Gigabyte 6OMM7 User Manual
Gigabyte 6OMM7 User Manual

Gigabyte 6OMM7 User Manual

Socket 370 processor motherboard
Table of Contents

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854- 9338/ (818) 854-9339
hereby declare s that the product
Product Name:
Mother Board
Model Number:
GA - 6OMM7
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
E r i c L u
Signature:
Date:
May. 22, 2000
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection against harmful interference in
residential
installations.
generates, uses, and can radiate radio
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
This
equipment

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6OMM7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gigabyte 6OMM7

  • Page 1 Product Name: Mother Board generates, uses, and can radiate radio Model Number: GA - 6OMM7 frequency energy, and if not installed and used Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), in accordance with the instructions, may cause...
  • Page 2: Declaration Of Conformity

    Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-6OMM7 is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive...
  • Page 3 6OMM7 Socket 370 Processor Motherboard USER'S MANUAL Socket 370 Processor Motherboard REV. 1.1 First Edition...
  • Page 4 R-11-01-000511...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: Manual revision information 1) Revision History Product item list 2) Item Checklist Product information & specification 3) Features Instructions on setting up the motherboard 4) Hardware Setup Product performance &...
  • Page 7: Table Of Contents

    Table Of Content Revision History Item Checklist Summary of Features 6OMM7 Motherboard Layout Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition Performance List P.29 Block Diagram P.30 Suspend to RAM Installation P.31 Memory Installation P.37 Page Index for BIOS Setup P.38...
  • Page 8: Revision History

    Revision Revision Note Date Initial release of the 6OMM7 motherboard user’s manual. May.2000 The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein.
  • Page 9: Item Checklist

    Item Checklist Item Checklist þThe 6OMM7 motherboard þCable for IDE / floppy device þDiskettes or CD (IUCD) for motherboard driver & utility oInternal COM B Cable (Optional) oInternal USB Cable (Optional) oCable for SCSI device þ6OMM7 user’s manual...
  • Page 10: Summary Of Features

    6OMM7 Motherboard Summary Of Features Form Factor 24.3 cm x 20.5 cm Micro ATX form factor, 4 layers PCB. Ÿ Socket 370 processor Ÿ Intel Pentium !!! 100/133MHz FSB, Coppermine core FC-PGA Intel Celeron 100MHz FSB, Coppermine core PC-PGA 2nd cache in CPU (Depend on CPU) Ÿ...
  • Page 11 Summary of Features PS/2 Connector PS/2 keyboard interface and PS/2 mouse interface Ÿ BIOS Licensed AWARD BIOS, 4M bit Flash ROM Ÿ Additional Features Supports Wake-on-LAN (WOL) Ÿ Supports Internal / External modem wake up Ÿ Includes 3 fan power connectors Ÿ...
  • Page 12: 6Omm7 Motherboard Layout

    6OMM7 Motherboard 6OMM7 Motherboard Layout PS/2 LED1 PGA 370 JP25 6OMM7 FW82815 BAT1 JP27 DFP/TV AC’97 JP12 PCI1 JP13 ICH82801 PCI2 JP14 JP15 JP20 PCI3 JP21 JP23 JP18 JP24 JP22...
  • Page 13: Page Index For Cpu Speed Setup/Connectors/Panel And Jumper Definition

    6OMM7 Motherboard Layout Page Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors Game & Audio Port COM A / VGA / LPT Port USB Connector P.10 PS/2 Keyboard & PS/2 Mouse Connector P.10 J1 (CPU Fan) P.11...
  • Page 14 6OMM7 Motherboard JP14 (Timeout Reboot Function) P.26...
  • Page 15 6OMM7 Motherboard Layout JP15 (Safe mode/Recovery/Normal) P.26 JP23 (PCI/AGP 3VAUX) P.27 JP24 (AMR Selection) [Optional] P.27 BAT1 (Battery) P.28...
  • Page 16: Cpu Speed Setup

