  • Page 1 686DLX USER'S MANUAL Pentium II Processor MAINBOARD REV. 1 First Edition R-01-01-080121...
  • Page 2 686DLX The author assumes no responsibility for any errors or omissions which may appear in this document nor does it make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners.

  • Page 3: Table Of Contents

    Table of Contents TABLE OF CONTENTS INTRODUCTION 1.1. PREFACE......................1-1 1.2. KEY FEATURES ....................1-1 1.3. PERFORMANCE LIST..................1-2 1.4. BLOCK DIAGRAM ....................1-3 1.5. INTRODUCE THE Pentium II Processor & AGP ..........1-4 1.6. What is AGP .......................1-6 1.7. What is RAID PORT ...................1-6 SPECIFICATION 2.1.
  • Page 4 686DLX 3.10. IDE & ATAPI DEVICE INSTALLATION.............3-7 3.11. SCSI DEVICE INSTALLATION .................3-8 3.12. PERIPHERAL DEVICE INSTALLATION............3-10 3.13. KEYBOARD & PS/2 MOUSE INSTALLATION..........3-10 3.14. KEYBOARD SETTING FUNCTION..............3-10 BIOS CONFIGURATION 4.1. ENTERING SETUP .....................4-1 4.2. CONTROL KEYS ....................4-1 4.3. GETTING HELP....................4-2 4.3.1. Main Menu ......................4-2 4.3.2.
  • Page 5 Table of Contents...

  • Page 7: Introduction

    Introduction INTRODUCTION 1.1. PREFACE Welcome to use the 686DLX motherboard. The motherboard is a Dual Pentium II Processor based PC / AT compatible system with AGP / PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want.

  • Page 8: Performance List

    686DLX ATX form factor, Double stack I/O connector, 4 layers PCB. 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users.

  • Page 9: Block Diagram

    Introduction 1.4. BLOCK DIAGRAM SLOT1 SLOT1 3.3V EDO/SDRAM DIMM Sockets Host Bus AGP Bus DRAM 82443LX CHIPSET PCI Bus SLOT Adaptec 66MHz AIC-7880P 33MHz 66MHz CLOCK 33MHz 66MHz 33MHz 14.318MHz SC652EY PCI Bus 14.318MHz 66MHz 48MHz IDE Bus PIIX4 24MHz 82371AB CHIPSET Ultra...
  • Page 10 686DLX 1.5. INTRODUCE THE Pentium II Processor & AGP Figure 1:Retention Mechanism & attach Mount Figure 2:OEM Pentium II Processor...
  • Page 11 Introduction Figure 3:Heatsink / FAN & Heat sink support for OEM Pentium II Processor Figure 4:Boxed Pentium II Processor & Heat sink support...

  • Page 12: What Is Agp

    686DLX 1.6. What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32- bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing.

  • Page 13: Specification

    Specification SPECIFICATION 2.1. HARDWARE Dual Pentium II processor 200 – 633 MHz. Dual 242 pins 66MHz slot1 on board. Onboard Buzzer Alarm when detect "CPU FAN PROTECTION Failure" or “ CPU Overheat” . Automatically slow down CPU speed when "CPU FAN Failure"...

  • Page 14: Software

    686DLX I/O PORTS Supports 2 16550 COM ports. (Using IRQ4, 3) Supports 1 EPP/ECP LPT port. (Using IRQ7 or 5 and DMA3 or 1) Supports 1 1.44/2.88 MB Floppy port. (Using DMA2 & IRQ6) Supports 2 USB ports. Supports PS/2 Mouse. (Using IRQ12 ) Supports PS/2 Keyboard.
  • Page 15 Specification Max. 20A current at 5V.

  • Page 17: Hardware Installation

    Hardware Installation HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: The 686DLX mainboard. The Retention Mechanism & Attach Mount USER'S MANUAL for mainboard. Cable set for IDE¡ B F loppy & SCSI Device. Diskette & CD for SCSI Controller & Mainboard Utility.

  • Page 18: Mainboard Layout

    686DLX separate. 3.2. MAINBOARD LAYOUT COMA COMB Mouse SLOT5 SLOT3 SLOT1 PCI4 PCI3 PCI2 PCI1 POWER Adapte AIC-7880P SLOT6 SLOT4 SLOT2 RAID PORT BUZZER CN8 FLOPP BIOS 686DLX DIMM4 Bank 3 1 2 3 4 DIMM3 Bank 2 371A DIMM2...
  • Page 19 Hardware Installation J1: slot1 (For CPU2) For Pentium II processor installed. J2: CPU2 cooling FAN Power Connector Pin No. Function GND. +12V SENSE J3: slot1 (For CPU1) For Pentium II processor installed. J4: CPU1 cooling FAN Power Connector Pin No. Function GND.
  • Page 20 686DLX GND (-) J8: Hard Disk active LED (HD-LED) Pin No. Function LED POWER (+) LED POWER (-) LED POWER (+) J9: INFRARED Connector (IR) -- Function Option Pin No. Function IR Data Output IR Data Input POWER (+) J10: GN-SW On –...

  • Page 21: Dram Installation

    Hardware Installation S1: CPU INT. / EXT. FREQ. RATIO CPU TYPE CLK RATIO 200MHz 233MHz X3.5 266MHz 300MHz X4.5 333MHz 366MHz X5.5 POWER1: ATX POWER connector Pin No. Function 3,5,7,13,15- 4,6,19,20 VCC (+5V) +12V -12V Power Good 5V SB (Stand by +5V) PS-ON (Soft ON/OFF) 3.4.

  • Page 22: Cpu Speed Setup

    686DLX inserted into socket completely. 3.5. CPU SPEED SETUP The system's speed is fixed to 66.6MHz. The user can change the DIP SWITCH (S1) selection to set up the CPU speed for 200 - 633MHz processor. The CPU speed must match with the frequency RATIO. It will cause system hanging up if the frequency RATIO is higher than CPU's.

  • Page 23: Speaker Connector Installation

    Hardware Installation the manufacturer. M Dispose of used batteries according to the manufacturer’s instructions. 3.7. SPEAKER CONNECTOR INSTALLATION There is always a speaker in AT system for sound purpose. The 4 - Pins connector J5 is used to connect speaker. The speaker can work well in both direction of connector when it is installed to the connector J5 on mainboard.

  • Page 24: Scsi Device Installation

    686DLX devices can exist in a system. The J8 is the active LED port for ATAPI device. 3.11. SCSI DEVICE INSTALLATION There are two SCSI ports on board, One is 8bit SCSI port for SCSI-2 or ULTRA SCSI device, and total 7 8bit SCSI devices can exist in a system.
  • Page 25 Hardware Installation System has EXT. SCSI port but has not INT. SCSI device EXT. 50pin or 68pin SCSI port EXT. SCSI Terminator Mainboard EXT. SCSI DEVICE EXT. SCSI port Terminator ON Terminator ON CASE 2: BIOS SETUP (SCSI Terminator Enable: High Byte) System has 16 bit &...

  • Page 26: Peripheral Device Installation

    686DLX System has 16 bit EXT. SCSI port & 8 bit INT. SCSI device EXT. 50pin SCSI port 8 bit 8 bit WIDE SCSI Terminator SCSI DEVICE SCSI DEVICE SCSI ID SCSI ID Mainboard No.6 No.0 EXT. WIDE SCSI DEVICE...
  • Page 27 Hardware Installation After booting the O.S., there are some special functions used by keyboard as follows: "CTRL_ALT_DEL" Pressing these keys simultaneously will cause system to Warm Start (Software Reset). 3-11...
