7 Series Motherboard A.3 How to put your system into STR mode? There are two ways to accomplish this: 1. Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” B.
  • Page 41 Suspend to RAM Installation...
  • Page 42 6WMZ7 Series Motherboard Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 43 C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button.. A.4 How to recover from the STR sleep mode? There are seven ways to “wake up”...
  • Page 44 6WMZ7 Series Motherboard A.5 Notices : In order for STR to function properly, several hardware and software requirements must be satisfied: A. Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). B.
  • Page 46: Memory Installation

    6WMZ7 Series Motherboard Memory Installation The motherboard has 2 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 47: Page Index For Bios Setup

    $ Page Index for BIOS Setup The Main Menu Standard CMOS Features Advanced BIOS Features Advanced Chipset Features Integrated Peripherals Power Management Setup PnP/ PCI Configuration PC Health status Frequency / Voltage Control Load Fail-Safe Defaults Load Optimized Defaults Set Supervisor / User Password SAVE to CMOS and EXIT EXIT Without Saving BIOS Setup...
  • Page 48: Entering Setup

    6WMZ7 Series Motherboard BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...
  • Page 49: The Main Menu

    GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 50 6WMZ7 Series Motherboard...
  • Page 51 Standard CMOS Features This setup page includes all the items in standard compatible BIOS. Advanced BIOS Features This setup page includes all the items of Award special enhanced features. Advanced Chipset Features This setup page includes all the items of chipset special features. Integrated Peripherals This setup page includes all onboard peripherals.
  • Page 52 6WMZ7 Series Motherboard Save & Exit Setup Save CMOS value settings to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup.
  • Page 53: Standard Cmos Features

    Standard CMOS Features The items in Standard CMOS Setup Menu (Figure 3) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software Date (mm:dd:yy) Time (hh:mm:ss)
  • Page 54 6WMZ7 Series Motherboard Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. IDE Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 55 Floppy 3 Mode Support (for Japan Area) Disabled Normal Floppy Drive. Drive A Drive A is 3 mode Floppy Drive. Drive B Drive B is 3 mode Floppy Drive. Both Drive A & B are 3 mode Floppy Drives. Video The category detects the type of adapter used for the primary system monitor that must match your video display card and monitor.
  • Page 56 6WMZ7 Series Motherboard Memory The category is display-only which is determined by POST (Power On Self Test) of the BIOS. Base Memory The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system. The value of the base memory is typically 512 K for systems with 512 K memory installed on the motherboard, or 640 K for systems with 640 K or more memory installed on the motherboard.
  • Page 57: Advanced Bios Features

    Advanced BIOS Features CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software Virus Warning CPU Cache CPU L2 Cache ECC Checking Quick Power On Self Test First Boot Device Second Boot Device Third Boot Device Boot Other Device Swap Floppy Drive Boot Up Floppy Seek Boot Up NumLock Status Gate A20 Option...
  • Page 58: Boot Other Device

    6WMZ7 Series Motherboard CPU Cache These two categories speed up memory access. However, it depends on CPU / chipset design. Enable cache. ( Default value ) Enabled Disabled Disable cache. CPU L2 Cache ECC Checking Enabled Enable CPU L2 Cache ECC Checking. Disable CPU L2 Cache ECC Checking.
  • Page 59: Security Option

    Boot Up Floppy Seek During POST, BIOS will determine the floppy disk drive installed is 40 or 80 tracks. 360 K type is 40 tracks 720 K, 1.2 M and 1.44 M are all 80 tracks. Enabled BIOS searches for floppy disk drive to determine it is 40 or 80 tracks. Note that BIOS can not tell from 720 K, 1.2 M or 1.44 M drive type as they are all 80 tracks.
  • Page 60 6WMZ7 Series Motherboard OS Select For DRAM>64MB Non-OS2 Using non-OS2 operating system. ( Default value ) Using OS2 operating system and DRAM>64MB. HDD S.M.A.R.T. Capability Enabled Enabled HDD S.M.A.R.T. Capability. Disabled Disabled HDD S.M.A.R.T. Capability. ( Default value ) Report No FDD For WIN 95 Assign IRQ6 For FDD.
  • Page 61: Advanced Chipset Features