    CPU Speed Setup CPU Speed Setup The system bus frequency can be switched at 66MHz, 100MHz, 133MHz and Auto by adjusting JP10/JP11/JP26 (See Figure 1). The CPU Frequency is control by BIOS. The CPU speed must match with the frequency RATIO. It will cause system hanging up if the frequency RATIO is higher than that of CPU.
  • Page 17 CPU Speed Setup your system can run under these specific bus frequencies properly will depend on your hardware configurations, including CPU, Chipsets, SDRAM, Cards….etc.
  • Page 18: Connectors

    6OMM7 Motherboard Connectors Game & Audio Port Game Port Line Out MIC In Line In COM A / VGA / LPT Port LPT Port COM A...
  • Page 19: Usb Connector

    Connectors USB Connector Pin No. Definition USB V0 USB D0- USB D0+ USB V1 USB D1- 1 2 3 4 USB D1+ PS/2 Keyboard & PS/2 Mouse Connector PS/2 Mouse PS/2 Keyboard PS/2 Mouse/ Keyboard Pin No. Definition Data VCC(+5V) Clock...
  • Page 20: J1: Cpu Fan

    6OMM7 Motherboard J1: CPU Fan Pin No. Definition +12V SENSE J2: Power Fan Pin No. Definition +12V SENSE...
  • Page 21: J14: System Fan

    Connectors J14: System Fan Pin No. Definition +12V SENSE ATX Power Pin No. Definition 3,5,7,13,15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB stand by+5V PS-ON(Soft On/Off)
  • Page 22: Jp13: Ir/Cir

    6OMM7 Motherboard JP13: IR/CIR Pin No. Definition IRRX IRTX CIRRX Floppy Port Red Line...
  • Page 23: Ide 1(Primary)/ Ide 2(Secondary) Port

    Connectors IDE1 (Primary), IDE2 (Secondary) Port IDE 2 IDE 1 Red Line J13: Ring Power On (Internal Modem Card Wake Up) Pin No. Definition Signal...
  • Page 24: J12: Wake On Lan

    6OMM7 Motherboard J12: Wake On LAN Pin No. Definition +5V SB Signal J7: TEL: The connector is for Modem with internal voice connector Pin No. Definition Signal-In Signal-Out...
  • Page 25: J6: Aux_In

    Connectors J6: AUX_IN Pin No. Definition AUX-L AUX-R J5: CD Audio Line In Pin No. Definition CD-L CD-R...
  • Page 26: Jp7: Str Led Connector & Led1: Dimm Led

    6OMM7 Motherboard JP7: STR LED Connector & LED1: DIMM LED DIMM LED STR LED Connector External Front USB Port (Optional) Pin No. Definition 1,4,5,10 3,7,9 USBP0+ USBP0-...
  • Page 27: J10: Extra Smbus

    Connectors J10: Extra SMBUS Pin No. Definition SMB CLK SMB DATA JP25: USB Port Selection (Optional) Front Panel USB Enable Back Panel USB Enable FPUSB BPUSB(Default) 1-2close 2-3close 4-5close 5-6close...
  • Page 28: Dfp/Tv Out Connector

    6OMM7 Motherboard DFP/TV Out Connector í Can be use Gigabyte’s Digital Flat Panel/TV-Out Daughter card (GA-DFP-x). JP27: SCR: Smart Card Reader Pin No. Definition 2,3,4,8,13 5,6,10,12 DATA Clock 9,14...
  • Page 29: Panel And Jumper Definition

    Panel and Jumper Definition Panel And Jumper Definition J11: For 2x11 Pins Jumper GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED) Pin 1: LED anode(+) Pin 2: LED cathode( ) HD (IDE Hard Disk Active LED) Pin 1: LED anode(+) Pin 2: LED cathode( ) SPK (Speaker Connector)
  • Page 30 6OMM7 Motherboard...
  • Page 31: Jp18: Clear Cmos Function

    Panel and Jumper Definition JP18: Clear CMOS Function Pin No. Definition 1-2 close Clear CMOS 2-3 close Normal (Default) JP4: STR Enable Pin No. Definition Open STR Disabled (Default) Close STR Enabled...
  • Page 32: Jp3: Ps/2 Keyboard Power On

    6OMM7 Motherboard JP3: PS/2 Keyboard Power On Pin No. Definition 1-2 close PS/2 Keyboard Power on Enabled 2-3 close Normal (Default) JP22: Case Open Pin No. Definition Signal...
  • Page 33 Panel and Jumper Definition...
  • Page 34: Jp1 (Rear Usb Device Wake Up Selection)

    6OMM7 Motherboard JP1: Rear USB Device Wake up Selection (USB Connector à CN2) Pin No. Definition Enabled Rear USB Device 1-2 close Wake up 2-3 close Normal (Default) (If you want to use “USB KB/Mouse Wake from S3” function, you have to set the BIOS setting “USB KB/Mouse Wake from S3”...
  • Page 35: Jp21: Top Block Lock

    Panel and Jumper Definition JP21: Top Block Lock Pin No. Definition Open Top Block Lock Close Top Block Unlock (Default) JP5: Over Voltage CPU Speed Up (Magic Booster) (When JP5 set “Close”, CPU Voltage is rising 10%) Pin No. Definition Close Turbo (Default) [Voltage enhance 10%]...
  • Page 36: Jp6: Dimm Over Voltage (Optional)

    6OMM7 Motherboard JP6: DIMM Over Voltage (Optional) Pin No. Definition Close Enabled DIMM Over Voltage Open Disabled DIMM Over Voltage (Default) JP12: Internal Buzzer (Optional) Pin No. Definition Open Internal Buzzer Disabled Close Internal Buzzer Enabled (Default)
  • Page 37 Panel and Jumper Definition JP14: Timeout Reboot Function Pin No. Definition Open Timeout Reboot Close No Reboot on Timeout JP15: Safe mode/Recovery/Normal Pin No. Definition 1-2close Normal (Default) 2-3close Safe mode 1-2-3open Recovery...
  • Page 38 6OMM7 Motherboard...
  • Page 39 Panel and Jumper Definition JP23: PCI/AGP 3VAUX Pin No. Definition Open Disabled PCI/AGP 3VAUX Function Close Enabled PCI/AGP 3VAUX (Default) JP24: AMR Selection (Optional) Pin No. Definition 1-2close AMR Secondary AMR Primary 2-3close AC’97 Disabled (Default) (Disabled Onboard CODEC)
  • Page 40 6OMM7 Motherboard...
  • Page 41 Panel and Jumper Definition BAT1: Battery Danger of explosion if battery is incorrectly replaced. + Replace only with the same or equivalent type recommended by the manufacturer. + Dispose of used batteries according to the manufacturer’s instructions.
  • Page 42: Performance List

    6OMM7 Motherboard Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.)
  • Page 43: Block Diagram

    Block Diagram Block Diagram Socket 370 66/100/133 MHz 2X/4X Display Host Bus 66/100/133MHz 66/100/133 MHz Intel 3.3V SDRAM FW82815 Display Cache 100 MHz 9250AF -25 14.318/33/48/66 MHz Interface 3 PCI PCI Bus 33MHz 82801AA ATA66 IDE Channels DFP/TV AC’97 Link 2 USB Ports Game Port COM Port...
  • Page 44: Suspend To Ram Installation

    6OMM7 Motherboard Suspend To RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 45 Suspend to RAM Installation Step 2: (If you want to use STR Function, please set jumper JP4 Closed.) Pin No. Definition Open STR Disabled (Default) Close STR Enabled Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup.
  • Page 46 6OMM7 Motherboard A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” B. Choose the “Stand by” item and press “OK”...
  • Page 47 Suspend to RAM Installation Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 48 6OMM7 Motherboard...
  • Page 49 Suspend to RAM Installation C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button.. A.4 How to recover from the STR sleep mode? There are seven ways to “wake up”...
  • Page 50 6OMM7 Motherboard...
  • Page 51 Suspend to RAM Installation A.5 Notices: In order for STR to function properly, several hardware and software requirements must be satisfied: A. Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). B.
  • Page 52: Memory Installation

    6OMM7 Motherboard Memory Installation The motherboard has 3 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 53: Page Index For Bios Setup