    Advanced Chipset Features CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software Advanced Chipset Features SDRAM CAS Latency Time SDRAM Cycle Time Tras/Trc SDRAM RAS-to-CAS Delay SDRAM RAS Precharge Time SDRAM Buffer Strength DRAM Page Closing Policy System BIOS Cacheable Video BIOS Cacheable Delayed Transaction On-Chip Video Window Size Local Memory Frequency...
  • Page 62 6WMZ7 Series Motherboard SDRAM RAS Precharge Set SDRAM RAS Precharge is 3. Set SDRAM RAS Precharge is 2. ( Default value ) SDRAM Buffer Strength Set SDRAM Buffer Strength is Auto. ( Default Value ) Auto Auto+1 Set SDRAM Buffer Strength is Auto+1. Auto-1 Set SDRAM Buffer Strength is Auto-1.
  • Page 63: Integrated Peripherals

    Set Display Cache Timing to Auto. ( Default value ) Auto Fast Set Display Cache Timing to Fast. Normal Set Display Cache Timing to Normal. Integrated Peripherals CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software On-Chip Primary PCI IDE On-Chip Secondary PCI IDE IDE Primary Master PIO IDE Primary Slave PIO IDE Secondary Master PIO...
  • Page 64 6WMZ7 Series Motherboard On-Chip Primary PCI IDE Enabled Enable onboard 1st channel IDE port. ( Default value ) Disabled Disable onboard 1st channel IDE port. Enable onboard 2nd channel IDE port. ( Default value ) Enabled Disabled Disable onboard 2nd channel IDE port. BIOS will automatically detect the IDE HDD Accessing mode.
  • Page 65 IDE Secondary Master UDMA Auto BIOS will automatically detect the IDE HDD Accessing mode. ( Default value ) Disabled Disable UDMA function. Auto BIOS will automatically detect the IDE HDD Accessing mode. Disable UDMA function. USB Controller Enable USB Controller. ( Default value ) Enabled Disabled Disable USB Controller.
  • Page 66: Onboard Fdc Controller

    6WMZ7 Series Motherboard POWER ON Function Password Enter from 1 to 5 characters to set the Keyboard Power On Password. Mouse Left Double click twice on PS/2 right bottom. BUTTON ONLY If your keyboard have “POWER Key” button, you can press the key to power on your system.
  • Page 67: Onboard Parallel Port

    D Active Hi, Hi RxD set Hi, TxD set Hi. Hi, Lo RxD set Hi, TxD set Lo. ( Default value ) Lo, Hi RxD set Lo,TxD set Hi. Lo, Lo RxD set Lo,TxD set Lo. IR Transmittiion delay Set IR Transmittiion delay Enabled. ( Default value ) Enabled Disabled Set IR Transmittiion delay Disabled.
  • Page 68 Midi Port Address Disabled On Board Midi Port. Set On Board Midi Port is 330. ( Default value ) Midi Port IRQ Set 10 for Midi Port IRQ.
  • Page 69: Power Management Setup

    Power Management Setup CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software Power Management Setup ACPI Suspend Type Power Management Video Off Method Video Off In Suspend MODE Suspend Mode Soft Off by PWR BTTN AC BACK Function ModemRingOn/WakeOnLan USB KB/M CPU Thermal Throttling * Date(of Month) Alarm Primary IDE 1...
  • Page 70: Power Management

    6WMZ7 Series Motherboard ACPI Suspend Type S1(PowerOn Suspend) S3(Suspend to RAM) Power Management User Define For configuring our own power management features. ( Default value ) Min Saving Enable Green function. Max Saving Disable Green function. Video off Method V/H SYNC+Blank BIOS will turn off V/H-SYNC when gets into Green mode for Green monitor power saving.
  • Page 71: Suspend Mode

    Suspend Mode Disable Suspend Mode. 1 min - 1 Hour Setup the timer to enter Suspend Mode. HDD Power Down Disable HDD Power Down mode function. ( Default value ) Disabled 1-15 mins. Enable HDD Power Down mode between 1 to 15 mins. Soft-off by PWR-BTTN ( Instant-off ) Instant-off Soft switch ON/OFF for POWER ON/OFF.
  • Page 72 Disabled Disabled this function. ( Default value ) Enabled Enabled USB KB/Mouse Wake From S3 function. CPU Thermal Throttling Monitor CPU Temp. will cause system slow down CPU Duty Cycle to 75.0% Monitor CPU Temp. will cause system slow down CPU Duty Cycle to 75.0%.
  • Page 73 FDD/COM/LPT Port Disabled Disable this function. Enabled Enable monitor FDC/COM/LPT for Green event. ( Default value ) PCI PIRQ[A- Enabled Monitor PCI PIRQ[A- Disabled PnP/PCI Configurations CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software PNP OS Installed Reset Configuration Data Resources Controlled By * IRQ Resources *DMA Resources...
  • Page 74 6WMZ7 Series Motherboard Reset Configuration Data Disabled Disable this function. ( Default value ) ESCD Clear PnP information in ESCD. Update Desktop Management Information data. Both Clear PnP information in ESCD & update DMI data. Resources Controlled by Manual User can set the PnP resource (I/O Address, IRQ & DMA channels) used by legacy ISA DEVICE.
  • Page 75: Pc Health Status