    BIOS Setup $ Page Index for BIOS Setup Page Main Menu P.40 Standard CMOS Features P.43 Advanced BIOS Features P.47 Advanced Chipset Features P.50 Integrated Peripherals P.52 Power Management Setup P.57 PnP/ PCI Configurations P.61 PC Health Status P.63 Frequency / Voltage Control P.65 Load Fail-Safe Defaults P.66...
  • Page 54: Entering Setup

    6OMM7 Motherboard BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off.
  • Page 55: Main Menu

    BIOS Setup GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 56: Set Supervisor Password

    6OMM7 Motherboard Standard CMOS Features This setup page includes all the items in standard compatible BIOS. Advanced BIOS Features This setup page includes all the items of Award special enhanced features. Advanced Chipset Features This setup page includes all the items of chipset special features.
  • Page 57 BIOS Setup Save & Exit Setup Save CMOS value settings to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup.
  • Page 58: Standard Cmos Features

    6OMM7 Motherboard Standard CMOS Features The items in Standard CMOS Setup Menu (Figure 3) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the...
  • Page 59 BIOS Setup...
  • Page 60 6OMM7 Motherboard Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. IDE Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 61 BIOS Setup Floppy 3 Mode Support (for Japan Area) Disabled Normal Floppy Drive. (Default value) Drive A Drive A is 3 mode Floppy Drive. Drive B Drive B is 3 mode Floppy Drive. Both Drive A & B are 3 mode Floppy Drives. Video The category detects the type of adapter used for the primary system monitor that must match your video display card and monitor.
  • Page 62: Extended Memory

    6OMM7 Motherboard Memory The category is display -only which is determined by POST (Power On Self Test) of the BIOS. Base Memory The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system.
  • Page 63: Advanced Bios Features

    BIOS Setup Advanced BIOS Features CMOS Setup Utility -Copyright( C ) 1984-2000 Award Software Advanced BIOS Features Virus Warning Disabled Item Help BIOS Flash Protection Disabled ø Processor Number Feature Menu Level 4 Enabled First Boot Device Floppy Allows you to Second Boot Device HDD-0 choose the VIRUS...
  • Page 64 6OMM7 Motherboard BIOS Flash Protection Enabled Enabled BIOS Flash Protection. Disabled Disabled BIOS Flash Protection. (Default Value) Processor Number Feature This item will show up when you install the Pentium !!! processor. Enabled Pentium !!! Processor Number Feature. (Default value) Disabled Disable this function.
  • Page 65: Security Option

    BIOS Setup Typematic Rate (Chars / Sec.) 6-30 Set the maximum Typematic rate from 6 chars. Per second to 30 characters. Per second. (Default value: 6) Typematic Delay (Msec.) 250-1000 Set the time delay from first key to repeat the same key in to computer. (Default value: 250) Security Option This category allows you to limit access to the system and Setup, or just to Setup.
  • Page 66: Advanced Chipset Features

    6OMM7 Motherboard Advanced Chipset Features CMOS Setup Utility -Copyright( C ) 1984-2000 Award Software Advanced Chipset Features Top Performance Disabled Item Help SDRAM Timing Control Auto ø Menu Level 4 SDRAM CAS Latency Time ø SDRAM Cycle Time Tras/Trc ø...
  • Page 67 BIOS Setup For Fastest SDRAM DIMM module.
  • Page 68 6OMM7 Motherboard SDRAM Cycle Time Tras/Trc Set SDRAM Tras/Trc Cycle time is 6/8 SCLKs. (Default value) Set SDRAM Tras/Trc Cycle time is 5/7 SCLKs. SDRAM RAS -to-CAS delay Set SDRAM RAS-to-CAS delay 3 SCLKs. (Default value) Set SDRAM RAS-to-CAS delay 2 SCLKs.
  • Page 69: Integrated Peripherals

    BIOS Setup Integrated Peripherals CMOS Setup Utility -Copyright( C ) 1984-2000 Award Software Integrated Peripherals On-Chip Primary PCI IDE Enabled Item Help On-Chip Secondary PCI IDE Enabled Menu Level 4 IDE Primary Master PIO Auto IDE Primary Slave PIO Auto IDE Secondary Master PIO Auto IDE Secondary Slave PIO...
  • Page 70 6OMM7 Motherboard On-Chip Secondary PCI IDE Enabled Enabled onboard 2nd channel IDE port. (Default value) Disabled Disabled onboard 2nd channel IDE port. IDE Primary Master PIO (for onboard IDE 1st channel) Auto BIOS will automatically detect the IDE HDD Accessing mode.
  • Page 71: Usb Controller

    BIOS Setup IDE Secondary Master UDMA Auto BIOS will automatically detect the IDE HDD Accessing mode. (Default value) Disabled Disable UDMA function. IDE Secondary Slave UDMA Auto BIOS will automatically detect the IDE HDD Accessing mode. (Default value) Disabled Disabled UDMA function. USB Controller Enabled Enabled USB Controller.
  • Page 72 6OMM7 Motherboard POWER ON Function Password Enter from 1 to 5 characters to set the Keyboard Power On Password. Mouse Click Double click on PS/2 mouse left button. BUTTON ONLY If your keyboard have “POWER Key” button, you can press the key to power on your system.
  • Page 73 BIOS Setup UR2 Duplex Mode IR Function Duplex Half. (Default Value) Half IR Function Duplex Full. Full Onboard Parallel port 378/IRQ7 Enabled onboard LPT port and address is 378/IRQ7. (Default Value) 278/IRQ5 Enabled onboard LPT port and address is 278/IRQ5. Disabled Disabled onboard LPT port.
  • Page 74: Power Management Setup

    6OMM7 Motherboard Power Management Setup CMOS Setup Utility -Copyright( C ) 1984-2000 Award Software Power Management Setup S1(PowerOn suspend) ACPI Suspend Type Item Help Video Off Method DPMS Menu Level 4 Suspend Type Stop Grant MODEM Use IRQ Suspend Mode...
  • Page 75: Suspend Mode

    BIOS Setup Video off Method V/H SYNC+Blank BIOS will turn off V/H-SYNC when gets into Green mode for Green monitor power saving. Blank Screen BIOS will only black monitor when gets into Green mode. DPMS BIOS will use DPMS Standard to control VGA card. (The Green type VGA card will turn off V/H-SYNC automatically.) (Default value) Suspend Type...
  • Page 76 6OMM7 Motherboard Power LED in Suspend Blinking Set Power LED in Suspend at Blinking mode. (Default value) Set Power LED in Suspend at On mode. Off/Dual Set Power LED in Suspend at Off/Dual color mode. Wake-Up by PCI card Disabled Disabled this function.
  • Page 77 BIOS Setup Resume by Alarm You can set “Resume by Alarm” item to Enabled and key in date/time to power on system. Disabled Disable this function. (Default value) Enabled Enable alarm function to POWER ON system. If the default value is Enabled. Date ( of Month) Alarm : 0~31 Time ( hh: mm: ss) Alarm :...
  • Page 78: Pnp/Pci Configurations

    6OMM7 Motherboard PnP/PCI Configurations CMOS Setup Utility -Copyright( C ) 1984-2000 Award Software PnP/PCI Configurations Reset Configuration Data Disabled Item Help Menu Level 4 Resources Controlled By Auto (ESCD) X IRQ Resources Press Enter When resources are controlled manually, assign each system...
  • Page 79 BIOS Setup PCI/VGA Palette Snoop Enabled For havi n g Vi d eo Card on ISA Bus and VGA Card on PCI Bus. Disabled For VGA Card only. (Default value)
  • Page 80: Pc Health Status

    6OMM7 Motherboard PC Health Status CMOS Setup Utility -Copyright( C ) 1984-2000 Award Software PC Health Status Reset Case Open Status Disabled Item Help Case Opened Menu Level 4 VCORE 1.936 V VGTL 1.424 V VCC3 3.264 V + 5V 4.730 V...
  • Page 81 BIOS Setup CPU FAN / Power FAN / System FAN Speed (RPM) Detect Fan speed status automatically. CPU Temperature Select ( C) 65 C / 149 F Monitor CPU Temp. at 65 C / 149 F. 70 C / 158 F Monitor CPU Temp.
  • Page 82: Frequency/Voltage Control