    PC Health Status CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software Reset Case Open Status Case Opened Current CPU Temperature CPU FAN Speed Power FAN Speed System FAN Speed VCORE VGTL VCC3 + 5V +12V - 12V - 5V VBAT 5VSB CPU Warning Temperature Shutdown Temperature...
  • Page 76 Monitor CPU Temp. at 70 C / 158 F. ( Default value ) 70 C / 158 F 75 C / 167 F Monitor CPU Temp. at 75 C / 167 F. Disabled Disabled this function. Shutdown Temp. ( C / F) (This function will be effective only for the operating systems that support ACPI Function.) Disabled Normal Operation...
  • Page 77: Frequency/Voltage Control

    Frequency/Voltage Control CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software Frequency/Voltage Control Auto Detect DIMM/PCI Clk Spread Spectrum CPU Type CELERON(TM) Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults Figure 10: Frequency/Voltage Control Auto Detect DIMM/PCI Clk Disabled Disabled Auto Detect DIMM/PCI Clk.
  • Page 78: Load Fail-Safe Defaults

    6WMZ7 Series Motherboard Load Fail-Safe Defaults CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software 4 Standard CMOS Features 4Advanced BIOS Features 4Advanced Chipset Features 4Integrated Peripherals 4Power Management Setup 4PnP/PCI Configurations Load Fail-Safe Defaults (Y/N)? N 4PC Health Status ESC:Quit F10:Save &...
  • Page 79 BIOS Setup...
  • Page 80: Load Optimized Defaults

    6WMZ7 Series Motherboard Load Optimized Defaults CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software 4 Standard CMOS Features 4Advanced BIOS Features 4Advanced Chipset Features 4Integrated Peripherals 4Power Management Setup 4PnP/PCI Configurations Load Optimized Defaults (Y/N)? N 4PC Health Status ESC:Quit F10:Save &...
  • Page 81: Set Supervisor / User Password

    Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software 4 Standard CMOS Features 4Advanced BIOS Features 4Advanced Chipset Features 4Integrated Peripherals...
  • Page 82: Save To Cmos And Exit

    6WMZ7 Series Motherboard Save & Exit Setup CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software 4 Standard CMOS Features 4Advanced BIOS Features 4Advanced Chipset Features 4Integrated Peripherals 4Power Management Setup 4PnP/PCI Configurations SAVE to CMOS and EXIT (Y/N)? Y 4PC Health Status ESC:Quit F10:Save &...
  • Page 83: Exit Without Saving

    Exit Without Saving CMOS Setup Utility-Copyright( C ) 1984-1999 Award Software 4 Standard CMOS Features 4Advanced BIOS Features 4Advanced Chipset Features 4Integrated Peripherals 4Power Management Setup 4PnP/PCI Configurations Quit Without Saving (Y/N)? N 4PC Health Status ESC:Quit F10:Save & Exit Setup Type "Y"...
  • Page 84: Appendix

    6WMZ7 Series Motherboard Appendix Appendix A : Onboard Driver Installation Procedure (In this manual, we assume that your CD-ROM Drive letter to be Drive D: ) Please reference IUCD CD directory D: \ Manual \ Whitney 810.pdf Appendix B : 810 INF update utility can’t find ICHxIDE.cat file automatically After the installation is of Winodws98 is completed, run the “...
  • Page 85 C:\utility\ AWDFlash or AMIFlash <filename of the BIOS binary file intended for flashing> Once the process is finished, reboot the system ü MNote : Please download the newest BIOS from our website (www.gigabyte.com.tw) or contact your local dealer for the file. Appendix...
  • Page 86 6WMZ7 Series Motherboard Appendix D : Acronyms Acro. Meaning ACPI Advanced configuration and power interface POST Power-on self test Local area network Extended capabilities port Advanced power management Direct memory access Megahertz ESCD Extended system configuration data Central processing unit Symmetric multi-processi Universal...
  • Page 87 Acro. Meaning Dual retention mechanism Industry standard architecture CRIMM Continuity RIMM Acro. Meaning Acro. PCI A.G.P. controller Audio Modem RIMM Riser Appendix Meaning Peripheral component interconnect Rambus In-line Memory Midule...