    6OMM7 Motherboard Frequency/Voltage Control CMOS Setup Utility -Copyright( C ) 1984-2000 Award Software Frequency/Voltage Control Auto Detect DIMM/PCI Clk Enabled Item Help CPU Clock Ratio Menu Level 4 Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail - Safe Defaults F7:Optimized Defaults...
  • Page 83: Load Fail-Safe Defaults

    BIOS Setup Load Fail-Safe Defaults CMOS Setup Utility -Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features Load Fail - Safe Defaults 4 Advanced Chipset Features Load Optimized Defaults 4 Integrated Peripherals Set Supervisor Password 4 Power Management Setup Set User Password...
  • Page 84: Load Optimized Defaults

    6OMM7 Motherboard Load Optimized Defaults CMOS Setup Utility -Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features Load Fail-Safe Defaults 4 Advanced Chipset Features Load Optimized Defaults 4 Integrated Peripherals Set Supervisor Password...
  • Page 85: Set Supervisor / User Password

    BIOS Setup Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. CMOS Setup Utility -Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features Load Fail-Safe Defaults...
  • Page 86: Save & Exit Setup

    6OMM7 Motherboard CMOS Setup Utility -Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features Load Fail-Safe Defaults 4 Advanced Chipset Features Load Optimized Defaults 4 Integrated Peripherals Set Supervisor Password 4 Power Management Setup...
  • Page 87 BIOS Setup...
  • Page 88: Exit Without Saving

    6OMM7 Motherboard Exit Without Saving CMOS Setup Utility -Copyright( C ) 1984-2000 Award Software 4 Standard CMOS Features 4 Frequency/Voltage Control 4 Advanced BIOS Features Load Fail-Safe Defaults 4 Advanced Chipset Features Load Optimized Defaults 4 Integrated Peripherals Set Supervisor Password...
  • Page 90: Appendix

    6OMM7 Motherboard Appendix Appendix A: Intel 815 Chipset Driver Installation A. Windows 9x INF Update Utility Insert the support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the setup screen.
  • Page 91 Appendix MWhen the Windows 9x INF Update Utility installation is completed, please restart your computer.
  • Page 92 6OMM7 Motherboard B: Intel 815 Chipset VGA Graphics Driver Installation Insert the support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the setup screen. 1.Click “Intel 815 Chipset VGA 2.Click ”Next”.
  • Page 93 Appendix...
  • Page 94 6OMM7 Motherboard C. Intel ICH IDE ATA66 Driver Installation Insert the support CD that came with your motherboard into your CD-ROM drive or double-click the CD drive icon in My Computer to bring up the setup screen. 1.Click “Intel ICH IDE ATA66 Driver”...
  • Page 95 Appendix 7.Click “Finish” to restart computer.
  • Page 96 C:\utility \ AWDFlash or AMIFlash <filename of the BIOS binary file intended for flashing>. Once the process is finished, reboot the system. ü MNote: Please download the newest BIOS from our website (www.gigabyte.com.tw) or contact your local dealer for the file.
  • Page 97 Appendix Appendix C: Issues To Beware Of When Installing AMR Please use inverse AMR card like the one in order to avoid mechanical problem. (See Figure A) PCI Slot Figure A: Inverse AMR Card (Default) PCI Slot Figure B: Non inverse AMR Card...
  • Page 98 6OMM7 Motherboard Appendix D: Acronyms Acor. Meaning ACPI Advanced Configuration and Power Interface POST Power-On Self Test Local Area Network Extended Capabilities Port Advanced Power Management Direct Memory Access Megahertz ESCD Extended System Configuration Data Central Processing Unit Symmetric Multi-Processing...
  • Page 99 Appendix DIMM Dual Inline Memory Module DRAM Dynamic Random Access Memory PCI A.G.P. Controller Audio Modem Riser To be continued… Acor. Meaning Peripheral Component Interconnect RIMM Rambus in-line Memory Module Dual Retention Mechanism Industry Standard Architecture Memory Translator Hub CRIMM Continuity RIMM...

This manual is also suitable for:

Ga-6omm7

Table of Contents
